OPERATION IRON GATE

Access Gate & Vault Control

Act II of OPERATION COLD IRON

LEGAL DISCLAIMER: The information, tools, and code provided in this repository and course are strictly for educational, research, and defensive purposes only.

You are explicitly prohibited from using any materials contained herein to access, test, modify, or exploit any device, network, or system that you do not own 100% or for which you do not have explicit, documented, and legally binding authorization to interact with.

By using this repository and course, you acknowledge and agree that:

Any illegal, unauthorized, or malicious use of this information is solely your responsibility.
The author(s) and contributor(s) of this repository and course shall not be held liable for any damages, legal repercussions, criminal charges, or unauthorized actions resulting from the use, misuse, or abuse of the contents herein.
You will comply with all applicable local, state, national, and international laws regarding cybersecurity and computer fraud.

IF YOU DO NOT AGREE WITH THESE TERMS, DO NOT USE THIS REPOSITORY AND COURSE.

Hello, friend.

In Act I you learned the first lesson: a sensor can lie. It reported minus eighteen while the store warmed, and the lie was the product.

This is the second lesson. The door.

The frame you pulled out of the monitor led somewhere. A NorthPharma logistics annex with one entrance and no windows. NIGHTINGALE sent her last ping from inside it, then went quiet. FROSTLINE is already wiping the site. WHITEOUT has until dawn.

The only way in is the access gate. A keypad nobody watches, a deadbolt on a servo, and an audit uplink that is supposed to tell the truth about who came through.

Last time the AI wrote bad code for a sensor. This time it wrote bad code for a door. Worse: the gate keeps its final verdict in plain SRAM, and the cryptography around it is perfect. So the door trusts a boolean.

You are going to walk through it, friend. Then you are going to seal it.

THE SYSTEM

NorthPharma owns the cold chain. Not all of it. Enough of it. The monitors, the gateways, the insurance, the audits. When a shipment spoils, they pay a claim, raise the premium, and sell a newer monitor. Failure is not a bug in their business. Failure is the business.

The door was a vendor upcharge. A lobby turnstile grew into a "secure access program," and the program was signed off by the same committee that approved the monitors. Same procurement, same deadline, same AI-assisted code generator, same negligent vendor. Act II is not a new enemy. It is the same disease with a deadbolt bolted to it.

Their security arm is still called FROSTLINE. You will not find it on an org chart. It exists so that when a site is scrubbed, no one can point at a person. It does not break into buildings. It makes the buildings believe they are safe.

THE STAKES

Act I was a lie about temperature. Act II is a lie about people. Every badge, every PIN entry, every request to exit lands in an access log that the site trusts. If the log can be forged, nobody knows who was inside when the wipe began. If the verdict can be flipped, the bolt opens for anyone with a debugger.

NIGHTINGALE is behind that door. The evidence that ends FROSTLINE is on the other side of it. The gate is the last thing standing between a person and a bulldozer, and the gate was built to trust the wrong thing.

That is not access control. That is a locked room with a vent, and the vent is a firmware flag.

NIGHTINGALE

She was a firmware engineer. Thirteen years. She wrote the bootloader they all trust. In Act I she copied the shipping image to a dead drop and sent one message to a crew that does not exist on paper. Us. WHITEOUT.

Then the messages stopped. The last packet was a frame from the monitor, and the frame carried a location. The location is the annex. The annex has a door. The door is this project.

She is still in there. The clock is running.

THE MACHINE

The firmware in this repository is the door's firmware. On a breadboard it is a toy: a Pico 2, an infrared badge reader that doubles as a PIN keypad, a 1602 LCD access log, three LEDs, a request-to-exit button, an SG90 deadbolt servo, a DHT11 vault interlock, and a radio.

Two things are open. The radio takes an order from anyone on the band, and it carries the sealed authorization and audit uplink. The infrared eye takes a badge and a PIN from anyone with a universal remote, and it is the primary input, not a maintenance afterthought. Neither surface asks a hard question by itself. And the servo will throw the deadbolt because a machine that keeps its verdict in plain SRAM will obey whatever writes the verdict.

Then there is the face of the thing. The LEDs and the LCD report DENIED, PENDING, and GRANTED with total confidence. The gate does not know the difference between a real desk grant and a boolean a debugger set. It will show you green while it lets you walk into a site that is being erased.

THE JOB

You do not have to be a hero. You have to be honest. The door is lying about who it let in. Make it tell the truth.

Read the dead. Take the image apart. Map the keypad, the display, the radio, the LEDs, the request-to-exit button, the servo, and the interlock.
Find the doors. Replay a captured grant. Forge an unlock. Flip the SRAM verdict with a debugger. Walk through request-to-exit.
Lock them. Seal every frame with XChaCha20-Poly1305, keyed through Argon2id, add a monotonic anti-replay window so a captured grant dies on second use, and tag the authorization record so a flipped boolean fails before the bolt moves.
Fix the policy. Make the gate fail secure, rate-limit the keypad, lock the debug port, and leave the life-safety egress exactly where it is, named and defended on purpose instead of by accident.

This document is the manual for the job. Work it on a breadboard. When the green light lies to you, remember what it is: not a welcome. A witness.

Goodbye, friend.

A NOTE ON THE ROADMAP

This capstone is Act II of OPERATION COLD IRON. Act I was the sensor (cold-chain-monitor). Act 2 is the door. Both are defended devices; the companion CTF repository ships the compromised one. The investigation lives here:

OPERATION IRON GATE CTF

The CTF is the red half, weaponized: four deep defects, each with a static analysis, a dynamic proof under GDB, a hardware demonstration, and an in-place, same-size patch. This repository is the defended device. The CTF repository is the breached one. The full story lives at github.com/mytechnotalent/access-gate.

WHERE THIS FITS: OPERATION COLD IRON

This repository is Act II (IRON GATE) of the ten-act OPERATION COLD IRON saga. Acts I and II are the vulnerability-only foundation; the malware track begins at Act III. The full spine is in SAGA.md.

Previous act: Act I, COLD IRON, cold-chain-monitor
This act: Act II, IRON GATE, the access gate
Next act: Act III, IRON VEIN (pipeline-valve-controller, forthcoming)
Companion CTF: CTF_access-gate

THE MINISTRY

The Ministry runs the state: the surveillance, the cold chain, the gates, the pipelines. NorthPharma is one of its deniable industrial fronts, and FROSTLINE is the contractor that does the work no Ministry letterhead will admit to. Against them is WHITEOUT, and the engineer who copied this image, NIGHTINGALE. This act is one node of the Ministry's industrial edge. TELESCREEN, the surveillance backbone that watches it, comes after the ten.

An adversarial, evidence-based audit of this act, including its honest limitations, is in NATION-STATE-REVIEW.md.

How This Project Fits the Embedded Hacking Course

This repository is the Act II capstone integration for the Embedded Hacking course. It reuses the entire Act I peripheral set so one breadboard serves both chapters, and it adds the stateful security concepts the course builds toward: authorization versus authentication, anti-replay, state integrity, debug-port trust, and fail-secure policy.

Each earlier module teaches one peripheral or language concept in isolation; this project wires several of them into a single, tested product and adds the wireless and stateful security layers on top.

