HTTP Semantics in HTTP/2
HTTP/2 was designed from the outset to be as compatible as possible with the HTTP in current use. This means that, from an application’s perspective, the protocol’s functionality is largely unchanged. To achieve this, all request and response semantics are preserved, although the syntax used to convey those semantics has changed.
Therefore, the specifications and requirements for semantics and content [RFC7231], conditional requests [RFC7232], range requests [RFC7233], caching [RFC7234], and authentication [RFC7235] in HTTP/1.1 apply equally to HTTP/2. Selected portions of HTTP/1.1 message syntax and routing [RFC7230], such as the HTTP and HTTPS URI schemes, also apply to HTTP/2, but the semantic expression for this protocol is defined below.
I. HTTP Request/Response Exchange
A client sends an HTTP request on a new stream using a previously unused stream identifier (Section 5.1.1). The server sends the HTTP response on the same stream as the request.
An HTTP message (request or response) consists of:
- For responses only, zero or more HEADERS frames (each followed by zero or more CONTINUATION frames) containing the header fields of informational (1xx) HTTP responses (see [RFC7230] Section 3.2 and [RFC7231] Section 6.2),
- One HEADERS frame containing the header fields (followed by zero or more CONTINUATION frames) (see [RFC7230] Section 3.2)
- Zero or more DATA frames containing the payload body (see [RFC7230] Section 3.3)
- Optionally, one HEADERS frame followed by zero or more CONTINUATION frames containing the trailer-part, if present (see [RFC7230] Section 4.1.2).
The last frame in the sequence carries the END_STREAM flag. Note that a HEADERS frame carrying the END_STREAM flag can be followed by CONTINUATION frames containing any remaining portion of the header block. Other frames (from any stream) MUST NOT appear between a HEADERS frame and any CONTINUATION frames that might follow it.
HTTP/2 uses DATA frames to carry message payloads. The "chunked" transfer coding defined in [RFC7230] Section 4.1 is prohibited in HTTP/2.
Trailing header fields are carried in a header block that also terminates the stream. Such a header block is a sequence that starts with a HEADERS frame, followed by zero or more CONTINUATION frames, where the HEADERS frame carries the END_STREAM flag. The first header block that does not terminate the stream is not part of an HTTP request or response.
HEADERS frames (and associated CONTINUATION frames) can appear only at the beginning or end of a stream. After receiving a final (non-informational) status code, an endpoint that receives a HEADERS frame without the END_STREAM flag set MUST treat the corresponding request or response as malformed (Section 8.1.2.6).
An HTTP request/response exchange fully consumes a single stream. A request begins with a HEADERS frame, which places the stream in the "open" state. The request ends with a frame carrying END_STREAM, which makes the stream "half-closed (local)" for the client and "half-closed (remote)" for the server. A response begins with a HEADERS frame and ends with a frame carrying END_STREAM, which transitions the stream to the "closed" state.
An HTTP response is complete after the server sends, or the client receives, a frame with the END_STREAM flag set (including any CONTINUATION frames needed to complete the header block). If the response does not depend on any part of the request that has not yet been sent and received, the server can send a complete response before the client has sent the entire request. In that case, after sending a complete response (for example, a frame with the END_STREAM flag), the server MAY request that the client abort transmission of the request without error by sending an RST_STREAM with the NO_ERROR error code. The client MUST NOT discard the response because it receives such an RST_STREAM, though the client may decide to discard the response for other reasons.
1. Upgrading from HTTP/2
HTTP/2 removes support for the 101 (Switching Protocols) informational status code ([RFC7231], Section 6.2.2). The semantics of 101 (Switching Protocols) do not apply to a multiplexed protocol. Alternative protocols can use the same mechanism as HTTP/2 to negotiate their use (see Section 3).
2. HTTP Header Fields
HTTP header fields carry information as a sequence of key-value pairs. For a list of registered HTTP headers, see the "Message Header Fields" registry maintained at https://www.iana.org/assignments/message-headers. As in HTTP/1.x, header field names are ASCII strings and are compared in a case-insensitive manner. However, before HTTP/2 encoding, header field names MUST be converted to lowercase. A request or response containing uppercase header field names MUST be treated as malformed (Section 8.1.2.6).
