PICOKIT-02 TRAFFIC LIGHT
Traffic Light Phases and Authenticated Heartbeat
Lesson 2 of the Picokit Series
LEGAL DISCLAIMER: The information, tools, and code provided in this repository and course are strictly for educational, research, and defensive purposes only.
You are explicitly prohibited from using any materials contained herein to access, test, modify, or exploit any device, network, or system that you do not own 100% or for which you do not have explicit, documented, and legally binding authorization to interact with.
By using this repository and course, you acknowledge and agree that:
- Any illegal, unauthorized, or malicious use of this information is solely your responsibility.
- The author(s) and contributor(s) of this repository and course shall not be held liable for any damages, legal repercussions, criminal charges, or unauthorized actions resulting from the use, misuse, or abuse of the contents herein.
- You will comply with all applicable local, state, national, and international laws regarding cybersecurity and computer fraud.
IF YOU DO NOT AGREE WITH THESE TERMS, DO NOT USE THIS REPOSITORY AND COURSE.
Overview
The second Picokit lesson. The node runs a real traffic light sequence on the red, green, and yellow lamps, holding red for three seconds, green for three seconds, and yellow for one second, and it blinks the onboard LED once per phase. Every five seconds it transmits an authenticated heartbeat over LoRa to a Python gateway that logs and displays it. It reuses the standard node shape introduced in lesson one and adds a multi-duration phase state machine.
What it teaches
- A multi-duration phase state machine: red 3 s, green 3 s, yellow 1 s.
- Reading the elapsed phase from a monotonic clock and scheduling the next transition.
- Sealing a tiny JSON body with Argon2id and XChaCha20-Poly1305 and sending it with an AT+SEND over the RYLR998.
- The gateway side: receive, authenticate, reject, log, and display.
Hardware
| Peripheral | Pico 2 pin | Role |
|---|---|---|
| Red / Yellow / Green | GP16 / GP17 / GP18 | the signal |
| Onboard LED | GP25 | heartbeat, one blink per phase |
| RYLR998 | GP8 TX / GP9 RX | LoRa heartbeat |
| Debug Probe | SWCLK/SWDIO/GND, GP0/GP1 | SWD and the console |
How it works
The node runs monitor_step in a loop. It enters the red phase, then green,
then yellow, holding each lamp for its own duration and blinking GP25 once per
phase, and every 5 seconds it seals {"n":2,"s":<seq>,"p":<phase>} with the
field key and sends it over LoRa. The gateway authenticates each frame and
only then parses it.
Build and flash
cd firmware
cmake -S . -B build -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s
cmake --build build
openocd -f interface/cmsis-dap.cfg -f target/rp2350.cfg \
-c "program build/picokit_02_traffic_light.elf verify reset exit"
Watch the node
Open the console at 115200 and reset:
BOOT
I2C scan:
no devices
=== PICOKIT-02 TRAFFIC LIGHT // PHASES + AUTHENTICATED HEARTBEAT ===
PHASE 0 RED seq=0
PHASE 1 GREEN seq=0
PHASE 2 YELLOW seq=0
RX from 0x0001, N bytes
The gateway
cd gateway
python3 -m venv .venv && source .venv/bin/activate
pip install -r requirements.txt
python3 listen.py --port /dev/cu.usbserial-A50285BI --hub 0001 --network 18 --db gateway.db
It prints OK node=2 rssi=... per authenticated heartbeat. The terminal
dashboard python3 tui.py --db gateway.db and the web dashboard
python3 web/app.py --db gateway.db show the same rows.
Verify
python3 .opencode/skill/embedded-c-standard/audit_c_standard.py
python3 .opencode/skill/embedded-python-standard/audit_python_standard.py
python3 .opencode/skill/iot-readme-standard/validate_readme.py
python3 .opencode/skill/iot-banner-standard/validate_banner.py
python3 scripts/run_tests.py
python3 scripts/check_coverage.py
