A Detailed Look at the HTTP/2 Header Compression Algorithm — HPACK
I. Introduction
In HTTP/1.1 (see [RFC7230]), header fields are not compressed. As the number of requests within a web page grows to tens or even hundreds, the redundant header fields in these requests unnecessarily consume bandwidth, significantly increasing latency.
SPDY [SPDY] initially addressed this redundancy by compressing header fields using the DEFLATE [DEFLATE] format, which proved to be very effective at representing redundant header fields. However, this approach exposed security risks, as demonstrated by attacks such as CRIME (Compression Ratio Info-leak Made Easy; see [CRIME]).
This specification defines HPACK, a new compression method that eliminates redundant header fields, limits vulnerabilities to known security attacks, and has bounded memory requirements in constrained environments. Section 7 describes the potential security issues of HPACK.
The HPACK format is deliberately designed to be simple and inflexible. Both properties reduce the risk of interoperability or security issues caused by implementation errors. No extension mechanism is defined; the format can only be changed by defining a complete replacement.
1. Overview
The format defined in this specification treats a list of header fields as an ordered collection of name-value pairs, which may include duplicate pairs. Names and values are considered opaque sequences of octets, and the order of header fields is preserved after compression and decompression.
Header field tables map header fields to index values, thereby enabling encoding. These header field tables can be incrementally updated when new header fields are encoded or decoded.
In the encoded form, a header field is represented either literally or as a reference to a header field in a header field table. Therefore, a list of header fields can be encoded using a mix of references and literal values.
Literal values can be encoded directly or using a static Huffman code (with a maximum compression ratio of 8:5).
The encoder is responsible for deciding which header fields to insert into the header field table as new entries. The decoder applies the modifications to the header field table specified by the encoder, reconstructing the list of header fields in the process. This keeps the decoder simple and interoperable with a variety of encoders.
Examples of representing header fields using these different mechanisms are provided in Appendix C.
Note: In HTTP/2, the definitions of request and response header fields remain unchanged, with only a few minor differences: all header field names are lowercase, and the request line is now split into the individual :method, :scheme, :authority, and :path pseudo-header fields.
2. Conventions
The key words “MUST”, “MUST NOT”, “REQUIRED”, “SHALL”, “SHALL NOT”, “SHOULD”, “SHOULD NOT”, “RECOMMENDED”, “MAY”, and “OPTIONAL” in this document are to be interpreted as described in RFC 2119 [RFC2119].
All numeric values are in network byte order. Unless otherwise specified, values are unsigned. Literal values are provided in decimal or hexadecimal where appropriate.
3. Terminology
This document uses the following terms:
Header Field: A name/value name-value pair. Both the name and the value are treated as opaque sequences of octets.
Dynamic Table: The dynamic table (see Section 2.3.2) is a table that associates stored header fields with index values. This table is dynamic and specific to an encoding or decoding context.
Static Table: The static table (see Section 2.3.1) is a table that statically associates frequently occurring header fields with index values. This table is ordered, read-only, always accessible, and can be shared across all encoding or decoding contexts.
Header List: A header list is an ordered collection of header fields that are encoded together and can contain duplicate header fields. The complete list of header fields contained in an HTTP/2 header block is the header list.
Header Field Representation: A header field can be represented in encoded form as either a literal or an index (see Section 2.4).
Header Block: An ordered list of header field representations that, once decoded, yields the complete header list.
II. Overview of the Compression Process
This specification does not describe a specific encoder algorithm. Instead, it precisely defines the expected behavior of the decoder, allowing an encoder to produce any encoding permitted by this definition.
1. Header List Ordering
HPACK preserves the order of header fields within a header list. The encoder MUST order the header field representations in a header block according to their order in the original header list. The decoder MUST order the header fields in the decoded header list according to their order in the header block.
2. Encoding and Decoding Contexts
To decompress a header block, the decoder only needs to maintain a dynamic table (see Section 2.3.2) as the decoding context. No other dynamic state is required.
When used for bidirectional communication (for example, in HTTP), the encoding and decoding dynamic tables maintained by an endpoint are completely independent; that is, the request and response dynamic tables are separate.
3. Indexing Tables
HPACK uses two tables to associate header fields with indexes. The static table (see Section 2.3.1) is predefined and contains common header fields, most of which have empty values. The dynamic table (see Section 2.3.2) is dynamic and can be used by the encoder to index repeated header fields in encoded header lists.