(1) Pseudo-Header Fields
Whereas HTTP/1.x uses a message start-line (see [RFC7230], Section 3.1) to convey the target URI, request method, and response status code, HTTP/2 uses special pseudo-header fields whose names begin with the ':' character (ASCII 0x3a) for the same purpose. Pseudo-header fields are not HTTP header fields. An endpoint MUST NOT generate pseudo-header fields that are not defined in this document.
Pseudo-header fields are valid only in the contexts in which they are defined. Pseudo-header fields defined for requests MUST NOT appear in responses; pseudo-header fields defined for responses MUST NOT appear in requests. Pseudo-header fields MUST NOT appear in trailers. An endpoint MUST treat a request or response containing an undefined or invalid pseudo-header field as malformed (Section 8.1.2.6).
All pseudo-header fields MUST appear in the header block before regular header fields. Any request or response that contains a pseudo-header field in a header block after a regular header field MUST be treated as malformed (Section 8.1.2.6).
(2) Connection-Specific Header Fields
HTTP/2 does not use the Connection header field to identify connection-specific header fields. In this protocol, connection-specific metadata is conveyed by other means. An endpoint is prohibited from generating a message containing connection-specific header fields. Any message containing connection-specific header fields MUST be treated as malformed (Section 8.1.2.6).
The sole exception is the TE header field, which may appear in HTTP/2 requests. It MUST NOT contain any value other than trailers. This means that an intermediary translating an HTTP/1.x message to HTTP/2 needs to remove any header fields mentioned by the Connection header field, as well as the Connection header field itself. Such intermediaries should also remove other connection-specific header fields, such as Keep-Alive, Proxy-Connection, Transfer-Encoding, and Upgrade, even if they are not named by the Connection header field.
Note: HTTP/2 intentionally does not support upgrading to another protocol. The handshake methods described in Section 3 are considered sufficient for negotiating alternative protocols.
(3) Request Pseudo-Header Fields
The following pseudo-header fields are defined for HTTP/2 requests:
- The ":method" pseudo-header field contains the HTTP method ([RFC7231], Section 4).
- The ":scheme" pseudo-header field contains the scheme portion of the target URI ([RFC3986], Section 3.1). The ":scheme" pseudo-header field is not limited to URIs with the "http" and "https" schemes. A proxy or gateway can translate requests for non-HTTP schemes, allowing HTTP to interact with non-HTTP services.
- The ":authority" pseudo-header field contains the authority portion of the target URI ([RFC3986], Section 3.2). The authority MUST NOT include the deprecated "userinfo" subcomponent for "http" or "https" scheme URIs. To ensure the HTTP/1.1 request line can be reproduced accurately, this pseudo-header field MUST be omitted when translating from an HTTP/1.1 request whose request target is in origin-form or asterisk-form (see [RFC7230], Section 5.3). Clients that generate HTTP/2 requests directly SHOULD use the ":authority" pseudo-header field instead of the Host header field. An intermediary that translates an HTTP/2 request to HTTP/1.1 MUST create a Host header field by copying the value of the ":authority" pseudo-header field if the request does not already contain one.
- The ":path" pseudo-header field contains the path and query portions of the target URI: the absolute path and, optionally, the '?' character followed by the query (see [RFC3986] Sections 3.3 and 3.4). A request in asterisk-form includes the value '*' for the ":path" pseudo-header field. For "http" or "https" URIs, this pseudo-header field MUST NOT be empty; an "http" or "https" URI that does not contain a path component MUST include the value "/". The exception to this rule is an OPTIONS request for an "http" or "https" URI that does not contain a path component; it MUST include a ":path" pseudo-header field with the value '*' (see [RFC7230], Section 5.3.4).