Embedded Hacking module	Concept you learn	Where it lives here
Week 1: Introduction, Ethics, Scoping	Authorized lab work	Every lab is self-contained and authorized by design
Week 3: RP2350 Architecture and Firmware Analysis	Bare-metal targets, ELF/UF2, SWD	Pico SDK build, `build/*.uf2`, Debug Probe flash via OpenOCD
Weeks 4-6: Variables, Integers/Floats, Static	Data types, GPIO	`src/monitor.c` state machine, LED on GP25
Week 7: Constants with 1602 LCD I2C	I2C bus, HD44780 commands	`src/display.c`
Week 9: Operators with DHT11	Bit operations, edge timing	`src/sensor.c` vault interlock
Week 11: Structures and Functions	Modular design	`include/.h` and `src/.c` module boundaries
This project adds	UART AT driver, LoRa desk link, stateful auth, anti-replay, authenticated state, debug lockdown, fail-secure policy, strict testing	`src/radio.c`, `src/auth.c`, `src/keypad.c`, `scripts/gateway.py`, `scripts/spoof.py`, `scripts/gen_packet.py`, `test/`

If you have not worked through Weeks 7 and 9 yet, do those first: this project assumes you are comfortable with I2C wiring and one-wire edge timing.

Learning Objectives

By the end of this chapter and its labs you will be able to:

Explain why physical access control is an authorization problem, not just an authentication problem, and why proving who someone is does not prove what they are allowed to do.
Wire and drive a 1602 LCD through a PCF8574 I2C backpack and render an access log with the last badge, sequence, and verdict.
Decode a VS1838B infrared receiver as both a badge reader and a NEC PIN keypad, including the digit, ENTER, and CLEAR command codes and the ready-before-consume guard on the accumulator.
Drive an SG90 deadbolt with 50 Hz PWM and explain why a 1000uF bulk capacitor is not optional.
Read a DHT11 vault interlock and enforce a safe environmental band before the bolt is allowed to move.
Design a sealed request and grant exchange over a sub-GHz LoRa link using a fixed-size envelope and the declared-length slicing invariant.
Distinguish authentication from authorization, and demonstrate both: a forged grant that fails the tag, and a captured grant that passes the tag but fails the anti-replay window.
Explain state integrity and TOCTOU, and demonstrate with GDB that flipping the SRAM verdict boolean without recomputing the state tag is rejected before the deadbolt moves.
Apply blue-half controls: a monotonic sequence window, an authenticated state tag, debug-port lockdown, keypad rate limiting and lockout, and a fail-secure policy.
Reason about designed egress: why request-to-exit is deliberately unauthenticated for life safety, and why the correct response is documentation and defense in depth rather than "fixing" it closed.
Derive a key with Argon2id, seal every frame with XChaCha20-Poly1305, and read and run a native host test suite with hardware mocks and line coverage.

Prerequisites

The Embedded Hacking breadboard (EHP2_bb.png) and parts list.
Act I is helpful but not required. See cold-chain-monitor for the sensor and telemetry chapter. The pin map is identical, so one breadboard serves both.
Comfort with C, the Linux/macOS shell, and basic electronics.
A Pico 2, a Debug Probe (recommended), a 1602 LCD with PCF8574 backpack, a DHT11, the full Embedded Hacking kit (3 LEDs, 3 resistors, a push button, an SG90 servo, a 1000uF capacitor, and a VS1838B infrared receiver plus NEC remote), two RYLR998 modules, and one USB-to-TTL serial adapter.
Toolchain: Pico SDK 2.2.0+, arm-none-eabi-gcc, CMake, Ninja, Python 3, GDB (arm-none-eabi-gdb) for Lab 3, and (optionally) typst to rebuild the paper.

Background
System Architecture
The Wire Protocol
The Cryptographic Envelope
Hardware You Need
Wiring the Node
Build and Flash
Lab 1: Bring-Up and Verify
Lab 2: Inspect the Wire Protocol
Lab 3: The Red Half
Lab 4: The Blue Half
Troubleshooting
Testing Philosophy and Coverage
Generating Packet Artifacts
Code Standards
Project Layout
Glossary
Further Reading
License

Background

Why physical access control

A door is a decision. Someone presents a badge or a PIN, the door decides whether that person may pass, and a bolt moves. Everything interesting in access control happens in that decision and in the record it leaves behind. Two separate questions hide inside it:

Authentication. Who is this? A badge number, a PIN, a cryptographic key.
Authorization. Are they allowed, right now, in this state, to pass?

The classic failure of naive systems is to collapse the two. If a PIN equals a stored value, open. But a PIN is a shared secret that leaks, that gets written on the back of a badge, and that says nothing about whether the holder should be inside the vault at three in the morning. Act II splits the questions on purpose: a sealed request goes to a security desk, and the desk decides. The desk is the authorization authority. The gate is the enforcement point.

Why replay and state integrity matter

Even after every frame is authenticated with strong cryptography, two attacks remain, and they are the heart of Act II:

Replay. A perfectly valid, authentically sealed GRANTED frame is captured off the air and sent again later. Cryptography is happy: the tag is correct. Only state, a monotonic counter, can tell the gate that this grant was already used.
State tampering. The gate decides with a boolean in SRAM, call it granted. An attacker with a debug probe and a GDB session does not break the cipher; they set granted = 1 and let the bolt move. The wire is sealed; the verdict is not.

This is the TOCTOU lesson in embedded form: the cryptographically strong decision happens, then a plain, mutable piece of memory is trusted afterward. The fix is not more cipher. It is to authenticate the state itself, so a modified verdict no longer matches the tag computed over the record.

Why ChaCha20 over AES on the RP2350

The RP2350 has no hardware AES engine; its accelerated crypto block covers SHA-256, not AES. A software AES implementation on this part is therefore both slower and riskier, because table-driven AES performs data-dependent memory accesses that create a cache-timing side channel. ChaCha20 is built only from addition, rotation, and XOR, with no data-dependent table lookups, so it is fast in portable C and has no comparable cache-timing surface. XChaCha20-Poly1305 is thus both the modern choice and the pragmatic one for this silicon. The full rationale, including the extended-nonce benefit, appears in The Cryptographic Envelope.

The two on-wire problems this project solves

Payloads that contain commas. The sealed body is carried as lowercase hex, but the +RCV framing still separates fields with commas. A naive receiver that splits the line on the first comma corrupts the frame. The correct discipline is the declared-length rule: slice exactly L characters after the second comma and require the next character to be a comma.
Telling a real grant from a forged or replayed one. The gate records the sender address exactly as the radio reports it, and it trusts the bytes that arrive. The sealed envelope plus the stateful window are what close that gap.

Inter-Integrated Circuit (I2C)

I2C is a two-wire bus: SDA (data) and SCL (clock), each pulled up to the supply rail. A controller (the Pico) addresses a target by its 7-bit address and writes or reads bytes. The 1602 LCD backpack carries a PCF8574 I/O expander at address 0x27; the firmware bit-bangs the HD44780 nibble protocol over that expander. Pull-ups are mandatory: the firmware enables the internal ones and the backpack usually adds its own.

The DHT11 one-wire protocol

The DHT11 is a low-cost digital temperature and humidity sensor. In Act II it is the vault environmental interlock: the deadbolt will not release unless the vault is inside a safe temperature band. It speaks a custom single-wire protocol:

The host pulls the line low for at least 18 ms (the start pulse), then releases it and enables its pull-up.
The sensor answers with an 80 us low, then an 80 us high handshake.
The sensor sends 40 bits. Each bit begins with a 50 us low, then a high pulse whose width encodes the value: about 26-28 us for a 0, about 70 us for a 1.
Five bytes follow: humidity integer, humidity decimal, temperature integer, temperature decimal, and a checksum equal to the low byte of their sum.

Reading it means timing edges on the order of tens of microseconds, so the firmware uses an 18 ms host pulse, a 50 us bit-classification threshold, and a 240 us per-edge timeout so a dead or unplugged sensor fails fast instead of hanging the loop. A reading that fails its checksum is never "safe", and a valid reading outside -5.0 C to 10.0 C (the tenths band -50 to 100) is out of band. Either way, the interlock denies the release.

