Feature Squeezing: Detecting Adversarial Examples in Deep Neural Networks
December 19, 2017 ยท View on GitHub
@inproceedings{xu2018feature,
title={{Feature Squeezing: Detecting Adversarial Examples in Deep Neural Networks}},
author={Xu, Weilin and Evans, David and Qi, Yanjun},
booktitle={Proceedings of the 2018 Network and Distributed Systems Security Symposium (NDSS)},
year={2018}
}
The note was created to help reproduce the results of the Feature Squeezing paper. The code was developed on Python 2, but should be runnable on Python 3 with tiny modifications.
1. Install dependencies.
pip install -r requirements_cpu.txt
If you are going to run the code on GPU, install this list instead:
pip install -r requirements_gpu.txt
2. Fetch submodules.
git submodule update --init --recursive
3. Download the pre-trained target models.
mkdir downloads; curl -sL https://github.com/mzweilin/EvadeML-Zoo/releases/download/v0.1/downloads.tar.gz | tar xzv -C downloads
4. Download the pre-generated adversary examples. You may skip this step and generate adversarial examples on your machine.
mkdir results
curl -sL https://github.com/mzweilin/EvadeML-Zoo/releases/download/v0.1/results_MNIST_100_317f6_carlini.tar.gz | tar xzv -C results
curl -sL https://github.com/mzweilin/EvadeML-Zoo/releases/download/v0.1/results_CIFAR-10_100_de671_densenet.tar.gz | tar xzv -C results
curl -sL https://github.com/mzweilin/EvadeML-Zoo/releases/download/v0.1/results_ImageNet_100_a2749_mobilenet.tar.gz | tar xzv -C results
5. Evaluate with the MNIST dataset.
# Evaluate the robust classification accuracy and the detection performance.
python main.py --dataset_name MNIST --model_name carlini \
--attacks "\
fgsm?eps=0.3;\
bim?eps=0.3&eps_iter=0.06;\
carlinili?targeted=next&batch_size=1&max_iterations=1000&confidence=10;\
carlinili?targeted=ll&batch_size=1&max_iterations=1000&confidence=10;\
carlinil2?targeted=next&batch_size=100&max_iterations=1000&confidence=10;\
carlinil2?targeted=ll&batch_size=100&max_iterations=1000&confidence=10;\
carlinil0?targeted=next&batch_size=1&max_iterations=1000&confidence=10;\
carlinil0?targeted=ll&batch_size=1&max_iterations=1000&confidence=10;\
jsma?targeted=next;\
jsma?targeted=ll;" \
--robustness "none;\
FeatureSqueezing?squeezer=bit_depth_1;\
FeatureSqueezing?squeezer=median_filter_2_2;\
FeatureSqueezing?squeezer=median_filter_3_3;" \
--detection "FeatureSqueezing?squeezers=bit_depth_1&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=bit_depth_2&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=bit_depth_1,median_filter_2_2&distance_measure=l1&fpr=0.05;"
5. Evaluate with the CIFAR-10 dataset.
python main.py --dataset_name CIFAR-10 --model_name DenseNet \
--attacks "fgsm?eps=0.0156;bim?eps=0.008&eps_iter=0.0012;carlinili?targeted=next&confidence=5;carlinili?targeted=ll&confidence=5;deepfool?overshoot=10;carlinil2?targeted=next&batch_size=100&max_iterations=1000&confidence=5;carlinil2?targeted=ll&batch_size=100&max_iterations=1000&confidence=5;carlinil0?targeted=next&confidence=5;carlinil0?targeted=ll&confidence=5;jsma?targeted=next;jsma?targeted=ll;" \
--robustness "none;\
FeatureSqueezing?squeezer=bit_depth_5;\
FeatureSqueezing?squeezer=bit_depth_4;\
FeatureSqueezing?squeezer=median_filter_2_2;\
FeatureSqueezing?squeezer=non_local_means_color_13_3_4;" \
--detection "\
FeatureSqueezing?squeezers=bit_depth_1&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=bit_depth_2&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=bit_depth_3&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=bit_depth_4&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=bit_depth_5&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=median_filter_2_2&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=median_filter_3_3&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=non_local_means_color_11_3_2&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=non_local_means_color_11_3_4&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=non_local_means_color_13_3_2&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=non_local_means_color_13_3_4&distance_measure=l1&fpr=0.05;\
FeatureSqueezing?squeezers=bit_depth_5,median_filter_2_2,non_local_means_color_13_3_2&distance_measure=l1&fpr=0.05;"
6. Evaluate with the ImageNet dataset.
python main.py --dataset_name ImageNet --model_name MobileNet --nb_examples 100 \
--attacks "fgsm?eps=0.0078;bim?eps=0.0040&eps_iter=0.0020;carlinili?batch_size=1&targeted=next&confidence=5;carlinili?batch_size=1&targeted=ll&confidence=5;deepfool?overshoot=35;carlinil2?max_iterations=1000&batch_size=10&targeted=next&confidence=5;carlinil2?max_iterations=1000&batch_size=50&targeted=ll&confidence=5;carlinil0?batch_size=1&targeted=next&confidence=5;carlinil0?batch_size=1&targeted=ll&confidence=5;" \
--detection "FeatureSqueezing?squeezers=bit_depth_5,median_filter_2_2,non_local_means_color_11_3_4&distance_measure=l1&fpr=0.05"