These two tables are combined into a single address space used to define index values (see Section 2.3.3).
(1) Static Table
The static table consists of a predefined static list of header fields. Its entries are defined in Appendix A.
(2) Dynamic Table
The dynamic table contains a list of header fields maintained in first-in, first-out order. The first and most recent entry in the dynamic table is at the lowest index, while the oldest entry in the dynamic table is at the highest index.
The dynamic table is initially empty. Entries are added as each header block is decompressed. The dynamic table can contain duplicate entries (that is, entries with the same name and the same value). Therefore, the decoder MUST NOT treat duplicate entries as an error.
The encoder decides how to update the dynamic table and therefore can control how much memory the dynamic table uses. To limit the decoder’s storage requirements, the size of the dynamic table is strictly bounded (see Section 4.2).
The decoder updates the dynamic table while processing the list of header field representations (see Section 3.2).
(3) Index Address Space
The static table and the dynamic table are combined into a single index address space.
Indexes between 1 and the length of the static table, inclusive, refer to elements in the static table (see Section 2.3.1).
Indexes strictly greater than the length of the static table refer to elements in the dynamic table (see Section 2.3.2). Subtract the length of the static table to find the index into the dynamic table.
An index strictly greater than the sum of the lengths of the two tables MUST be treated as a decoding error.
For a static table size of s and a dynamic table size of k, the following figure shows the entire valid index address space.
4. Header Field Representation
An encoded header field can be represented as either an index or a literal.
An indexed representation defines a header field as a reference to an entry in either the static table or the dynamic table (see Section 6.1); a literal representation defines a header field by specifying its name and value. The header field name can be represented literally or as a reference to an entry in either the static table or the dynamic table. The header field value is represented literally. Three different literal representations are defined:
-
A literal representation that adds the header field to the beginning of the dynamic table as a new entry (see Section 6.2.1).
-
A literal representation that does not add the header field to the dynamic table (see Section 6.2.2).
-
A literal representation that does not add the header field to the dynamic table and additionally specifies that this header field is always to be represented literally, especially when re-encoded by an intermediary (see Section 6.2.3). This representation is intended to protect header field values that would otherwise be at risk after compression (for more details, see Section 7.1.3).
To protect sensitive header field values (see Section 7.1), one of these literal representations can be selected for security reasons.
The literal representation of a header field name or header field value can encode the octet sequence directly or by using the static Huffman code (see Section 5.2)
III. Decoding a Header Block
1. Header Block Processing
The decoder processes a header block sequentially to reconstruct the original header list.
A header block is the concatenation of header field representations. The different possible header field representations are described in Section 6.
Once a header field has been decoded and added to the reconstructed header list, it cannot be removed. Header fields added to the header list can be safely passed to the application.
By passing the resulting header fields to the application, a decoder can be implemented with minimal temporary memory beyond the memory required for the dynamic table.
2. Header Field Representation Processing
This section defines the process for handling a header block to obtain a header list. To ensure that decoding successfully produces a header list, the decoder MUST follow the rules below.
All header field representations contained in a header block are processed in the order in which they appear, as follows. For details on the formats of the various header field representations and some additional processing instructions, see Section 6.
_indexed representation_ requires the following action:
- The header field corresponding to the referenced entry in the static table or dynamic table is appended to the decoded header list.
A “_literal representation_” not added to the dynamic table requires the following action:
- The header field is appended to the decoded header list.
A “_literal representation_” added to the dynamic table requires the following actions:
- The header field is appended to the decoded header list.
- The header field is inserted at the beginning of the dynamic table. This insertion may cause previous entries in the dynamic table to be evicted (see Section 4.4).
IV. Dynamic Table Management
To limit storage requirements on the decoder side, the size of the dynamic table is bounded.
The dynamic dictionary is context-dependent, and a separate dictionary needs to be maintained for each HTTP/2 connection.
1. Calculating Table Size
The size of the dynamic table is the sum of the sizes of its entries. The size of an entry is the sum of the length of its name (in octets) (as defined in Section 5.2), the length of its value (in octets), and 32. The size of an entry is calculated using the lengths of its name and value, without applying any Huffman encoding.