Universal Asynchronous Receiver/Transmitter (UART) and AT commands

The RYLR998 is driven over a UART at 115200 baud using CRLF-terminated ASCII commands. The firmware writes AT+SEND=... and drains inbound +RCV=... lines. Because the radio is a separate processor, its configuration (address, network identifier, band) persists until changed; the gate and the security desk each provision their own radio at start-up so they agree before any authorization traffic flows.

Cyclic Redundancy Check (CRC)

src/crc.c implements CRC-16/CCITT-FALSE (poly = 0x1021, init = 0xFFFF, check value 0x29B1 for "123456789"). It is provided as a reusable integrity diagnostic and exercised by the test suite. It is not part of the LoRa frame in this project; the lesson is the absence of authentication, not the absence of a checksum.

System Architecture

There are four roles:

Role	Runs on	Job
Gate node	Pico 2 firmware	Decodes the IR badge and PIN keypad, seals an unlock request to the desk, announces PENDING, verifies the sealed grant, drives the deadbolt, enforces the interlock, and logs state
Security desk	laptop + USB-TTL radio	Authenticates every request, logs it to `access_log.csv`, decides authorization, and answers with a sealed grant carrying a sequence and a state tag (`scripts/gateway.py`)
Edge simulator	laptop + USB-TTL radio	Pretends to be a second gate node and sends sealed requests (`scripts/sim_edge.py`)
Attacker	laptop + USB-TTL radio	Impersonates the desk, forges a grant, or replays a captured grant (`scripts/spoof.py`)

Data flow

+----------------------+                              +----------------------+
|   Pico 2 gate node   |        LoRa (sub-GHz)        |   Security desk      |
|   IR keypad -> GP5   |  AT+SEND=0001,<len>,<hex>    |  USB-TTL radio       |
|   DHT11     -> GP4   |----------------------------->|  scripts/gateway.py  |
|   Servo     -> GP14  |<-----------------------------|  access_log.csv      |
|   LCD    -> GP2/GP3  |  AT+SEND=<gate>,<len>,<hex>  |  sealed grant reply  |
+----------------------+                              +----------------------+

+----------------------+                              +----------------------+
|   Attacker laptop    |  forged or replayed grant    |   (same gate)        |
|   scripts/spoof.py   |----------------------------->|   rejects at the tag |
|  claims the desk     |                              |   tag or seq window  |
+----------------------+                              +----------------------+

Firmware module map

File	Responsibility
`src/main.c`	Entry point: `stdio_init_all`, `monitor_init`, tick loop
`src/monitor.c`	State machine: I2C bus scan, keypad, desk request, grant verification, deadbolt, interlock, access log
`src/keypad.c`	NEC command to PIN accumulator with a bounded count and ready-before-consume guard
`src/auth.c`	Authorization record, monotonic anti-replay window, authenticated state tag
`src/sensor.c`	DHT11 one-wire sampling and vault interlock classifier
`src/display.c`	HD44780 driver over the PCF8574 backpack and access-log rendering
`src/radio.c`	RYLR998 provisioning, `AT+SEND` builder, `+RCV` parser, line pump
`src/status_led.c`	Red/yellow/green DENIED/PENDING/GRANTED annunciator
`src/button.c`	Debounced request-to-exit button around the internal pull-up
`src/servo.c`	50 Hz PWM deadbolt actuator
`src/ir_remote.c`	VS1838B edge timing and NEC remote decode
`src/chacha20.c`	ChaCha20 stream cipher and HChaCha20 subkey derivation
`src/poly1305.c`	Poly1305 one-time message authenticator
`src/crypto_aead.c`	XChaCha20-Poly1305 seal/open envelope
`src/blake2b.c`	BLAKE2b and the Argon2 variable-length hash H'
`src/argon2.c`	Argon2id core (BLAMKA, hybrid addressing)
`src/crypto_kdf.c`	Argon2id passphrase key derivation
`src/envelope.c`	Hex nonce/ciphertext/tag envelope codec
`src/crc.c`	CRC-16/CCITT-FALSE diagnostic
`include/access_gate.h`	Pin map, bus, and provisioning constants
`include/auth.h`	Authorization record, window, and state tag
`include/keypad.h`	PIN accumulator interface

The Wire Protocol

Request frame

The gate seals the entered PIN into an authenticated envelope and sends it to the security desk:

AT+SEND=0001,<len>,<hex envelope>

The plaintext of a request is the PIN text itself, for example 482190 for a six-digit PIN. Six digits is the bounded accumulator length (ACCESS_GATE_PIN_LENGTH, PACKET_PIN_LENGTH); the keypad refuses a seventh and refuses any value above nine.

Grant frame

The desk answers an authenticated request with a sealed grant. The grant plaintext is a 20-byte body:

seq[4] (little-endian) || state_tag[16]

seq is the monotonic desk sequence number.
state_tag is an XChaCha20-Poly1305 tag over the authorization record the grant would produce, so the gate can verify that the verdict it is about to store is the one the desk authorized.

The desk sends it back to the claimed sender address:

AT+SEND=<gate>,<len>,<hex envelope>

Sealed envelope layout

Every payload on the wire is the lowercase hexadecimal encoding of:

nonce[24] || ciphertext[L] || tag[16]

For a six-digit request body this is 24 + 6 + 16 = 46 bytes, or 92 hex characters. For a 20-byte grant body this is 24 + 20 + 16 = 60 bytes, or 120 hex characters. The declared length L in the AT+SEND and +RCV framing is the length of the hex string, not of the underlying plaintext.

The maximum accepted plaintext is 48 bytes (ENVELOPE_MAX_PLAINTEXT), and the maximum hex envelope buffer is (24 + 48 + 16) * 2 + 1 = 177 bytes (ENVELOPE_MAX_HEX_LEN), which fits the 256-byte radio command and receive buffers with framing headroom.

Declared-length slicing invariant

Given the substring T after the second comma:

C = T[0 : L]   and   T[L] == ","

The receiver checks T[L] == ",", so a mismatch between the declared length and the actual payload is a parse error rather than silent corruption. This is what makes hex-bearing payloads safe to carry and is the same invariant Act I uses.

LCD access log

PIN:482190 S:0007
STATE:PENDING

Line 1 is the last badge PIN and the most recent accepted sequence number. Line 2 is the current gate state: OFF, DENIED, PENDING, or GRANTED. Exactly one status LED is lit at a time to match.

Radio provisioning

For the link to work, both radios must share the same network identifier and each must have the address the other targets:

Firmware sets its own radio: AT+ADDRESS=7, AT+NETWORKID=18.
gateway.py sets the desk radio: AT+ADDRESS=1, AT+NETWORKID=18.

Both radios must also be the same band variant (for example 915 MHz or 868 MHz); band and RF parameters are left at factory defaults, so use matching modules.

Timing

Quantity	Value
Authorization wait (`AUTH_WAIT_MS`)	5000 ms
Deadbolt release hold (`MONITOR_HOLD_MS`)	5000 ms
Request-to-exit debounce	30000 us
DHT11 host start pulse	18000 us
DHT11 bit threshold	50 us
DHT11 per-edge timeout	240 us
LCD I2C clock	100000 Hz
Radio UART baud	115200
PIN length	6 digits
Interlock safe band	-50 to 100 tenths (-5.0 C to 10.0 C)
Servo locked pulse	500 us
Servo open pulse	1500 us
Servo PWM period	20000 us (50 Hz)

The Cryptographic Envelope

The radio is the first open door, and it is the one a key can close. The fix is authenticated encryption: every request and every grant is sealed so a forged frame dies at the authentication tag instead of moving the deadbolt. The full implementation lives in src/chacha20.c, src/poly1305.c, and src/crypto_aead.c, and every primitive is checked against its published test vectors in the native suite.

