Latest Update

🔥[2026.08] We added MiniMax-H3 support in ComfyUI-CacheDiT, validated on official T2V, I2V, and R2V workflows with same-seed comparisons, achieving 1.41-1.50x speedup while preserving native video output and stereo audio.

Overview

ComfyUI-CacheDiT brings 1.4-1.6x speedup to DiT (Diffusion Transformer) models through intelligent caching, with zero configuration required.

Inspired by llm-scaler, a high-performance GenAI solution for text, image, and video generation on Intel XPU.

Tested & Verified Models

MiniMax H3 uses residual-difference-based adaptive DBCache decisions rather than a fixed skip_interval, so that column is not applicable to H3.

Installation

Prerequisites

pip install -r requirements.txt

Install Node

Clone Repository

cd ComfyUI/custom_nodes/
git clone https://github.com/Jasonzzt/ComfyUI-CacheDiT.git

Quick Start

Ultra-Simple Usage (3 Steps)

For Image Models (Z-Image, Qwen-Image Flux.2 Klein):

1. Load your model
2. Connect to ⚡ CacheDiT Accelerator node
3. Connect to KSampler - Done!

[Load Checkpoint] → [⚡ CacheDiT Accelerator] → [KSampler]

For Video Models (MiniMax H3, LTX-2, WAN2.2 14B):

MiniMax H3:

[Load Diffusion Model] → [⚡ CacheDiT Accelerator] → [Model Sampling / Guider]

The Auto preset detects MiniMaxH3Model and enables Pattern 3 DBCache with in-place-safe residual boundaries for its joint audio-video transformer.

For explicit H3 tuning, use the optional ⚡ CacheDiT MiniMax H3 Advanced node in the same position. It exposes only the four H3 DBCache controls that are useful for workflow-level quality/speed tuning; Auto remains the recommended starting point.

The initial H3 preset is F8 / B0 / threshold 0.12 / warmup 3:

Control	Initial value	Meaning and initial-setting rationale
fn_blocks	8	Always execute the first 8 blocks. This gives the residual comparison an early, current-step signal while leaving most blocks eligible for reuse.
bn_blocks	0	Do not recompute tail blocks on a cache hit. This is the initial performance-oriented setting; raise it if a workflow needs more conservative tail refinement.
residual_diff_threshold	0.12	Reuse the middle-block residual when the normalized residual difference stays below 0.12. Lower values are more conservative; higher values usually increase cache hits and quality risk.
warmup_steps	3	Fully compute steps 0, 1, and 2; adaptive cache reuse becomes eligible at step 3.

These values are a validated integration baseline, not a model-wide optimum. T2V, I2V, and R2V workflows can respond differently to the same cache settings. Tune one control at a time and compare the same workflow, seed, steps, resolution, frame count, audio settings, and output codec.

LTX-2 Models:

[Load Checkpoint] → [⚡ LTX2 Cache Optimizer] → [Stage 1 KSampler]

WAN2.2 14B Models (High-Noise + Low-Noise MoE):

[High-Noise Model] → [⚡ Wan Cache Optimizer] → [KSampler]

[Low-Noise Model]  → [⚡ Wan Cache Optimizer] → [KSampler]

Each expert model gets its own optimizer node with independent cache.

Node Parameters

That's it! The generic node configures technical parameters automatically. Use the H3 Advanced node only when you need explicit H3 workflow tuning.

How It Works

Caching Logic:

# After warmup phase (first 3 steps)
if (current_step - warmup) % skip_interval == 0:
    # Reuse cached result
    result = cache
else:
    # Compute new result
    result = transformer.forward(...)
    cache = result.detach()  # Save to cache

Credits

Based on cache-dit by Vipshop's Machine Learning Platform Team.

Built for ComfyUI - the powerful and modular Stable Diffusion GUI.

FAQ

Note for LTX-2: This audio-visual transformer uses dual latent paths (video + audio). Use the dedicated ⚡ LTX2 Cache Optimizer node (not the standard CacheDiT node) for optimal temporal consistency and quality.

Note for WAN2.2 14B: This model uses a MoE (Mixture of Experts) architecture with High-Noise and Low-Noise models. Use the dedicated ⚡ Wan Cache Optimizer node (not the standard CacheDiT node) for best results.

Other DiT models should work with auto-detection, but may need manual preset selection.

Q: Does it support distilled low step models?

A: Currently, only Z-Image-Turbo (9 steps) has been tested and verified. Other low-step distilled models require further validation.

For extremely low step counts (< 6 steps), the warmup overhead significantly reduces the benefit - sacrificing quality for minimal speed gains is generally not worthwhile in such cases.

Q: How can I disable the node without restarting ComfyUI?

A: Simply set enable=False in the node and run it once. This will cleanly remove the CacheDiT optimization from your model without requiring a restart.

Q: Performance Dashboard shows 0% cache hit?

A: This usually means:

1. Model not properly detected - try manual preset selection
2. Inference steps too short (< 10 steps) - warmup takes most steps
3. Check logs for "Lightweight cache enabled" message

Q: Does this affect image quality?

A: Properly configured (default settings), quality impact is minimal:

---
