PICOKIT-23 LORA COMMAND
Remote Command LEDs and Authenticated Heartbeat
Lesson 23 of the Picokit Series
LEGAL DISCLAIMER: The information, tools, and code provided in this repository and course are strictly for educational, research, and defensive purposes only.
You are explicitly prohibited from using any materials contained herein to access, test, modify, or exploit any device, network, or system that you do not own 100% or for which you do not have explicit, documented, and legally binding authorization to interact with.
By using this repository and course, you acknowledge and agree that:
- Any illegal, unauthorized, or malicious use of this information is solely your responsibility.
- The author(s) and contributor(s) of this repository and course shall not be held liable for any damages, legal repercussions, criminal charges, or unauthorized actions resulting from the use, misuse, or abuse of the contents herein.
- You will comply with all applicable local, state, national, and international laws regarding cybersecurity and computer fraud.
IF YOU DO NOT AGREE WITH THESE TERMS, DO NOT USE THIS REPOSITORY AND COURSE.
Overview
The twenty third Picokit lesson. The Python gateway sends a command over LoRa, the node acts on it and reflects the selection on the status LEDs, and the node reports the last command in its authenticated heartbeat. It is the first lesson that turns the downlink into an action.
What it teaches
- Receiving and parsing a downlink command over LoRa.
- Acting on the command by selecting a status LED.
- Reporting the last applied command in the authenticated heartbeat.
- Sealing the JSON body with Argon2id and XChaCha20-Poly1305 and sending it with an AT+SEND over the RYLR998.
Hardware
| Peripheral | Pico 2 pin | Role |
|---|---|---|
| Onboard LED | GP25 | heartbeat, one blink per transmit |
| Red LED | GP16 | command 0 |
| Yellow LED | GP17 | command 1 |
| Green LED | GP18 | command 2 |
| RYLR998 | GP8 TX / GP9 RX | command downlink and heartbeat uplink |
| Debug Probe | SWCLK/SWDIO/GND, GP0/GP1 | SWD and the console |
How it works
The node runs monitor_step in a loop. Every 5 seconds it seals
{"n":23,"s":<seq>,"c":<cmd>} with the field key and sends the heartbeat
over LoRa. When the gateway sends CMD <n>, the node logs it, lights the
matching status LED, and carries the command value in its next heartbeat.
The gateway authenticates each frame and only then parses it.
Build and flash
cd firmware
cmake -S . -B build -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s
cmake --build build
openocd -f interface/cmsis-dap.cfg -f target/rp2350.cfg \
-c "program build/picokit_23_lora_command.elf verify reset exit"
Watch the node
Open the console at 115200 and reset:
BOOT
=== PICOKIT-23 LORA COMMAND // REMOTE COMMAND LEDS + AUTHENTICATED HEARTBEAT ===
RX from 0x0001, 5 bytes
CMD 2
The gateway
cd gateway
python3 -m venv .venv && source .venv/bin/activate
pip install -r requirements.txt
python3 listen.py --port /dev/cu.usbserial-A50285BI --hub 0001 --network 18 --db gateway.db
Send a command with python3 cli.py send --port /dev/cu.usbserial-A50285BI --node 23 --command 2. The terminal dashboard python3 tui.py --db gateway.db and the web dashboard python3 web/app.py --db gateway.db show
the same rows.
Verify
python3 .opencode/skill/embedded-c-standard/audit_c_standard.py
python3 .opencode/skill/embedded-python-standard/audit_python_standard.py
python3 .opencode/skill/iot-readme-standard/validate_readme.py
python3 .opencode/skill/iot-banner-standard/validate_banner.py
python3 scripts/run_tests.py
python3 scripts/check_coverage.py