Except for CONNECT requests, all HTTP/2 requests MUST include valid values for the ":method", ":scheme", and ":path" pseudo-header fields (Section 8.3). An HTTP request that omits a mandatory pseudo-header field is malformed (Section 8.1.2.6). HTTP/2 does not define a way to carry the version identifier included in an HTTP/1.1 request line.
(4) Response Pseudo-Header Fields
For HTTP/2 responses, the ":status" pseudo-header field is defined to carry the HTTP status code field (see [RFC7231], Section 6). This pseudo-header field MUST be included in all responses; otherwise, the response is malformed (Section 8.1.2.6). HTTP/2 does not define a way to carry the version or reason phrase included in an HTTP/1.1 status line.
(5) Compressing the Cookie Header Field
The Cookie header field [COOKIE] uses a semicolon (";") to delimit cookie pairs (or "crumbs"). This header field does not follow the list construction rules in HTTP (see [RFC7230], Section 3.2.2), which prevents cookie pairs from being split into separate name-value pairs. This can significantly reduce compression efficiency, because only a single cookie pair might be updated.
To improve compression efficiency, the Cookie header field can be split into separate header fields, each containing one or more cookie pairs. If multiple Cookie header fields are present after decompression, they MUST be concatenated into a single octet string using the two-octet delimiter 0x3B, 0x20 (the ASCII string "; ") before being passed into a non-HTTP/2 context, such as an HTTP/1.1 connection or a generic HTTP server application.
Therefore, the following two lists of Cookie header fields are semantically equivalent.
cookie: a = b;c = d;e = f
cookie: a = b
cookie: c = d
cookie: e = f
(6) Malformed Requests and Responses
A malformed request or response is an otherwise valid sequence of HTTP/2 frames that is invalid because it contains extraneous frames, prohibited header fields, omits required header fields, or includes uppercase header field names.
A request or response that includes a payload body can include a Content-Length header field. If the value of the Content-Length header field is not equal to the sum of the payload lengths of the DATA frames that form the body, the request or response is also considered malformed. As described in [RFC7230] Section 3.3.2, a response defined to have no payload can have a non-zero Content-Length header field even if no content is included in DATA frames.
An intermediary that processes HTTP requests or responses (that is, any intermediary not acting as a tunnel) MUST NOT forward malformed requests or responses. A detected malformed request or response MUST be treated as a stream error of type PROTOCOL_ERROR (Section 5.4.2). For a malformed request, a server MAY send an HTTP response before closing or resetting the stream. A client MUST NOT accept a malformed response. Note that these requirements are intended to prevent several common classes of attacks against HTTP; they are deliberately strict because leniency can create vulnerabilities.
3. Examples
This section shows HTTP/1.1 requests and responses and provides descriptions of the equivalent HTTP/2 requests and responses. An HTTP GET request includes header fields but no payload body, so it is sent as a single HEADERS frame followed by zero or more CONTINUATION frames containing the serialized header field block. The HEADERS frame below sets both the END_HEADERS and END_STREAM flags; no CONTINUATION frames are sent.
GET /resource HTTP/1.1 HEADERS
Host: example.org ==> + END_STREAM
Accept: image/jpeg + END_HEADERS
:method = GET
:scheme = https
:path = /resource
host = example.org
accept = image/jpeg
Similarly, a response that contains only response header fields is sent as a HEADERS frame (again, followed by zero or more CONTINUATION frames), which contains the serialized response header field block.
HTTP/1.1 304 Not Modified HEADERS
ETag: "xyzzy" ==> + END_STREAM
Expires: Thu, 23 Jan ... + END_HEADERS
:status = 304
etag = "xyzzy"
expires = Thu, 23 Jan ...
An HTTP POST request containing request header fields and payload data is sent as a HEADERS frame, followed by zero or more CONTINUATION frames containing request header fields, followed by one or more DATA frames, with the last CONTINUATION (or HEADERS) frame setting the END_HEADERS flag and the final DATA frame setting the END_STREAM flag.