Why XChaCha20-Poly1305

256-bit key, 192-bit nonce. The extended nonce means nonces can be drawn at random forever, so the gate never needs a shared counter that a reboot could reuse.
AEAD in one pass. Confidentiality and integrity come from one operation; the associated data (the gate node id, byte 0x07) is authenticated even though it is not encrypted.
Constant-time software. ChaCha20 has no data-dependent table lookups, so it has no cache-timing surface. The RP2350 has no hardware AES engine (it accelerates SHA-256 only), which makes software AES both slower and riskier on this silicon.
128-bit Poly1305 tag. Guessing a valid tag succeeds with probability $2^{-128}$ .

Why Argon2id

A passphrase is not a key. Argon2id (RFC 9106) is the memory-hard password hash: it mixes the passphrase with a salt across memory and time so an attacker cannot cheaply recover the field passphrase from a captured image. The classroom profile is t=3, p=1, m=64 blocks (CRYPTO_KDF_TIME_COST, CRYPTO_KDF_PARALLELISM, CRYPTO_KDF_MEMORY_BLOCKS) to fit the RP2350 SRAM budget. Raise it on the security desk. The lab salt is the 16 ASCII bytes coldiron-salt-01.

Key model: one field key plus a desk key

Act II introduces a two-role key model, and the lifecycle is the lesson:

Field key. Derived with Argon2id and used to seal every frame on the wire, both the gate request and the desk grant.
Desk key. The authorization authority. It is the key under which the desk computes the state tag over the authorization record, so the gate can tell a real grant from a boolean a debugger wrote into SRAM.

In the classroom build the field key and the desk role are both derived from the same committed lab passphrase and salt, so the firmware and the security desk interoperate with no provisioning step. That is a lab convenience, not a deployment. The design names the two roles separately so students can reason about the real lifecycle: derive, provision per device, use, rotate on a schedule, and retire. A production build provisions key material from one-time-programmable (OTP) memory, keeps the desk key off the field device, and rotates the field key without reflashing every gate.

Envelope layout

The sealed frame is carried as hex inside the AT+SEND payload:

nonce[24] || ciphertext[L] || tag[16]

The receiver recomputes the Poly1305 tag over the associated data and ciphertext, compares it in constant time, and only then decrypts. This envelope is wired end to end: src/monitor.c seals the request with src/envelope.c, the desk authenticates before it parses or acts, and the gate opens the reply only after the tag verifies. Authenticated frames carry the gate node id as associated data, so a frame sealed for one node cannot be relabeled for another.

Act II additions: anti-replay and authenticated state

Strong AEAD is necessary and not sufficient. Two stateful controls sit on top:

Anti-replay sequence window. src/auth.c keeps last_seq, the highest sequence number ever accepted. auth_apply_grant accepts a grant only when its sequence is strictly greater than last_seq. A captured GRANTED frame, even a perfectly valid one, is rejected on second use.
Authenticated state tag. The authorization record is ten bytes: granted, pending, seq[4], last_seq[4]. The tag is an XChaCha20-Poly1305 tag over that record, computed under the field key with a deterministic nonce built from the sequence number and the domain byte 0xA6. auth_state_ok recomputes the tag and compares it in constant time before the bolt is allowed to move. A debugger that sets granted = 1 without recomputing the tag fails here first.

The sequence window and the state tag are independent. The window stops a valid grant from working twice; the tag stops an unauthorized verdict from existing at all.

Hardware You Need

Full parts list with links: PARTS.md.

Qty	Part	Notes
1	Raspberry Pi Pico 2 (RP2350) with headers	The gate node
1	Raspberry Pi Debug Probe	SWD flashing, UART0 console, and the Lab 3 SRAM attack (recommended)
1	Full-size breadboard
1	Assorted jumper wires
1	1602 LCD with PCF8574 I2C backpack	Access log, address `0x27`
1	DHT11 temperature/humidity sensor	Vault environmental interlock
1	10K resistor	Only if your DHT11 has no onboard pull-up
3	5mm LEDs (red, yellow, green)	DENIED, PENDING, GRANTED annunciator
3	100, 220, or 330 Ohm resistors	One per LED
1	Push button (tactile switch)	Request-to-exit, active low
1	SG90 servo motor	Deadbolt actuator
1	1000uF 25V capacitor	Bulk decoupling on the servo 5V rail
1	VS1838B infrared receiver	Badge reader and PIN keypad input
1	NEC-compatible infrared remote	Badge and PIN keypad trigger
3	RYLR998 LoRa modules with antennas	2 for the authorization loop, 3 for the live attack lab
2	USB-to-TTL serial adapters (FTDI FT232, CP2102, or CH340), 3.3V logic	1 for the desk, 1 for the attacker in the live lab
4	USB cables	Pico 2, Debug Probe, and serial adapter(s)

How many radios do you actually need?

Goal	Radios	What is connected
Legitimate authorization loop (Labs 1-2)	2	1x RYLR998 on the Pico (UART1) + 1x RYLR998 on a USB-to-TTL adapter (the desk)
Live attack lab (Labs 3-4, watch a grant land and fail)	3	the 2 above + 1x RYLR998 on a second USB-to-TTL adapter (the attacker)
Attack concept with no extra hardware	2 or 0	read-and-run the offline parser demo, or the unit tests

A radio never receives its own transmission, and the desk radio is busy listening as gateway.py, so the live attack needs a separate attacker radio. The 2-radio kit runs the whole legitimate system; only the live attack observation needs the third.

Serial adapter warning: the RYLR998 is not 5V tolerant. Use a 3.3V-logic USB-to-TTL adapter (or set its jumper to 3.3V).

How each part works

Every part in the bill of materials does one physical job and one job in this act:

