Hello again, friend.

Act I was the lie. Act II was the door. Act III was the payload. This is the payload that refuses to die.

WHITEOUT neutralized the valve implant. The crew erased the payload sector, patched the re-install check, reflashed the controller, and watched it come back. Not on the same board. On the next one. The HVAC automation node that feeds the clean room where NorthPharma compounds the cold medicine, and the implant had already learned the lesson of the last act.

It hides a copy of itself in a reserved flash sector. On every boot it reads that sector, finds its own marker, and re-installs the beacon and the bomb. You can reflash the firmware all day; the payload returns. It also wears a rootkit. It masks its own beacon from the BMS display and the maintenance log, so the operator reads a clean node while the radio is still talking.

NorthPharma is the Ministry's front. FROSTLINE wrote the persistence.

Do not trust the clean screen. Read the reserved sector. Then remove it for good.

The baffle is holding. That is exactly why you should be afraid.

THE SYSTEM

NorthPharma does not only move cold medicine. It moves the air that keeps the medicine cold: the clean room, the reagent store, the chilled corridor where a few degrees decide whether a batch is medicine or waste. The HVAC automation node is the hand on that air. It reads the room, it compares the room to a setpoint, and it drives a baffle.

An HVAC node is a simple machine. A climate sensor reports the room, the BMS gateway authorizes a setpoint, the controller decides, an actuator moves the baffle, and an annunciator says whether the space is nominal. The failure that matters is not a wrong number on a screen. It is a baffle that closes when no one asked, or a setpoint that drifts while the display insists the space is fine.

The node in this repository is that hand. On a breadboard it is a toy: a Pico 2, a servo that acts as the baffle, a DHT11 that stands in for the room climate sensor, an infrared remote that is the local override, a button that is the manual override, a 1602 LCD that is the BMS readout, three lamps, and a radio.

Nothing about it looks broken. That is the horror of Act IV. The code compiles, the tests pass, the annunciator is green, and there is an implant inside it that survives the exact procedure that was supposed to remove it.

THE STAKES

Act I was a lie about temperature. Act II was a lie about people. Act III was a lie about machinery. Act IV is a lie about remediation, and it is the first lie that tells you it is gone.

The node is weaponized, not buggy. A hidden implant beacons over LoRa on a timer, and a logic bomb re-arms on every boot and closes the baffle on its own schedule. Close a baffle on a live clean room and the room runs hot; the process does not care that the firmware passed its tests.

And here is the part that keeps the responders awake. The setpoint command path is already authenticated. The cryptography is real and it is correct. The implant does not break the cipher. It does something worse: it re-installs itself from a reserved flash sector, and it hides from the operator while it does it. You cannot patch a protocol if the attacker is already inside the protocol, and you cannot uninstall a payload with the same reflash the payload already survived.

That is not a clean node. That is a clean node with a tenant.

WHITEOUT

WHITEOUT is a resistance that does not exist on paper. It does not hold ground and it does not hold press conferences. It reads firmware. When NIGHTINGALE copied the shipping image and went quiet, the crew kept pulling the thread. The gate led to the pipeline. The pipeline led to the plant, and the plant led to the air.

NIGHTINGALE is still the thread. Her last verified copy came off the valve controller, and it was clean. The thing that came after it was not. Somewhere between the build server and the rack, someone signed an HVAC image that carries a payload, and that image is holding a clean room right now.

WHITEOUT's job in Act IV is not to break in. It is to prove the machine is already broken, in writing, with a debugger and a disassembler, and then to remove the thing that does not belong and make the removal stick.

THE MACHINE

The firmware in this repository is the node's firmware. On a breadboard it is a toy: a Pico 2, an SG90 servo that is the baffle, a DHT11 that is the room climate sensor, a VS1838B infrared eye that takes a local override remote, a 1602 LCD BMS readout over I2C, red/yellow/green annunciator lamps, a manual override button, and an RYLR998 LoRa link to a BMS gateway.