Note: The additional 32 octets account for the estimated overhead associated with an entry. For example, an entry structure that uses two 64-bit pointers to reference the entry's name and value, and two 64-bit integers to count the number of references to that name and value, would have 32 octets of overhead. (64*2*2/8=32 bytes)
2. Maximum Table Size
The protocol using HPACK determines the maximum size that the encoder is allowed to use for the dynamic table. In HTTP/2, this value is determined by the SETTINGS_HEADER_TABLE_SIZE setting (see Section 6.5.2 of [HTTP2]).
The encoder can choose to use a capacity smaller than this maximum size (see Section 6.3), but the chosen size must remain less than or equal to the maximum capacity set by the protocol.
Changes to the maximum size of the dynamic table are caused by dynamic table size updates (see Section 6.3). A dynamic table size update MUST occur at the beginning of the first header block after the dynamic table size has changed. In HTTP/2, this follows acknowledgment of the settings (see Section 6.5.3 of [HTTP2]).
Multiple updates to the maximum table size can occur between the transmission of two header blocks. If the size changes more than once during this interval, then the smallest maximum table size that occurred in the interval MUST be signaled in a dynamic table size update. The final maximum size is always signaled as well, resulting in at most two dynamic table size updates. This ensures that the decoder can perform evictions based on decreases in the dynamic table size (see Section 4.3).
Using this mechanism, entries can be completely cleared from the dynamic table by setting the maximum size to 0, after which it can be restored.
HTTP/2 encourages using as few connections as possible. Header compression is an important reason for this: the more requests and responses generated on the same connection, the more complete the accumulated dynamic dictionary becomes, and the better the header compression ratio.
3. Entry Eviction When Dynamic Table Size Changes
Whenever the maximum size of the dynamic table is reduced, entries are evicted from the end of the dynamic table until the size of the dynamic table is less than or equal to the maximum size.
4. Entry Eviction When Adding New Entries
Before a new entry is added to the dynamic table, entries are evicted from the end of the dynamic table until the size of the dynamic table is less than or equal to (maximum size - new entry size), or until the table is empty.
If the size of the new entry is less than or equal to the maximum size, the entry is added to the table. Attempting to add an entry larger than the maximum size is not an error; attempting to add an entry larger than the maximum size causes the table to be emptied of all existing entries, leaving the table empty.
A new entry can reference the name of an entry A in the dynamic table, and entry A can be evicted when the new entry is added to the dynamic table. Note that if the referenced entry is removed from the dynamic table before the new entry is inserted, removing the referenced name should be avoided.
V. Primitive Type Representations
HPACK encoding uses two primitive types: unsigned variable-length integers and octet strings.
1. Integer Representation
Integers are used to represent name indexes, header field indexes, or string lengths. An integer representation can start at any position within an octet. To optimize processing, an integer representation always ends at the end of an octet.
An integer is represented in two parts: a prefix that fills the current octet, and an optional list of octets used if the integer value does not fit in that prefix. The number of bits in the prefix (called N) is a parameter of the integer representation.
If the integer value is small enough, that is, strictly less than 2^N-1, it is encoded in the N-bit prefix.
In the example above, N = 5, so the largest integer that can be represented is -1 = 31
If the integer value is greater than 2^N-1, all bits of the prefix are set to 1, and the value reduced by 2^N-1 is encoded using a list of one or more octets. The most significant bit of each octet is used as a continuation flag: it is set to 1 for every octet except the last one in the list. The remaining bits of the octets are used to encode the reduced value.
Decoding an integer value from the list of octets starts by reversing the order of the octets in the list. Then, for each octet, its most significant bit is removed. The remaining bits of the octets are concatenated, and the resulting value is increased by 2^N-1 to obtain the integer value.
The prefix size N is always between 1 and 8 bits. An integer that starts at an octet boundary has an 8-bit prefix.
The pseudocode for representing an integer I is as follows:
if I < 2^N - 1, encode I on N bits
else
encode (2^N - 1) on N bits
I = I - (2^N - 1)
while I >= 128
encode (I % 128 + 128) on 8 bits
I = I / 128
encode I on 8 bits
The pseudocode for decoding integer I is as follows:
decode I from the next N bits
if I < 2^N - 1, return I
else
M = 0
repeat
B = next octet
I = I + (B & 127) * 2^M
M = M + 7
while B & 128 == 128
return I
Appendix C.1 provides examples that illustrate integer encoding.
The integer representation allows values of indeterminate size. An encoder might also send a large number of zero values, which can waste octets and potentially cause the integer value to overflow. Integer encodings that exceed implementation limits (in value or octet length) MUST be treated as decoding errors. Depending on implementation constraints, different limits can be set for each distinct use of integers.