Part	How it works	Role in this act
1x Full-size breadboard (long)	The two columns of spring-clip tie points sit on a 0.1 inch grid, so every hole in a row is bridged by a metal clip, while the two outer power rails run the full length and distribute power and ground to the whole build.	It is the substrate that holds the Pico 2, LCD, sensor, servo, and radio headers and distributes 3.3V and 5V across the gate.
1x Assorted jumper wires (male-to-male, male-to-female, female-to-female)	Male pins push into breadboard tie points or female headers, female sockets slide over the Pico 2, LCD, and servo header pins, and male-to-female leads bridge a breadboard row to a module header.	They carry power and the I2C, one-wire, UART, PWM, IR, and GPIO signals between the boards.
1x Raspberry Pi Pico 2 with header	The RP2350 pairs two Arm Cortex-M33 cores with 3.3V logic and a GPIO block that exposes ADC, I2C, UART, and PWM, plus the onboard GP25 LED.	It is the gate controller that accumulates the IR PIN, checks the vault interlock, drives the deadbolt servo and annunciator, and runs the sealed request and grant protocol.
1x Raspberry Pi Pico Debug Probe	It drives the two-wire SWD port (SWCLK and SWDIO) to flash and single-step the target, and it also presents a USB UART bridge for the serial console.	It flashes and debugs the gate and is the instrument for the Lab 3 SRAM verdict attack and the fix.
2x USB A-male to USB micro-B cables	USB carries 5V power and a data channel on the same cable, so one cable powers the Pico 2 and presents its USB CDC console while the other powers the Debug Probe and carries its SWD and UART traffic.	They power the two boards and carry the console and debug links.
3x 5mm LEDs (1 red, 1 green, 1 yellow)	An LED is a diode with a forward voltage drop of roughly 2V, so current flows only from the anode to the cathode, and a GPIO pin set high sources that current and lights the lamp.	They are the red DENIED, yellow PENDING, and green GRANTED access annunciator, and exactly one is lit per state.
3x 100, 220, or 330 Ohm resistors	A resistor in series with each LED sets the current by Ohm's law, I equals (supply minus forward voltage) divided by resistance, which protects the LED and keeps the GPIO within its current limit.	One resistor per lamp limits the LED current on each of the three annunciator pins.
1x Push button (tactile switch)	The switch shorts its input pin to ground when pressed, and the RP2350 internal pull-up holds that pin high at rest so the press reads as active low.	It is the request-to-exit button, the deliberate life-safety egress path that opens the deadbolt without a badge or PIN.
1x 1602 LCD with PCF8574 I2C backpack	The HD44780 controller takes a 4-bit nibble protocol with register-select and enable strobes, and the PCF8574 I2C expander latches those eight control lines so the whole display is driven over two I2C wires at address 0x27.	It renders the access log readout.
1x DHT11 temperature and humidity sensor	The host pulls the single data line low for a start pulse, then the sensor answers with 40 bits of humidity, temperature, and checksum timed by pulse widths, and the checksum must match.	It is the vault environmental interlock that denies a release when the reading fails or leaves the -5.0 C to 10.0 C band.
1x SG90 servo motor	The servo expects a 50 Hz PWM signal whose high pulse of 1 to 2 ms selects the shaft angle, and a Pico PWM slice generates that pulse train.	It is the deadbolt actuator, locked at 0 degrees and open at 90 degrees.
1x 1000uF 25V capacitor	Wired across the servo 5V rail and ground, the capacitor is a bulk reservoir that supplies the motor inrush current and smooths the rail while the servo starts.	It keeps the deadbolt move from browning out the RP2350 and resetting the gate.
1x Infrared (IR) receiver (VS1838B)	The receiver pairs a photodiode with a 38 kHz bandpass demodulator that ignores ambient light and outputs an active-low logic pulse for each IR burst.	It is the primary PIN input that feeds digits and ENTER and CLEAR into the accumulator on GP5.
1x Infrared (IR) remote controller (NEC-compatible)	The remote emits its bursts modulated at 38 kHz in the NEC frame, a 9 ms leader followed by 32 bits where the address and command are each sent with their bitwise complements for validation.	It is the badge and PIN keypad that sends digits 0x16 to 0x4A, ENTER 0x46, and CLEAR 0x45.
1x RYLR998 LoRa radio module	The module is configured and driven over UART with AT commands and carries sub-GHz LoRa packets, and its logic pins are 3.3V only so the radio must never see 5V.	It is the UART1 request and grant link that carries the sealed frames between the gate and the desk, and it is not 5V tolerant.

Wiring the Node

Pin map

This is the authoritative map; it is identical to Act I and is defined in include/access_gate.h and enforced by the test suite.

Peripheral	Signal	Pico 2 GPIO
DHT11 vault interlock	DATA (one-wire)	GP4
1602 LCD (PCF8574)	SDA (I2C1)	GP2
1602 LCD (PCF8574)	SCL (I2C1)	GP3
RYLR998	RX <- Pico TX (UART1)	GP8
RYLR998	TX -> Pico RX (UART1)	GP9
Infrared receiver	OUT (VS1838B)	GP5
Deadbolt servo	PWM signal	GP14
Red DENIED LED	anode	GP16
Yellow PENDING LED	anode	GP17
Green GRANTED LED	anode	GP18
Request-to-exit button	to ground	GP15
Onboard LED	heartbeat	GP25
Debug Probe / UART0 console	TX	GP0
Debug Probe / UART0 console	RX	GP1

Note: GPIO 2/3 are the classic I2C1 pins used throughout the Embedded Hacking breadboard; this project's map matches that board because it is the same board.

1602 LCD with I2C backpack

LCD backpack	Pico 2
VCC	3.3V
GND	GND
SDA	GP2
SCL	GP3

DHT11 vault interlock

DHT11	Pico 2
VCC	3.3V
DATA	GP4
GND	GND

If your DHT11 has no onboard pull-up, add a 10K resistor between DATA and 3.3V. The firmware also enables the internal pull-up, but the external resistor makes reads far more reliable over jumper wires. The interlock denies the release when the sensor fails or reads outside -5.0 C to 10.0 C.

Status LEDs

LED	Pico 2	Series resistor
Red (DENIED)	GP16 (anode)	220-330 Ohm to GND
Yellow (PENDING)	GP17 (anode)	220-330 Ohm to GND
Green (GRANTED)	GP18 (anode)	220-330 Ohm to GND

Exactly one lamp is lit at a time. Red is a denied or failed authorization, yellow is a request awaiting the desk, and green is an open deadbolt.

LED behavior

State	Lamp	Indication	Meaning
`STATUS_LED_OFF`	none	All dark	Deadbolt is locked and no authorization is in flight.
`STATUS_LED_DENIED`	Red	Solid	Authorization was denied or failed, the interlock tripped, or the pending wait expired.
`STATUS_LED_PENDING`	Yellow	Solid	A sealed unlock request is awaiting the desk grant.
`STATUS_LED_GRANTED`	Green	Solid	The deadbolt is released for the bounded hold.

The three annunciator lamps are always solid; status_led.c never blinks them. Exactly one lamp is lit at a time, and STATUS_LED_OFF leaves all three dark. A pending request that times out falls back to STATUS_LED_DENIED, and a grant that expires falls back to STATUS_LED_OFF. The onboard GP25 LED is initialized as an output and driven as a heartbeat: monitor.c toggles it every four monitor ticks in monitor_heartbeat, so a running gate is visible even while idle.

Request-to-exit button

Button	Pico 2
Leg 1	GP15
Leg 2	GND

The firmware enables the internal pull-up, so do not connect 3.3V to the button. This is the deliberate, unauthenticated life-safety egress path: a press consumes one debounced edge, checks the interlock, and opens the deadbolt without a badge, a PIN, or a desk grant. Lab 4 explains why that is correct and how to contain it rather than close it.

SG90 deadbolt servo

Servo	Pico 2
Signal (orange)	GP14
VCC (red)	5V (VBUS)
GND (brown)	GND

Solder the 1000uF capacitor across the servo 5V and GND rails to absorb the inrush current; without it the RP2350 can brown out when the deadbolt moves. Locked is 0 degrees and open is 90 degrees.

Infrared receiver

VS1838B	Pico 2
OUT	GP5
VCC	3.3V
GND	GND

Point any NEC-compatible remote at the receiver. In Act II this is the primary input, not a maintenance extra: the firmware decodes digit commands 0x16 through 0x4A, an ENTER command 0x46, and a CLEAR command 0x45, and feeds them into the PIN accumulator. There is no challenge and no secret on the optical surface, which is exactly the point of Lab 3.

Using the remote

Point the NEC remote at the VS1838B receiver on GP5 and press a mapped button; the receiver idles high and pulls low on a mark. Every valid frame prints IR <NAME> (0xNN) on the console and is fed straight into the PIN accumulator.

NEC command	Name	Action
`0x16`	`MONITOR_IR_DIGIT_0`	Pushes digit `0` onto the PIN accumulator.
`0x0C`	digit	Pushes digit `1` onto the PIN accumulator.
`0x18`	digit	Pushes digit `2` onto the PIN accumulator.
`0x5E`	digit	Pushes digit `3` onto the PIN accumulator.
`0x08`	digit	Pushes digit `4` onto the PIN accumulator.
`0x1C`	digit	Pushes digit `5` onto the PIN accumulator.
`0x5A`	digit	Pushes digit `6` onto the PIN accumulator.
`0x42`	digit	Pushes digit `7` onto the PIN accumulator.
`0x52`	digit	Pushes digit `8` onto the PIN accumulator.
`0x4A`	`MONITOR_IR_DIGIT_9`	Pushes digit `9` onto the PIN accumulator.
`0x46`	`MONITOR_IR_ENTER_COMMAND`	Latches a full-length PIN and sends a sealed unlock request to the desk; the annunciator shows PENDING.
`0x45`	`MONITOR_IR_CLEAR_COMMAND`	Clears the PIN accumulator without sending a request.