Two things are open, and one thing is not what it seems. The optical surface takes an override command from any NEC remote, and it is not authenticated. The radio carries the sealed setpoint path, and it is authenticated correctly. The part that is not what it seems is the implant: a module compiled only under a build flag called SANDBOX_ONLY, invisible in the clean firmware, and present in the test and CTF builds. It beacons, it re-installs from a reserved sector, it hides from the display and the log, and it hides from the debugger.

The face of the thing is honest in the way that matters least. The lamps say HVAC ALARM, OVERRIDE PENDING, and HVAC NOMINAL with total confidence, and the LCD shows the setpoint, the link, and the beacon. None of it lies. A healthy machine can still be a hostile one.

THE JOB

You do not have to be a hero. You have to be thorough. The node is carrying a passenger that no design review admitted to, and the passenger has a backup. Find it, prove it, and take it out for good.

1. Bring it up. Build the clean firmware, wire the board, and confirm the node reads the room climate, takes a local override, reaches the gateway, and moves the baffle. Nothing looks broken because nothing is broken yet.
2. Hunt the malware. Build the SANDBOX_ONLY image and find the beacon, the logic bomb trigger, the rootkit masking branch, the anti-debug trap, and the reserved-sector persistence marker. A firmware reflash alone will not remove it.
3. Defuse it. Break the re-install on boot, expose the rootkit hiding, and step past the anti-debug with GDB so the implant cannot tell that a probe is attached. Then erase the reserved sector.
4. Fix the machine. Seal the setpoint command path so only an authorized gateway can move the baffle, make the local override ask for authorization instead of bypassing it, and make the node fail to a safe setpoint on a lost link.

This document is the manual for the job. Work it on a breadboard. When the green lamp is lit and the log says the node is clean, remember what it is: not a healthy machine. An occupied one.

Goodbye, friend.

A NOTE ON THE ROADMAP

This project is Act IV of OPERATION COLD IRON. Act I was the sensor (cold-chain-monitor). Act II was the door (access-gate). Act III was the valve (pipeline-valve-controller). Act IV is the air. All four are defended devices; the companion CTF repository ships the compromised one. The investigation lives here:

• OPERATION IRON LUNG CTF

The CTF is the red half, weaponized: six deep tasks, each with static analysis, a dynamic proof under GDB, a hardware demonstration, and an in-place, same-size patch. This repository is the defended device. The CTF repository is the breached one. The full story lives at github.com/mytechnotalent/hvac-automation-node.

---

WHERE THIS FITS: OPERATION COLD IRON

This repository is Act IV (IRON LUNG) of the ten-act OPERATION COLD IRON saga. The malware track began in Act III; here it becomes persistence. The full spine is in SAGA.md.

• Previous act: Act III, IRON VEIN, the pipeline valve controller, pipeline-valve-controller
• This act: Act IV, IRON LUNG, the HVAC automation node
• Next act: Act V, IRON WEB, industrial-tamper-system (forthcoming)
• Companion CTF: CTF_hvac-automation-node

THE MINISTRY

The Ministry runs the state: the surveillance, the cold chain, the gates, the pipelines, the air. NorthPharma is one of its deniable industrial fronts, and FROSTLINE is the contractor that does the work no Ministry letterhead will admit to. FROSTLINE did not break into this controller; it built the implant, taught it to survive a reflash, signed the image, and moved on. Against them is WHITEOUT, and the engineer who copied the first image, NIGHTINGALE. This act is one node of the Ministry's industrial edge. TELESCREEN, the surveillance backbone that watches it, comes after the ten.

An adversarial, evidence-based audit of this act, including its honest limitations, is in NATION-STATE-REVIEW.md.

How This Project Fits the Embedded Hacking Course

This repository is the Act IV capstone integration for the Embedded Hacking course. It reuses the entire Act I peripheral set so one breadboard serves the whole foundation, and it adds the concepts the later acts build toward: a payload that persists in a reserved flash sector, a rootkit that hides its own beacon from the operator, re-install on boot, and the blue-half controls that contain them.

Each earlier module teaches one peripheral or language concept in isolation; this project wires several of them into a single, tested product, and then teaches you to look at that product as an adversary sees it.

