DoughNet :doughnut: A Visual Predictive Model for Topological Manipulation of Deformable Objects

Dominik Bauer¹, Zhenjia Xu^1,2, Shuran Song^1,2
1 Columbia University, ² Stanford University

Project website   •   Paper

Dependencies

Create the conda environment

• conda env create -f environment.yml

Install additional submodules

• git submodule init && git submodule update
• conda activate doughnet
• nvdiffrast: cd net/nvdiffrast && pip install -e . && cd ../..
• sdftoolbox: cd sim/sdftoolbox && pip install -e . && cd ../..

Downloads

• All required files are provided in this folder.
• Download our dataset for training, testing on synthetic and real manipulation trajectories and place it in data/dataset.h5.
• If you are only interested in the dataset, you can check the provided README for a simple data loader and a brief description of the structure.
• Download our pretrained weights to reproduce the results in the paper and place them in weights/{ae,dyn}.pth.

Evaluation

Using the provided weights, the evaluation reproduces the main results from the paper. Note that due to dataset preprocessing and weights trained from scratch using this public code base, the results may vary slightly. Alternatively, train the model from scratch or create a new dataset as described below. Make sure to adapt the paths in the config files accordingly.

• python net/prediction.py --config-name dyn "settings.test_only=True"

Training

Using the provided dataset, the autoencoder and the dynamics prediction are trained in two stages, as shown below. Alternatively, generate a custom dataset as described below.

Note that for multi-GPU training, e.g., using 2 GPUs, the settings.ddp flag needs to be set in the config. Run the scripts below with CUDA_VISIBLE_DEVICES=0,1 torchrun --standalone --nproc_per_node=2 {path_to_script} instead of python {path_to_script}.

Geometry-topology Autoencoder

• python net/prediction.py --config-name ae
• This saves the weights in the corresponding hydra output directory (i.e., outputs/{date}/{time when run was started}/best.pth). Either copy them to the default path (weights/ae.pth), or adapt the settings.resume_path in net/config/dyn.yaml accordingly before starting the next stage.

Dynamics Prediction

• python net/prediction.py --config-name dyn
• Again, the weights are saved in the corresponding hydra output directory. Follow the directions above to make sure that settings.test_path points to the desired weights when running subsequent evaluations.

Generation

Our simulation with topology annotation may be used to generate additional scenes or completely new datasets.

To this end, first, derive novel scene definitions from template.yaml, e.g., by adapting to_pos and to_quat (grasp pose), or close_d (final opening width).

Simulation

• python sim/generate.py
• This will create a log.pkl with particle-based information (and visualization.gif if render=True in config) in the scene directory.

Processing

• python sim/process.py
• This will process the simulated scenes in parallel and create data.h5 with additional mesh-based information.

Citation

@article{bauer2024doughnet,
  title={DoughNet: A Visual Predictive Model for Topological Manipulation of Deformable Objects},
  author={Bauer, Dominik and Xu, Zhenjia and Song, Shuran},
  journal={European Conference on Computer Vision (ECCV)},
  year={2024}
}