2. String Literal Representation
A header field name and header field value can be represented as string literals. A string literal can be encoded either by directly encoding the octets of the string literal or by using a Huffman code to encode the string literal as a sequence of octets (see [HUFFMAN]).
The string literal representation contains the following fields:
-
H:
A one-bit flag H indicating whether the octets of the string are Huffman encoded. -
String Length:
The number of octets used to encode the string literal, encoded as an integer with a 7-bit prefix (see Section 5.1). -
String Data: The encoded data of the string literal. If H is '0', the encoded data is the raw octets of the string literal. If H is '1', the encoded data is the Huffman encoding of the string literal.
A string literal using Huffman encoding is encoded with the Huffman code defined in Appendix B (for examples, see the examples in Appendix C.4 and the response examples in Appendix C.6). The encoded data is the bitwise concatenation of the codes corresponding to each octet of the string literal.
Because Huffman-encoded data does not always end on an octet boundary, padding is inserted after it up to the next octet boundary. To avoid this padding being misinterpreted as part of the string literal, the most significant bits of the code corresponding to the EOS (end-of-string) symbol are used.
During decoding, an incomplete code at the end of the encoded data is treated as padding and discarded. Padding strictly longer than 7 bits MUST be treated as a decoding error. Padding that does not correspond to the most significant bits of the EOS symbol's code MUST be treated as a decoding error. A Huffman-encoded string literal containing the EOS symbol MUST be treated as a decoding error.
VI. Binary Format
This section describes the detailed format of each different header field representation and the dynamic table size update instruction.
1. Indexed Header Field Representation
An indexed header field representation identifies an entry in the static table or dynamic table (see Section 2.3).
An indexed header field representation adds the header field to the decoded header list, as described in Section 3.2.
The case above corresponds to both Name and Value being in the indexing table (including the static table and the dynamic table).
An indexed header field starts with the 1-bit pattern “1”, followed by the index of the matching header field, represented as an integer with a 7-bit prefix (see Section 5.1).
The index value 0 is not used. If an index value of 0 is found in an indexed header field representation, it MUST be treated as a decoding error.
2. Literal Header Field Identification
A header field representation contains a literal header field value. The header field name is provided either literally or by referencing an existing table entry in the static table or dynamic table (see Section 2.3).
This specification defines three forms of literal header field representation: with indexing, without indexing, and never indexed.
(1). Literal Header Field with Incremental Indexing
A literal header field with an incremental indexing representation appends the header field to the decoded header list and inserts it into the dynamic table as a new entry.
The case above corresponds to Name being in the indexing table (including the static table and the dynamic table), while Value must be encoded and transmitted, and the field is also added to the dynamic table.
The case above corresponds to both Name and Value needing to be encoded and transmitted, and the field is also added to the dynamic table.
A literal header field with an incremental indexing representation starts with the 2-bit pattern “01”.
If the header field name matches the header field name of an entry stored in the static table or dynamic table, the index of that entry can be used to represent the header field name. In this case, the entry index is represented as an integer with a 6-bit prefix (see Section 5.1). This value is generally non-zero.
Otherwise, the header field name is represented as a string literal (see Section 5.2). The value 0 is used in place of the 6-bit index, followed by the header field name.
In both forms, the header field name representation is followed by the header field value represented as a string literal (see Section 5.2).
(2). Literal Header Field without Indexing
A literal header field without an indexing representation appends the header field to the decoded header list without modifying the dynamic table.
The case above corresponds to Name being in the indexing table (including the static table and the dynamic table), while Value must be encoded and transmitted, and the field is not added to the dynamic table.
The case above corresponds to both Name and Value needing to be encoded and transmitted, and the field is not added to the dynamic table.
A literal header field without an indexing representation starts with the 4-bit pattern “0000”.
If the header field name matches the header field name of an entry stored in the static table or dynamic table, the index of that entry can be used to represent the header field name. In this case, the entry index is represented as an integer with a 4-bit prefix (see Section 5.1). This value is generally non-zero.
Otherwise, the header field name is represented as a string literal (see Section 5.2). The value 0 is used in place of the 4-bit index, followed by the header field name.
In both forms, the header field name representation is followed by the header field value as a string literal (see Section 5.2).
