HEPSUB RTP:Engine

Call Recording Endpoint

HOMER Seven allows external agents to subscribe capabilities to provide "on-demand" session details from external APIs, databases, etc. to augment internally available data without requiring data duplication and allowing creative use of the core HEP platform.

The HEPSUB RTP:Engine client will receive on-demand request from HOMER sessions, and will return any local metadata and PCAP recordings.

[ HOMER ] <---> [ HEPSUB-RTPENGINE ] <---> [ RTPENGINE META/PCAP ]

Status

• Beta Testing! APIs might change. Open an Issue if you'd like to join in.

Install

npm install

Configure

Configure your HOMER URL, API Token and local network settings in file config.js

HOMER HEPsub

Add the following profile to your HEPsub configuration

{
    "lookup_id": 0,
    "lookup_type": "pubsub",
    "lookup_field": "{\"data\":$source_field,\"fromts\":$fromts,\"tots\":$tots}",
    "lookup_range": [
        -300,
        200
    ],
    "source_fields": {
        "sid": "data_header.sid",
        "callid": "data_header.callid",
        "source_ip": "data_header.srcIp"
    },
    "lookup_profile": "pcap"
}

Initialize

npm start

Docker

To use our ready container, just populate the following variables and use the included docker-compose file:

      - PUBLIC_IP=   YOUR SERVICE IP/DOMAIN
      - HOMER_IP=    YOUR HOMER IP
      - HOMER_PORT=  YOUR HOMER PORT
      - HOMER_TOKEN= YOUR HOMER AUTH TOKEN

---

Made by Humans

This Open-Source project is made possible by actual Humans without corporate sponsors, angels or patreons.
If you use this software in production, please consider supporting its development with contributions or donations