A digit command beyond 0x4A is discarded, and ENTER is ignored until exactly ACCESS_GATE_PIN_LENGTH digits are held.

RYLR998 LoRa radio

The RYLR998 must be powered. Forgetting VDD is the single most common reason the link appears dead: the firmware prints while the radio sits silent.

RYLR998	Pico 2
VDD	3.3V
GND	GND
RXD	GP8 (Pico UART1 TX)
TXD	GP9 (Pico UART1 RX)

Attach the antenna before transmitting. TX and RX are crossed: the radio's RXD is the Pico's TX and vice versa.

Debug Probe (recommended)

Debug Probe	Pico 2
SWCLK	SWCLK (3-pin debug header)
SWDIO	SWDIO
GND	GND
UART TX	GP1 (Pico RX)
UART RX	GP0 (Pico TX)
GND	GND

The firmware enables stdio on both UART0 (115200) and USB, so you can watch boot output on the probe's console or on the Pico's own USB serial port. The Debug Probe is also the instrument for the Lab 3 SRAM verdict attack: the probe that fixes the firmware is the probe that breaks it if the verdict is not authenticated.

Peripherals used

Every part in the Act II bill of materials is exercised by the firmware:

Peripheral	Role	Where it is used
Red, yellow, green LEDs	Tri-color access-gate annunciator	`status_led.c` drives exactly one lamp per state
Request-to-exit button (GP15)	Life-safety egress	`button.c` consumes one debounced press in `monitor_handle_rex`
1602 I2C LCD	Access log readout	`display.c` renders the formatted lines over I2C1
DHT11 (GP4)	Vault environmental interlock	`sensor.c` reads the one-wire frame and gates the release
SG90 servo (GP14)	Deadbolt actuator	`servo.c` locks and unlocks the deadbolt
1000uF capacitor	Bulk decoupling on the servo 5V rail	Required to keep the RP2350 from browning out on servo moves
VS1838B IR receiver (GP5)	Primary PIN input	`ir_remote.c` captures and decodes the frame
NEC IR remote	PIN keypad and ENTER/CLEAR	Sends digits `0x16` to `0x4A`, ENTER `0x46`, and CLEAR `0x45`
RYLR998 (UART1)	LoRa request and grant link	`radio.c` sends the sealed request and pumps inbound grants
Onboard GP25 LED	Onboard heartbeat	`monitor.c` toggles it every four monitor ticks in `monitor_heartbeat`
Debug Probe	SWD flashing and UART0 console	`stdio` is enabled on both UART0 `115200` and USB

Every Act II peripheral in the bill of materials is exercised by the firmware.

How the functionality works

Every input feeds the state machine in monitor_step, every output is driven once per tick, and the interactive console mirrors both over UART0 and USB. This is what each surface does at run time.

Inputs

Input	What it does when you use it
Infrared remote (GP5)	A decoded NEC frame prints `IR <NAME> (0xNN)` and is applied: digits `0x16` to `0x4A` push onto the PIN accumulator, `0x46` latches a full PIN and sends a sealed request, and `0x45` clears it.
Push button (GP15)	A debounced press prints `BUTTON request-to-exit -> release check` and opens the deadbolt for the bounded hold, unless the vault interlock is out of band.
DHT11 (GP4)	The vault interlock is sampled when a release is attempted; a good read prints a live status line, and a failed read prints `SENSOR read failed -> WARNING` and denies.
RYLR998 (UART1)	Each inbound `+RCV` frame prints `RX from 0xNNNN, N bytes` and is offered to the sealed reply path.

Outputs

Output	What it shows
Red, yellow, green LEDs	Exactly one solid lamp per state, red DENIED, yellow PENDING, green GRANTED, and all three dark at rest; `status_led.c` never blinks them.
1602 I2C LCD	`PIN:<pin> S:<seq>` on the first line and `STATE:<state>` on the second, refreshed every tick.
SG90 servo	The deadbolt, locked at 0 degrees and open at 90 degrees for the bounded hold.
Onboard GP25 LED	The heartbeat, toggled every four monitor ticks in `monitor_heartbeat`.

Watching the console

Open the UART0 console (Debug Probe) or the Pico's own USB serial port at 115200. The boot banner and control hint name the remote buttons and the push button:

=== OPERATION IRON GATE // ACT II ACCESS CONTROL ===
REMOTE: CH+ 0x47 spare | CH- 0x45 clear | CH 0x46 enter
KEYPAD: 0x16-0x4A digits | BUTTON: GP15 request-to-exit

While the gate runs, an interlock read prints one live status line and each event prints a named line:

INTERLOCK t=23 h=610 valid=1 LED=GRANTED seq=4
IR ENTER (0x46)
RX from 0x0001, 120 bytes
BUTTON request-to-exit -> release check
SENSOR read failed -> WARNING

The status line carries the sensor value (t and h), the annunciator state (LED), and the authorization sequence (seq). The event lines cover a decoded remote command, a button press, an inbound radio frame, and a failed sensor read.

Build and Flash

1. Install toolchain prerequisites

Pico SDK 2.2.0+
ARM GNU toolchain (arm-none-eabi)
CMake and Ninja
Python 3.x
GDB (arm-none-eabi-gdb) for the Lab 3 SRAM attack

Linux:

export PICO_SDK_PATH="$HOME/.pico-sdk/sdk/2.2.0"

macOS:

brew install cmake ninja arm-none-eabi-gcc python
export PICO_SDK_PATH="$HOME/.pico-sdk/sdk/2.2.0"

Windows: install PowerShell, Visual Studio Build Tools, CMake, Ninja, Python 3, and the ARM embedded toolchain.

2. Build the firmware

mkdir -p build && cmake -S . -B build -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s && cmake --build build

Build-time artifact guardrail:

The build regenerates packet_artifact.h from scripts/packet_artifact.json before compiling.
The build fails if the committed include/packet_artifact.h is stale relative to the JSON artifact.

Generated outputs:

build/access_gate.elf (primary firmware binary)
build/access_gate.uf2 (UF2 for BOOTSEL/picotool)
build/access_gate_app.elf / .uf2 (backward-compatible copies)

3. Flash the RP2350

BOOTSEL (drag-and-drop): hold BOOTSEL while plugging in USB, then:

cp build/access_gate.uf2 /Volumes/RP2350/

picotool:

picotool load build/access_gate.uf2 -fx

(If picotool is not on your PATH, invoke it from $HOME/.pico-sdk/picotool/*/picotool/picotool.)

Debug Probe (SWD): with openocd installed you can flash and reset without touching BOOTSEL:

openocd -f interface/cmsis-dap.cfg -f target/rp2350.cfg \
  -c "program build/access_gate.elf verify reset exit"

4. Watch the console

Open the UART0 console (Debug Probe) or the Pico's USB serial port at 115200. On reset you should see:

BOOT
I2C scan:
  found 0x27
=== OPERATION IRON GATE // ACT II ACCESS CONTROL ===
REMOTE: CH+ 0x47 spare | CH- 0x45 clear | CH 0x46 enter
KEYPAD: 0x16-0x4A digits | BUTTON: GP15 request-to-exit

found 0x27 confirms the LCD backpack answered on the I2C bus, and the banner confirms the state machine reached its ready policy. If a peripheral fails, the firmware prints INIT FAIL and stops.

Lab 1: Bring-Up and Verify

Goal: prove the gate reads the interlock, drives the LCD, takes a PIN, reaches the desk, and moves the deadbolt.