7. Combine with Adversarial Training.
# Compare with FGSM-based Adversarial Training.
python main.py --dataset_name MNIST --model_name carlini --noselect --nb_examples 10000 \
--attacks "fgsm?eps=0.1;fgsm?eps=0.2;fgsm?eps=0.3;fgsm?eps=0.4;" \
--robustness "none;FeatureSqueezing?squeezer=bit_depth_1;"
python main.py --dataset_name MNIST --model_name cleverhans_adv_trained --noselect --nb_examples 10000 \
--attacks "fgsm?eps=0.1;fgsm?eps=0.2;fgsm?eps=0.3;fgsm?eps=0.4;" \
--robustness "none;FeatureSqueezing?squeezer=bit_depth_1;"
# Compare with PGD-based Adversarial Training.
python main.py --dataset_name MNIST --model_name pgdbase --noselect --nb_examples 10000 \
--attacks "pgdli?epsilon=0.1;pgdli?epsilon=0.2;pgdli?epsilon=0.3;pgdli?epsilon=0.4;" \
--robustness "none;FeatureSqueezing?squeezer=bit_depth_1;"
python main.py --dataset_name MNIST --model_name pgdtrained --noselect --nb_examples 10000 \
--attacks "pgdli?epsilon=0.1;pgdli?epsilon=0.2;pgdli?epsilon=0.3;pgdli?epsilon=0.4;" \
--robustness "none;FeatureSqueezing?squeezer=bit_depth_1;"
8. Compare with MagNet.
# Evaluate with MNIST.
python main.py --dataset_name MNIST --model_name carlini \
--attacks "fgsm?eps=0.3;bim?eps=0.3&eps_iter=0.06;carlinili?targeted=next&batch_size=1&max_iterations=1000&confidence=10;carlinili?targeted=ll&batch_size=1&max_iterations=1000&confidence=10;carlinil2?targeted=next&batch_size=100&max_iterations=1000&confidence=10;carlinil2?targeted=ll&batch_size=100&max_iterations=1000&confidence=10;carlinil0?targeted=next&batch_size=1&max_iterations=1000&confidence=10;carlinil0?targeted=ll&batch_size=1&max_iterations=1000&confidence=10;jsma?targeted=next;jsma?targeted=ll;" \
--detection "FeatureSqueezing?squeezers=bit_depth_1,median_filter_2_2&distance_measure=l1&threshold=1.2358;MagNet"
# Evaluate with CIFAR-10
python main.py --dataset_name CIFAR-10 --model_name DenseNet \
--attacks "fgsm?eps=0.0156;bim?eps=0.008&eps_iter=0.0012;carlinili?targeted=next&confidence=5;carlinili?targeted=ll&confidence=5;deepfool?overshoot=10;carlinil2?targeted=next&batch_size=100&max_iterations=1000&confidence=5;carlinil2?targeted=ll&batch_size=100&max_iterations=1000&confidence=5;carlinil0?targeted=next&confidence=5;carlinil0?targeted=ll&confidence=5;jsma?targeted=next;jsma?targeted=ll;" \
--detection "FeatureSqueezing?squeezers=bit_depth_5,median_filter_2_2,non_local_means_color_13_3_2&distance_measure=l1&threshold=1.7547;MagNet"
9. Evaluate Adaptive Adversary with MNIST.
# Adaptive adversary by He et al.
python main.py --dataset_name MNIST --model_name carlini \
--attacks "adaptive_carlini_l2?targeted=false&tf_squeezers=median_filter_2_2,binary_filter_0.5&distance_measure=l1&detector_threshold=0.002915;\
adaptive_carlini_l2?targeted=next&tf_squeezers=median_filter_2_2,binary_filter_0.5&distance_measure=l1&detector_threshold=0.002915;\
adaptive_carlini_l2?targeted=ll&tf_squeezers=median_filter_2_2,binary_filter_0.5&distance_measure=l1&detector_threshold=0.002915;" \
--detection "FeatureSqueezing?squeezers=binary_filter_0.5,median_filter_2_2&distance_measure=l1&threshold=0.002915;" \
--nodetection_train_test_mode
# Clip the adaptive adversarial examples by epsilon 0.3.
python main.py --dataset_name MNIST --model_name carlini \
--attacks "adaptive_carlini_l2?targeted=false&tf_squeezers=median_filter_2_2,binary_filter_0.5&distance_measure=l1&detector_threshold=0.002915;adaptive_carlini_l2?targeted=next&tf_squeezers=median_filter_2_2,binary_filter_0.5&distance_measure=l1&detector_threshold=0.002915;adaptive_carlini_l2?targeted=ll&tf_squeezers=median_filter_2_2,binary_filter_0.5&distance_measure=l1&detector_threshold=0.002915;" \
--detection "FeatureSqueezing?squeezers=bit_depth_1,median_filter_2_2&distance_measure=l1&threshold=0.002915;" \
--nodetection_train_test_mode --clip 0.3\