Embedded Hacking module	Concept you learn	Where it lives here
Week 1: Introduction, Ethics, Scoping	Authorized lab work	Every lab is self-contained and authorized by design
Week 3: RP2350 Architecture and Firmware Analysis	Bare-metal targets, ELF/UF2, SWD	Pico SDK build, build/*.uf2, Debug Probe flash via OpenOCD
Weeks 4-6: Variables, Integers/Floats, Static	Data types, GPIO	src/monitor.c state machine, LED on GP25
Week 7: Constants with 1602 LCD I2C	I2C bus, HD44780 commands	src/display.c
Week 9: Operators with DHT11	Bit operations, edge timing	src/sensor.c room climate sensor
Week 11: Structures and Functions	Modular design	include/*.h and src/*.c module boundaries
This project adds	Reserved flash sectors, boot-time re-install, rootkit hiding, UART AT driver, LoRa setpoint path, anti-replay, authenticated state, fail-safe policy, malware analysis, anti-debug evasion, strict testing	src/implant.c, src/baffle.c, src/control.c, src/hvac_auth.c, src/radio.c, scripts/gateway.py, scripts/spoof.py, test/

If you have not worked through Weeks 7 and 9 yet, do those first: this project assumes you are comfortable with I2C wiring and one-wire edge timing.

Learning Objectives

By the end of this chapter and its labs you will be able to:

• Explain why a control system must protect integrity, availability, and state together, and why a firmware reflash is not remediation when a payload has a copy of itself outside the firmware.
• Wire and drive a 1602 LCD through a PCF8574 I2C backpack and render a BMS status, setpoint, link, and beacon readout.
• Decode a VS1838B infrared receiver as a local override remote for OPEN, CLOSE, and CLEAR commands, and explain why an unauthenticated optical surface is still an attack surface and must not silently bypass authorization.
• Drive an SG90 baffle actuator with 50 Hz PWM and explain why a 1000uF bulk capacitor is not optional.
• Read a DHT11 room climate sensor and classify the room against a safe band before the baffle is allowed to move.
• Design a sealed setpoint command path over a sub-GHz LoRa link using a fixed-size envelope, a monotonic anti-replay window, and a keyed state tag.
• Analyze a persistent implant: locate the reserved-sector marker, explain the re-install on boot, find the rootkit masking branch, and read the anti-debug trap.
• Explain why erasing the reserved sector and patching the re-install check are both required, and why a firmware reflash alone is not enough.
• Defeat an anti-debug check under GDB by understanding the CoreDebug DHCSR register at 0xE000EDF0.
• Apply blue-half controls: sealed and authorized commands, an override that requests authorization, fail-safe behavior, and containment for the implant.
• Derive a key with Argon2id, seal every frame with XChaCha20-Poly1305, and read and run a native host test suite with hardware mocks and line coverage.

Prerequisites

• The Embedded Hacking breadboard (EHP2_bb.png) and parts list.
• Acts I to III are helpful but not required. See cold-chain-monitor, access-gate, and pipeline-valve-controller for the sensor, the door, and the valve. The pin map is identical, so one breadboard serves all four.
• Comfort with C, the Linux/macOS shell, and basic electronics.
• A Pico 2, a Debug Probe (recommended, and required for the malware lab), a 1602 LCD with PCF8574 backpack, a DHT11, the full Embedded Hacking kit (3 LEDs, 3 resistors, a push button, an SG90 servo, a 1000uF capacitor, and a VS1838B infrared receiver plus NEC remote), two RYLR998 modules, and one USB-to-TTL serial adapter.
• Toolchain: Pico SDK 2.2.0+, arm-none-eabi-gcc, CMake, Ninja, Python 3, GDB (arm-none-eabi-gdb) for Lab 3, and (optionally) typst to rebuild the paper.

Table of Contents

1. Background
2. System Architecture
3. The Wire Protocol
4. The Cryptographic Envelope
5. The FROSTLINE Implant
6. Hardware You Need
7. Wiring the Node
8. Build and Flash
9. Lab 1: Bring-Up and Verify
10. Lab 2: Inspect the Wire Protocol
11. Lab 3: The Malware Track
12. Lab 4: The Fix Track
13. Troubleshooting
14. Testing Philosophy and Coverage
15. Generating Packet Artifacts
16. Code Standards
17. Project Layout
18. Glossary
19. Further Reading
20. License

Background

Why HVAC automation control

An HVAC plant is a control loop with a room in it. A climate sensor reports the room, a BMS gateway authorizes a setpoint, a controller decides, an actuator moves a baffle, and a gateway logs what happened. The baffle is where the decision becomes physical. Everything interesting in building control happens in that transition from a number to a motion.