Wire the node per the pin map and attach the antenna.
Build and flash the firmware.
Connect the desk radio to the laptop and find its port (/dev/cu.usbserial-* on macOS, /dev/ttyUSB* on Linux).

Start the security desk:

python3 scripts/gateway.py --port /dev/cu.usbserial-XXXX --baud 115200

Type a six-digit PIN on the IR remote and press ENTER. The gate seals a request and the desk prints it, then answers with a sealed grant:
```
+OK
+OK
+RCV=7,92,<92 hex characters>,-11,10
GRANT seq=1 pin=482190
```
The gate turns yellow (PENDING), receives the grant, verifies the state tag and the anti-replay window, checks the interlock, then turns green (GRANTED) and opens the deadbolt for five seconds before sealing again.

Checkpoint: the LCD shows PIN:482190 S:0001 and STATE:GRANTED, the green LED is lit during the release, and access_log.csv gains one row per request:

utc,sender,auth,pin,rssi_snr
2026-09-20T09:30:05+00:00,7,OK,482190,"-11,10"

Theory check: why does a successful grant prove the LCD initialized? Because monitor_init() only returns true when every peripheral, including the LCD, is ready; otherwise main prints INIT FAIL and never enters the loop.

Lab 2: Inspect the Wire Protocol

Goal: see the sealed envelope and the declared-length rule in action.

Capture a full +RCV line from the console or the desk log.
Confirm the declared length equals the number of hex characters between the second comma and the RSSI field.
Split the hex into three parts: the first 48 hex characters are the 24-byte nonce, the last 32 are the 16-byte tag, and everything between is the ciphertext of the request or grant body.
Locate the payload, its declared length, and the two tail fields in scripts/gateway.py (_rcv_parts and _split_payload), and explain why finding the first comma would be a bug.
Challenge: for the grant body, identify the four bytes of the sequence number and the sixteen bytes of the state tag.

Checkpoint: you can explain why a frame must be sliced by the number in the declared length field, not by delimiter counting, and why a hex envelope is even safer than comma-bearing JSON.

Lab 3: The Red Half

Goal: get in using the gate's own flaws, with no key. Four attacks, each one demonstrating a defect that Lab 4 then seals.

Attack A: replay a captured grant

Run the legitimate loop and capture one sealed grant hex string from the desk console.

Replay it with the spoof tool in replay mode:

python3 scripts/spoof.py --port /dev/cu.usbserial-ATTACK --victim 7 --mode replay --capture <captured hex>

On the naive gate the replayed grant opens the deadbolt again, because the tag is genuine and nothing tracks freshness.

The lesson: authentication is not freshness. A captured valid frame is still a valid frame until the gate keeps state.

Attack B: forge a grant

Inject a structurally plausible grant with a random nonce and a random tag:

python3 scripts/spoof.py --port /dev/cu.usbserial-ATTACK --victim 7 --mode bad-tag --seq 99

The naive gate accepts it because it only checks the grant flag. The hardened gate rejects it because the spoof tool holds no field key and cannot produce a tag that verifies.

The lesson: a grant is data, and data without a key is a suggestion.

Attack C: flip the SRAM verdict with GDB

This is the centerpiece. The cryptography is perfect, and the verdict lives unprotected in SRAM.

Start the gate and halt it under the Debug Probe:

arm-none-eabi-gdb build/access_gate.elf
(gdb) target extended-remote /dev/cu.usbmodemXXXX
(gdb) monitor reset halt

Break in monitor_grant_release and inspect the authorization record:
```
(gdb) p g_auth
(gdb) set g_auth.granted = 1
(gdb) continue
```
On the naive gate the deadbolt opens. On the hardened gate, auth_state_ok recomputes the state tag over the modified record, finds that granted no longer matches the tag, and denies before the bolt moves.

The lesson: the wire is authenticated, the verdict is not, unless you tag the state. This is the TOCTOU failure in one GDB session.

Attack D: walk through request-to-exit

Press the request-to-exit button with no badge and no desk grant.
The deadbolt opens. This is not a bug. It is a deliberate, defensible life-safety egress path: a person inside the vault must always be able to leave, even in a fire, even if the desk is down, even if every key is lost.
Note what that means for the audit trail: the access log shows a release with no badge, because the design accepts local egress over remote authority.

The lesson: security decisions and safety decisions can conflict, and the right answer is to name the trade-off and contain it, not to "fix" it closed.

Hardening checklist for the red half

Reject any grant whose sequence is not strictly newer than the last accepted one.
Verify a keyed tag before trusting the grant flag.
Authenticate the authorization record itself before acting on the verdict.
Rate-limit and lock out the keypad so a four-to-six digit PIN is not a brute force target.
Lock the debug port in production and treat the probe as an attacker.
Log unauthenticated attempts distinctly instead of discarding them.

Lab 4: The Blue Half

Goal: seal the gate so the red half cannot be done to you. Each control maps to an attack in Lab 3.

1. Anti-replay window

src/auth.c holds last_seq, the highest sequence ever accepted. auth_apply_grant requires seq > last_seq before it will do anything else. A captured GRANTED frame fails on second use even though its tag is valid. Re-run Attack A: the replayed grant now lands on the DENIED lamp and the bolt does not move.

2. Authenticated state tag

auth_state_tag seals a ten-byte record (granted, pending, seq[4], last_seq[4]) under the field key with a deterministic nonce built from the sequence and the 0xA6 domain byte. auth_state_ok recomputes and compares in constant time. Re-run Attack C: the debugger write is detected and denied.

3. Debug-port lockdown

The probe that fixes the firmware is the probe that breaks it. In production, burn the RP2350 secure-boot and debug-disable settings in OTP so SWD cannot read or write SRAM on a deployed gate. In the lab, this is a discussion control: the authenticated state tag is what makes a compromised debug port survivable.

4. Rate limiting and lockout

A six-digit PIN is one million combinations, and the keypad is a physical, unauthenticated input. Add a failed-attempt counter and a lockout window in the monitor policy, and log lockouts distinctly. Brute force is a real attack on a door in a way it is not on a signed protocol.

5. Fail-secure policy

The deadbolt is sealed at initialization and on every failure path. Loss of power, a failed sensor read, a malformed grant, a write to the verdict, or a lost radio link all leave the bolt locked, because the release is an affirmative action that must be authorized. Compare this to the life-safety egress, which is fail-safe by design. The single most important blue-half lesson is that fail mode is a deliberate policy choice, and the two halves of a door (security ingress, life-safety egress) can require opposite defaults.

The blue-half checklist

Anti-replay: strictly monotonic sequence window.
Authenticated state: keyed tag over the authorization record.
Debug-port lockdown: OTP debug disable on the deployed part.
Lockout: failed-attempt counter and cooldown on the optical pad.
Fail-secure: sealed on power loss and every fault.
Designed egress: request-to-exit stays unauthenticated, documented, and logged.
Key lifecycle: separate the field key and the desk key, provision from OTP, and rotate on a schedule.