(3). Literal Header Field Never Indexed
A literal header field never-indexed representation appends the header field to the decoded header list without modifying the dynamic table. Intermediaries MUST use the same representation to encode this header field.
The case above corresponds to Name being in the indexing table (including the static table and the dynamic table), while Value must be encoded and transmitted, and the field is never added to the dynamic table.
The case above corresponds to both Name and Value needing to be encoded and transmitted, and the field is never added to the dynamic table.
The literal header field never-indexed representation starts with the 4-bit pattern “0001”.
When a header field is represented as a literal header field never indexed, it is important to encode it using this specific literal representation. In particular, when a peer sends a received header field, and the received header is represented as a literal header field never indexed, it MUST forward that header field using the same representation.
This representation is intended to protect header field values by ensuring they are not put at risk through compression (for more details, see Section 7.1).
The encoding of this representation is the same as that of a literal header field without indexing (see Section 6.2.2).
3. Dynamic Table Size Update
A dynamic table size update represents a change to the dynamic table size.
A dynamic table size update starts with the 3-bit pattern “001”, followed by the new maximum size, represented as an integer with a 5-bit prefix (see Section 5.1).
The new maximum size MUST be less than or equal to the limit determined by the protocol using HPACK. A value exceeding this limit MUST be treated as a decoding error. In HTTP/2, this limit is the last value of the SETTINGS_HEADER_TABLE_SIZE parameter (see Section 6.5.2 of [HTTP2]) received from the decoder and acknowledged by the encoder (see Section 6.5.3 of [HTTP2]).
Reducing the maximum size of the dynamic table causes entries to be evicted (first in, first out) (see Section 4.3).
There are two ways to update the dynamic table size as described above: one is to modify it directly in the HEADERS frame (starting with the 3-bit pattern “001”), and the other is to set it via SETTINGS_HEADER_TABLE_SIZE in the SETTINGS frame.
VII. Security Considerations
This section describes the potential security risks of HPACK:
-
Using compression as a length-based oracle to validate guesses about encrypted data compressed into a shared compression context.
-
Denial of service caused by exhausting the decoder's processing or storage capacity.
1. Probing Dynamic Table State
HPACK reduces the length of header field encodings by exploiting redundancy inherent in protocols such as HTTP. The ultimate goal is to reduce the amount of data required to send HTTP requests or responses.
An attacker can probe the compression context used to encode header fields. The attacker can also define header fields to be encoded and transmitted, and observe the lengths of those fields after encoding. When an attacker can do both, they can adaptively modify requests to confirm guesses about the state of the dynamic table. If a guess compresses to a shorter length, the attacker can observe the encoded length and infer that the guess was correct.
This attack is possible even when Transport Layer Security (TLS) is used (see [TLS12]), because TLS provides cryptographic protection for content but only limited protection for content length.
Note: Padding schemes can provide only limited protection against attackers with these capabilities; their effect may merely be to force the attacker to increase the number of guesses needed to infer the length associated with a given guess. Padding schemes can also directly counter compression by increasing the number of bits transmitted.
Attacks such as CRIME [CRIME] demonstrate that such attackers exist. That specific attack exploits the fact that DEFLATE [DEFLATE] removes redundancy based on prefix matching. This allows an attacker to determine one character at a time, reducing an exponential-time attack to a linear-time attack.
(1). Applicability to HPACK and HTTP
HPACK mitigates, but does not completely prevent, attacks modeled on CRIME [CRIME] by forcing guesses to match an entire header field value rather than a single character. An attacker can only learn whether a guess is correct, reducing the attack to brute-force guessing of header field values. Therefore, the feasibility of recovering a specific header field value depends on the entropy of the value. As a result, high-entropy values are unlikely to be recovered successfully. However, low-entropy values remain vulnerable.
An attack of this nature can occur whenever two mutually distrustful entities receive and send requests or responses over a single HTTP/2 connection. If a shared HPACK compressor allows one entity to add entries to the dynamic table and another entity to access those entries, the state of the table can be learned.
Requests or responses from mutually distrustful entities arise when an intermediary does any of the following:
-
Sends requests from multiple clients over a single connection to an origin server.
-
Fetches responses from multiple origin servers and sends those responses over a shared connection to a client.
Web browsers also need to assume that requests made on the same connection from different web origins [ORIGIN] are issued by mutually distrustful entities.