POST /resource HTTP/1.1 HEADERS
Host: example.org ==> - END_STREAM
Content-Type: image/jpeg - END_HEADERS
Content-Length: 123 :method = POST
:path = /resource
{binary data} :scheme = https
CONTINUATION
+ END_HEADERS
content-type = image/jpeg
host = example.org
content-length = 123
DATA
+ END_STREAM
{binary data}
Note that the data contributing to any given header field can be spread across header block fragments. The assignment of header fields to frames in this example is purely illustrative.
A response containing header fields and payload data is sent as a HEADERS frame, followed by zero or more CONTINUATION frames, followed by one or more DATA frames, with the last DATA frame in the sequence setting the END_STREAM flag.
HTTP/1.1 200 OK HEADERS
Content-Type: image/jpeg ==> - END_STREAM
Content-Length: 123 + END_HEADERS
:status = 200
{binary data} content-type = image/jpeg
content-length = 123
DATA
+ END_STREAM
{binary data}
Informational responses that use 1xx status codes other than 101 are sent as a HEADERS frame, followed by zero or more CONTINUATION frames.
After the request or response header block and all DATA frames have been sent, trailing header fields are sent as a header block. The HEADERS frame that begins the trailers header block has the END_STREAM flag set. The following example includes the 100 (Continue) status code, which is sent in response to a request that includes the “100-continue” token in the Expect header field, as well as trailing header fields.
HTTP/1.1 100 Continue HEADERS
Extension-Field: bar ==> - END_STREAM
+ END_HEADERS
:status = 100
extension-field = bar
HTTP/1.1 200 OK HEADERS
Content-Type: image/jpeg ==> - END_STREAM
Transfer-Encoding: chunked + END_HEADERS
Trailer: Foo :status = 200
content-length = 123
123 content-type = image/jpeg
{binary data} trailer = Foo
0
Foo: bar DATA
- END_STREAM
{binary data}
HEADERS
+ END_STREAM
+ END_HEADERS
foo = bar
4. Request Reliability Mechanisms in HTTP/2
In HTTP/1.1, an HTTP client cannot retry a non-idempotent request when an error occurs, because it cannot determine the nature of the error. Some server-side processing might have occurred before the error, and retrying the request could cause undesirable effects.
HTTP/2 provides two mechanisms that give clients assurance that a request has not been processed:
- A GOAWAY frame indicates the highest stream number that might have been processed. Therefore, requests on streams with higher numbers are guaranteed to be safe to retry.
- The REFUSED_STREAM error code can be included in an RST_STREAM frame to indicate that the stream is being closed before any processing has occurred. Any retry request sent on the reset stream can be safely sent again.
Unprocessed requests have not failed; clients can automatically retry them, even those with non-idempotent methods. A server cannot indicate that a stream has not been processed unless it can guarantee that fact. If frames on a stream have been delivered to the application layer for any stream, REFUSED_STREAM cannot be used for that stream, and the GOAWAY frame must include a stream identifier greater than or equal to the given stream identifier.
In addition to these mechanisms, the PING frame gives clients an easy way to test a connection. Because some intermediaries (for example, network address translators or load balancers) silently discard connection bindings, idle connections can be broken. The PING frame allows a client to safely test whether the connection is still alive without sending a request.
2. Server Push
HTTP/2 allows a server to preemptively send (or “push”) responses (along with the corresponding “promised” requests) to a client for requests associated with an earlier client-initiated request. Server Push can be useful when the server knows that the client will need those responses in order to fully process the response to the original request.
After the client receives a PUSH_PROMISE frame, it can choose to reject the stream based on its own circumstances (via an RST_STREAM frame). (For example, this might happen if the resource is already in the cache.) This is a significant improvement over HTTP/1.x. By contrast, resource inlining (a popular HTTP/1.x “optimization”) is equivalent to “forced push”: the client cannot choose to reject, cancel, or separately process the inlined resource.
A client can indicate that server push is disabled when making a request, although this is negotiated independently on each hop. The SETTINGS_ENABLE_PUSH setting can be set to 0 to indicate that server push is disabled.