Three properties have to hold at once, and they are not the same property:

• Integrity. The setpoint that reaches the baffle is the setpoint the gateway authorized. Not a replay, not a forgery, not a stray value.
• Availability. The baffle is there when the room needs it. A jammed radio or a crashed controller can be as dangerous as a hostile one.
• State. The controller knows whether it is open, closed, moving, or faulted, and it does not trust a stale or tampered verdict.

Act IV adds a fifth property that no protocol can provide from the outside: persistence resistance. Removing the attacker's code once is not remediation if the attacker kept a copy that the removal did not reach.

Why integrity plus availability plus state matter

The classic naive controller collapses the three. It accepts any setpoint on the radio, it has no anti-replay window, and it keeps its verdict in plain SRAM. Act II showed what that costs a door. Act III showed the industrial version. Act IV adds the recovery failure:

• Integrity without exclusivity. The sealed setpoint path in this build is correct. XChaCha20-Poly1305 authenticates every frame, the sequence window rejects a replay, and the state tag detects a tampered verdict. None of that stops an implant that calls the actuator directly.
• Availability as the attack goal. A logic bomb does not need to steal anything. It needs to close a baffle at the wrong moment. Denial is the whole payload.
• State as the last line of defense. A keyed tag over the authorization record means a debugger that rewrites the record is caught before the actuator moves. It is the same lesson Act II taught, carried into the air handler.
• Persistence as the recovery trap. A payload that writes itself into a reserved sector and re-installs on boot turns the natural response into a loop. The fix is not only a patch; it is a patch plus the erasure of the copy.

The fix track in Lab 4 seals the command path, makes the local override request authorization, and makes the node fail to a safe setpoint. The malware track in Lab 3 breaks the re-install, exposes the rootkit, and removes the passenger that was never in the design.

Why ChaCha20 over AES on the RP2350

The RP2350 has no hardware AES engine; its accelerated crypto block covers SHA-256, not AES. A software AES implementation on this part is therefore both slower and riskier, because table-driven AES performs data-dependent memory accesses that create a cache-timing side channel. ChaCha20 is built only from addition, rotation, and XOR, with no data-dependent table lookups, so it is fast in portable C and has no comparable cache-timing surface. XChaCha20-Poly1305 is thus both the modern choice and the pragmatic one for this silicon. The full rationale, including the extended-nonce benefit, appears in The Cryptographic Envelope.

The two on-wire problems this project solves

1. Payloads that contain commas. The sealed body is carried as lowercase hex, but the +RCV framing still separates fields with commas. A naive receiver that splits the line on the first comma corrupts the frame. The correct discipline is the declared-length rule: slice exactly L characters after the second comma and require the next character to be a comma.
2. Telling a real command from a forged or replayed one. The controller records the sender address exactly as the radio reports it, and it trusts the bytes that arrive. The sealed envelope plus the stateful window are what close that gap.

Inter-Integrated Circuit (I2C)

I2C is a two-wire bus: SDA (data) and SCL (clock), each pulled up to the supply rail. A controller (the Pico) addresses a target by its 7-bit address and writes or reads bytes. The 1602 LCD backpack carries a PCF8574 I/O expander at address 0x27; the firmware bit-bangs the HD44780 nibble protocol over that expander. Pull-ups are mandatory: the firmware enables the internal ones and the backpack usually adds its own.

The DHT11 one-wire protocol

The DHT11 is a low-cost digital temperature and humidity sensor. In Act IV it is the room climate sensor: the node classifies the room against a safe band before it will move the baffle. It speaks a custom single-wire protocol:

1. The host pulls the line low for at least 18 ms (the start pulse), then releases it and enables its pull-up.
2. The sensor answers with an 80 us low, then an 80 us high handshake.
3. The sensor sends 40 bits. Each bit begins with a 50 us low, then a high pulse whose width encodes the value: about 26-28 us for a 0, about 70 us for a 1.
4. Five bytes follow: humidity integer, humidity decimal, temperature integer, temperature decimal, and a checksum equal to the low byte of their sum.