Troubleshooting

Symptom	Likely cause	Fix
No `BOOT` on the console	Wrong console pins / not reset	Check UART0 GP0/GP1 or USB; press RESET
`INIT FAIL` with no `0x27` in the scan	LCD not answering	Check LCD VCC=3.3V, SDA=GP2, SCL=GP3, contrast pot
LCD shows blocks / nothing	Contrast or address	Turn the backpack contrast pot; confirm address `0x27` vs `0x3F`
Interlock always denies	DHT11 not reading	Check DATA=GP4; add 10K pull-up to 3.3V; wait 1-2 s after power-up
IR remote does nothing	Receiver wiring or remote protocol	Check OUT=GP5, VCC=3.3V; confirm the remote is NEC-compatible
PIN will not latch	Fewer than six digits, or a consumed PIN	Enter exactly six digits, then ENTER; a consumed PIN must be entered again
`AT+SEND` sent but desk sees nothing	Radio unpowered / wrong band	Power VDD, attach antenna, use matching band modules
Desk sees nothing but `+OK`	Address/network mismatch	Confirm desk radio provisioned to `AT+ADDRESS=1`, `AT+NETWORKID=18`
`access_log.csv` stays empty while `+RCV` prints	Desk parser regression	Ensure `_split_payload` checks the comma at the declared length
Gate shows PENDING forever	No grant arrived before the wait	Confirm the desk replied and the gate radio address matches the reply target
Grant rejected on the gate	Tag, window, or interlock	Check the field key matches, the sequence is newer, and the vault is in band

Testing Philosophy and Coverage

Hardware bugs are expensive to find on the bench, so the firmware is written so that almost all of it can be tested on the host. The suite compiles the real src/*.c files against mock Pico SDK headers (test/mock/), replacing GPIO, I2C, UART, and time with deterministic fakes.

The mock GPIO can replay a recorded DHT11 waveform as an absolute time/level timeline, so the exact edge-timing decoder is exercised without a sensor.
The mock I2C records every LCD byte, so rendered text can be decoded and asserted.
The mock UART records outbound AT+SEND bytes and injects inbound +RCV lines, so the keypad-to-desk-to-deadbolt path runs end to end with no radio.

Run the native test suite:

python3 scripts/run_tests.py

Or configure via CMake and CTest:

cmake -S test -B build-test -G Ninja && cmake --build build-test && ctest --test-dir build-test --output-on-failure

The suite has 113 cases and 357 checks covering the full DHT11 waveform and every timeout shape, the keypad accumulator and its ready-before-consume guard, the NEC decoder and its malformed, ambiguous, and timeout shapes, the authorization window and state tag, the declared-length parser with hex-bearing payloads, and monitor ticks for request, grant, replay, tamper, interlock-fail, and deadline paths.

Verify 100% line coverage of owned firmware modules:

python3 scripts/check_coverage.py

The harness itself is a small in-repo framework (test/harness/) so the repo vendors no third-party code and every owned file obeys the coding standard.

Generating Packet Artifacts

scripts/gen_packet.py writes the build-time generated header from the JSON artifact:

scripts/packet_artifact.json is the source of truth.
include/packet_artifact.h is the generated header, committed for the build guardrail.

Why these constants are compiled into firmware:

The RP2350 firmware has no runtime JSON parser or filesystem on this path.
include/packet_artifact.h is generated from the JSON so the frame size, node id, desk address, PIN length, authorization wait, servo pulses, DHT timeout, and provisioning constants are embedded in flash.
This is provisioned data; regenerate whenever you rotate node identity, desk addressing, or key material.

To sync the committed header from the JSON artifact:

python3 scripts/gen_packet.py --from-json scripts/packet_artifact.json --header-out include/packet_artifact.h

The check_packet_artifact_header CMake target fails the build when the committed header is stale.

Code Standards

This repository enforces unusually strict standards because the point is to teach disciplined embedded and tooling practice, not just working code.

C standard

Every function body has no blank lines.
Every function body is at most eight lines (Doxygen comment blocks and lone braces excluded).
Every file, function, macro, type, and struct member carries Doxygen @brief documentation.
Naming: snake_case files/functions, UPPER_SNAKE macros, snake_case_t types.

Run the C audit:

python3 scripts/audit_c_standard.py

Python standard

Strict PEP8, four-space indents, snake_case, 79-character lines.
Every function has a NumPy-style docstring.
Every function executable body is at most eight lines, with no exceptions.
No blank lines inside function bodies.

Run the Python audit:

python3 scripts/audit_python_standard.py

Both audits must report nothing.

Project Layout

src/main.c: firmware entry point
src/monitor.c: state machine tying keypad, auth, deadbolt, interlock, and radio together
src/keypad.c: NEC command to PIN accumulator with a ready-before-consume guard
src/auth.c: authorization record, monotonic anti-replay window, authenticated state tag
src/sensor.c: DHT11 one-wire sampling and vault interlock classifier
src/display.c: 1602 LCD rendering over the PCF8574 I2C backpack
src/radio.c: RYLR998 provisioning, AT-command interface, and +RCV parser
src/status_led.c: red/yellow/green DENIED/PENDING/GRANTED annunciator
src/button.c: debounced request-to-exit input
src/servo.c: 50 Hz PWM deadbolt actuator
src/ir_remote.c: VS1838B edge timing and NEC badge/keypad decoder
src/crc.c: CRC-16/CCITT-FALSE helper
src/chacha20.c, src/poly1305.c, src/crypto_aead.c, src/blake2b.c, src/argon2.c, src/crypto_kdf.c, src/envelope.c: the in-repo cryptographic stack
include/access_gate.h: board-level pin and provisioning configuration
include/auth.h, include/keypad.h: authorization and keypad interfaces
include/field_secrets.h: lab-only committed key material
include/packet_artifact.h: generated packet artifact header
test/test_access_gate_and_security.c, test/test_peripheral_and_crypto.c: comprehensive test suites
test/mock/: Pico SDK hardware mocks (GPIO, I2C, UART, timer)
test/harness/: minimal in-repo test harness (strictly C-standard compliant)
scripts/gateway.py: security desk with radio provisioning, authentication, CSV logging, and sealed grant replies
scripts/spoof.py: forged and replayed grant injection client
scripts/sim_edge.py: laptop gate-node simulator
scripts/field_crypto.py: pure-Python interoperable crypto
scripts/gen_packet.py / scripts/packet_artifact.json: packet artifact generator and source
scripts/run_tests.py, scripts/check_coverage.py: test runner and coverage report
scripts/audit_c_standard.py, scripts/audit_python_standard.py: code-standard auditors
scripts/gen_banner.py: banner generator
paper.typ / paper.pdf: classroom paper describing the protocol and exercise
.github/workflows/release.yml: tag-driven UF2 release workflow

Glossary

AEAD: authenticated encryption with associated data; one operation for secrecy and integrity.
Anti-replay window: a monotonic sequence rule that rejects a valid frame that has already been used.
Argon2id: the memory-hard password hash (RFC 9106) used to derive the field key.
AT command: a short ASCII command (AT+...) understood by the radio.
Authorization: whether an authenticated party is allowed to act now.
Authentication: proving who a party is.
CRC: cyclic redundancy check, a checksum for detecting corruption.
Declared length: the byte count the sender claims for a payload; the receiver slices exactly that many characters.
Desk key: the authorization authority under which the state tag is computed.
DHT11: a low-cost temperature/humidity sensor using a custom one-wire protocol, used here as the vault interlock.
Fail-secure: a fault leaves the door locked. Fail-safe: a fault leaves the egress passable.
Field key: the key that seals frames on the wire.
HD44780: the character-LCD controller inside a 1602 module.
I2C: a two-wire bus (SDA/SCL) used here for the LCD backpack.
LoRa: a long-range, low-power sub-GHz radio modulation.
NEC: the infrared remote encoding the VS1838B decodes.
PCF8574: an I2C I/O expander that drives the LCD's parallel interface.
Request-to-exit (REX): the deliberately unauthenticated life-safety egress button.
RSSI / SNR: received signal strength and signal-to-noise ratio reported with each +RCV frame.
State tag: a keyed tag over the authorization record that detects a tampered verdict.
TOCTOU: time-of-check to time-of-use; a decision checked in one state and trusted in another.
UART: a serial port used to talk to the radio.
XChaCha20-Poly1305: the AEAD used for every sealed frame, with a 192-bit nonce and a 128-bit tag.

License

MIT License