Promised requests must be cacheable (see [RFC7231], Section 4.2.3), must be safe (see [RFC7231], Section 4.2.1), and must not include a request body. A client that receives a promised request that is not cacheable, is unsafe, or indicates the presence of a request body must reset the promised stream with a stream error of type PROTOCOL_ERROR (Section 5.4.2). Note that if the client cannot determine whether a newly defined method is safe, this can result in the promised stream being reset.
If the client implements an HTTP cache, cacheable pushed responses can be cached (see [RFC7234], Section 3). While the stream identified by the promised stream ID remains open, pushed responses can be successfully validated against the origin server (for example, if a “no-cache” cache response directive is present ([RFC7234], Section 5.2.2)). Non-cacheable pushed responses must not be stored by any HTTP cache. They can be provided directly to the application.
If the server is authoritative, it needs to include a value in the ":authority" pseudo-header field (see Section 10.1). A client must treat a PUSH_PROMISE from a server that is not authoritative as a stream error of type PROTOCOL_ERROR (Section 5.4.2).
An intermediary can receive pushes from a server and choose not to forward them to the client. In other words, how the pushed information is used is up to that intermediary. Similarly, an intermediary might choose to perform additional pushes to the client without taking any action on the server.
Clients cannot push. Therefore, a server must treat receipt of a PUSH_PROMISE frame as a connection error of type PROTOCOL_ERROR (Section 5.4.1). A client must reject any attempt to change the SETTINGS_ENABLE_PUSH setting to a value other than 0; if it encounters this, it can treat the message that changes the setting as a connection error of type PROTOCOL_ERROR (Section 5.4.1).
1. Push Requests
Server push is semantically equivalent to a server responding to a request; however, in this case the request is also sent by the server, as a PUSH_PROMISE frame.
The PUSH_PROMISE frame includes a header block containing the complete set of request header fields defined by the server for the request. A response cannot be pushed for a request that contains a request body.
A pushed response is always associated with an explicit request from the client. The PUSH_PROMISE frame sent by the server is sent on the stream for that explicit request. The PUSH_PROMISE frame also includes a promised stream identifier, which is selected from the stream identifiers available to the server (see Section 5.1.1).
The header fields in the PUSH_PROMISE and any subsequent CONTINUATION frames must form a valid and complete set of request header fields (Section 8.1.2.3). The server must include a safe and cacheable method in the “:method” pseudo-header field. If the client receives a PUSH_PROMISE that does not contain a complete and valid set of header fields, or if the “:method” pseudo-header field identifies an unsafe method, it must respond with a stream error of type PROTOCOL_ERROR (Section 5.4.2).
The server should send the PUSH_PROMISE frame before sending any frames that reference the promised response (Section 6.6). Doing so avoids a race in which the client issues a request before receiving any PUSH_PROMISE frame.
For example, if the server receives a request for a document that contains embedded links to multiple image files, and the server chooses to push those additional images to the client, sending the PUSH_PROMISE frames before the DATA frames that contain the image links ensures that the client can see the pushed resources before it discovers the embedded links. Similarly, if the server pushes responses referenced by a header block (for example, in a Link header field), sending the PUSH_PROMISE before the header block ensures that the client does not request those resources.
PUSH_PROMISE frames must not be sent by clients.
PUSH_PROMISE frames can be sent by a server in response to any client-initiated stream, but the stream must be in the "open" or "half-closed (remote)" state from the server’s perspective. PUSH_PROMISE frames are interleaved with frames that contain the response, although they cannot be interleaved between HEADERS and CONTINUATION frames that contain a single header block.
Sending a PUSH_PROMISE frame creates a new stream and places that stream in the server’s "reserved (local)" state and the client’s "reserved (remote)" state.