(2). Mitigation
HTTP users that require header fields to be confidential can use values with enough entropy to make guessing infeasible. However, this is impractical as a general solution, because it would force all users of HTTP to take steps to mitigate the attack. It would impose new constraints on how HTTP is used.
Rather than imposing constraints on HTTP users, HPACK implementations can constrain how compression is applied to limit the potential for probing the dynamic table.
The ideal solution is to isolate access to the dynamic table based on the entity that constructs the header field. A header field value added to the table is attributed to an entity, and only the entity that created a specific value can retrieve that value.
To improve the compression performance of this option, some entries can be marked as public. For example, a web browser might make the value of the Accept-Encoding header field available across all requests.
An encoder that has limited knowledge of the origin of header fields might introduce a penalty mechanism for header fields with many different values. If an attacker makes many attempts to guess a header field value and triggers the penalty mechanism, the header field will no longer be compared against dynamic table entries in future messages. This effectively prevents further guessing.
Note: If the attacker has a reliable way to reinstall the value, simply removing the entry corresponding to the header field from the dynamic table might not be an effective defense. For example, requests for images loaded in a web browser usually include the Cookie header field (a potentially high-value target for this kind of attack), and a website can easily force images to be loaded, thereby refreshing the entry in the dynamic table.
The penalty can be made inversely proportional to the length of the header field value. Compared with longer values, shorter values are more likely to cause the header field to be marked as no longer using the dynamic table, or to do so at a faster rate.
(3). Never-Indexed Literals
Implementers can also choose not to compress sensitive header fields, and instead encode their values as literals, thereby protecting them.
Refusing to generate an indexed representation of a header field is effective only if compression is avoided on all hops. The never-indexed literal (see Section 6.2.3) can be used to signal to intermediaries that a specific value is intentionally sent as a literal.
Intermediaries must not re-encode a value represented using a never-indexed literal into another representation that would index it. If HPACK is used for re-encoding, the never-indexed literal representation must be used.
The choice to use the never-indexed literal representation for a header field depends on several factors. Because HPACK cannot prevent guessing an entire header field value, it is easier for an attacker to recover short or low-entropy values. Therefore, an encoder might choose not to index values with low entropy.
An encoder might also choose not to add indexes for values of header fields that are considered high-value or sensitive to recovery, such as the Cookie or Authorization header fields.
Conversely, if a value is public, the encoder might prefer to index header fields whose indexed value is small or negligible. For example, the User-Agent header field usually does not change between requests and is sent to any server. In this case, confirming that a specific User-Agent value has been used provides little value.
Note that, as new attacks continue to be discovered, the criteria for deciding to use the never-indexed literal representation will evolve over time.
2. Static Huffman Encoding
There are currently no known attacks against static Huffman encoding. One study shows that using a static Huffman encoding table can cause information leakage; however, the same study concludes that an attacker cannot exploit this leakage to recover any meaningful amount of information (see [PETAL]).
Dynamic Huffman encoding is vulnerable to attack!
3. Memory Management
An attacker can attempt to exhaust an endpoint’s memory. HPACK is designed to limit the peak amount of memory allocated by an endpoint and the amount of state it maintains.
The amount of memory used by the compressor is limited by the maximum size defined for the dynamic table under the HPACK protocol. In HTTP/2, this value is controlled by the decoder through the SETTINGS_HEADER_TABLE_SIZE setting parameter (see Section 6.5.2 of [HTTP2]). This limit accounts for both the size of the data stored in the dynamic table and a small amount of overhead.
A decoder can limit the use of memory for state by setting an appropriate value for the maximum size of the dynamic table. In HTTP/2, this is done by setting an appropriate value for the SETTINGS_HEADER_TABLE_SIZE parameter. An encoder can limit the amount of state memory it uses by signaling a dynamic table size smaller than the state allowed by the decoder (see Section 6.3).
The amount of temporary memory consumed by an encoder or decoder can be limited by processing header fields sequentially. Implementers do not need to retain the complete list of header fields. Note, however, that for other reasons an application might need to retain the complete header list. Even though HPACK does not force this situation, application constraints might make it necessary.
4. Implementation Limits
HPACK implementers need to ensure that large integer values, long encodings of integers, or long string literals do not create security vulnerabilities.
An implementation must set limits on the integer values and encoding lengths it accepts (see Section 5.1). Similarly, it must set a length limit for string literals (see Section 5.2).
Reference：
GitHub Repo: Halfrost-Field
Follow: halfrost · GitHub