2. Push Responses
After sending a PUSH_PROMISE frame, the server can begin sending the pushed response as a response (Section 8.1.2.4) on the server-initiated stream that uses the promised stream identifier. The server uses this stream to transmit the HTTP response, using the same sequence of frames defined in Section 8.1. After sending the initial HEADERS frame, the stream becomes "half-closed" from the client’s perspective (Section 5.1). Once the client receives the PUSH_PROMISE frame and chooses to accept the pushed response, the client should not issue any request for the promised response before the promised stream is closed.
If the client determines for some specific reason that it does not want to receive the pushed response from the server, or if the server takes too long to begin sending the promised response, the client can send an RST_STREAM frame using the CANCEL or REFUSED_STREAM code and referencing the identifier of the pushed stream.
A client can use the SETTINGS_MAX_CONCURRENT_STREAMS setting to limit the number of responses the server pushes concurrently. To prevent the server from creating the necessary streams, the SETTINGS_MAX_CONCURRENT_STREAMS value can be set to zero to disable server push. This does not prohibit the server from sending PUSH_PROMISE frames; the client needs to reset any unwanted promised streams.
A client receiving a pushed response must verify that the server is authoritative (see Section 10.1), or that the corresponding request is handled by a proxy capable of providing the pushed response. For example, a server with only a "example.com" DNS-ID or Common Name certificate is not allowed to push a response for "https://www.example.org/doc".
The response on a PUSH_PROMISE stream begins with a HEADERS frame, which immediately places the stream in the server’s "half-closed (remote)" state and the client’s "half-closed (local)" state, and ends with a frame carrying END_STREAM, which places the stream in the "closed" state.
Note: A client never sends a frame with the END_STREAM flag for server push.
3. The CONNECT Method
In HTTP/1.x, the pseudo-method CONNECT ([RFC7231], Section 4.3.6) is used to convert an HTTP connection into a tunnel to a remote host. CONNECT is primarily used with HTTP proxies to establish a TLS session with an origin server in order to interact with "https" resources.
In HTTP/2, the CONNECT method can be used to establish a tunnel to a remote host over a single HTTP/2 stream, serving a purpose similar to that in HTTP/1.x. The mapping of HTTP header fields is defined in Section 8.1.2.3 (“Request Pseudo-Header Fields”), with a few differences. In particular:
- The ":method" pseudo-header field is set to "CONNECT".
- The ":scheme" and ":path" pseudo-header fields must be omitted.
- The ":authority" pseudo-header field contains the host and port of the host to connect to (equivalent to the authority form of the request-target of a CONNECT request see [RFC7230], Section 5.3).
A CONNECT request that does not conform to the above restrictions is malformed (Section 8.1.2.6). A proxy that supports CONNECT establishes a TCP connection [TCP] to the server identified in the ":authority" pseudo-header field. Once the connection is successfully established, the proxy sends a HEADERS frame containing a 2xx series status code to the client, as defined in [RFC7231], Section 4.3.6.
After each peer has sent its initial HEADERS frame, all subsequent DATA frames correspond to data sent on the TCP connection. The payload of any DATA frame sent by the client is forwarded by the proxy to the TCP server; data received from the TCP server is assembled by the proxy into DATA frames. Frame types other than DATA or stream-management frames (RST_STREAM, WINDOW_UPDATE, and PRIORITY) must not be sent on the connected stream, and if received must be treated as a stream error (Section 5.4.2).
Either peer can close the TCP connection. The END_STREAM flag on a DATA frame is treated as equivalent to the TCP FIN bit. Only after receiving a frame with the END_STREAM flag can the client send a DATA frame with the END_STREAM flag set. A proxy that receives a DATA frame with the END_STREAM flag can send additional data and set the FIN bit on the final TCP segment. A proxy that receives a TCP segment with the FIN bit set sends a DATA frame with the END_STREAM flag set. Note that the final TCP segment or DATA frame can be empty.
RST_STREAM is used to indicate a TCP connection error. Any error in the proxied TCP connection is treated as a stream error of type CONNECT_ERROR (Section 5.4.2), including receiving a TCP segment with the RST bit set. Correspondingly, if the proxy detects an error in the stream or the HTTP/2 connection, the proxy must send a TCP segment with the RST bit set.