Reading it means timing edges on the order of tens of microseconds, so the firmware uses an 18 ms host pulse, a 50 us bit-classification threshold, and a 240 us per-edge timeout so a dead or unplugged sensor fails fast instead of hanging the loop. A reading that fails its checksum is never safe, and a valid reading outside 0.0 C to 40.0 C (the tenths band 0 to 400) is out of band. Either way, the room is not nominal.

Universal Asynchronous Receiver/Transmitter (UART) and AT commands

The RYLR998 is driven over a UART at 115200 baud using CRLF-terminated ASCII commands. The firmware writes AT+SEND=... and drains inbound +RCV=... lines. Because the radio is a separate processor, its configuration (address, network identifier, band) persists until changed; the controller and the gateway each provision their own radio at start-up so they agree before any command traffic flows.

Cyclic Redundancy Check (CRC)

src/crc.c implements CRC-16/CCITT-FALSE (poly = 0x1021, init = 0xFFFF, check value 0x29B1 for "123456789"). It is provided as a reusable integrity diagnostic and exercised by the test suite. It is not part of the LoRa frame in this project; the lesson is the absence of authentication, not the absence of a checksum.

System Architecture

There are four roles:

Role	Runs on	Job
HVAC node	Pico 2 firmware	Decodes the infrared override remote, verifies sealed gateway SETPOINT commands, annunciates OVERRIDE PENDING, checks the room climate sensor, drives the baffle, enforces the manual override, and renders the BMS readout
BMS gateway	laptop + USB-TTL radio	Authenticates every request, logs it to hvac_log.csv, decides authorization, and answers with a sealed SETPOINT command carrying a sequence and a state tag (scripts/gateway.py)
Edge simulator	laptop + USB-TTL radio	Pretends to be a node and sends sealed setpoint requests (scripts/sim_edge.py)
Attacker	laptop + USB-TTL radio	Impersonates the gateway, forges a command, or replays a captured command (scripts/spoof.py)

Data flow

+----------------------+                              +----------------------+
|  Pico 2 HVAC node    |        LoRa (sub-GHz)        |   BMS gateway        |
|  IR remote  -> GP5   |  AT+SEND=0001,<len>,<hex>    |  USB-TTL radio       |
|  DHT11      -> GP4   |----------------------------->|  scripts/gateway.py  |
|  Servo      -> GP14  |<-----------------------------|  hvac_log.csv        |
|  LCD     -> GP2/GP3  |  AT+SEND=<node>,<len>,<hex>  |  sealed command      |
+----------------------+                              +----------------------+

+----------------------+                              +----------------------+
|   Attacker laptop    |  forged or replayed command  |   (same HVAC node)   |
|   scripts/spoof.py   |----------------------------->|   rejects at the tag |
|  claims the gateway  |                              |   tag or seq window  |
+----------------------+                              +----------------------+

Firmware module map

File	Responsibility
src/main.c	Entry point: stdio_init_all, monitor_init, tick loop
src/monitor.c	State machine: I2C bus scan, override remote, gateway command, baffle motion, manual override, room climate sensor, BMS render
src/implant.c	SANDBOX_ONLY FROSTLINE implant: covert beacon, logic bomb, rootkit hiding, CoreDebug anti-debug, reserved-sector persistence and re-install
src/baffle.c	Baffle state machine: bounded travel, open/closed/fault/moving, fail safe
src/control.c	Sealed SETPOINT command path: open, authorize, guarded setpoint command
src/hvac_auth.c	Authorization record, monotonic anti-replay window, authenticated state tag
src/sensor.c	DHT11 one-wire sampling and room-climate-band classifier
src/display.c	HD44780 driver over the PCF8574 backpack and BMS status rendering
src/radio.c	RYLR998 provisioning, AT+SEND builder, +RCV parser, line pump
src/status_led.c	Red/yellow/green HVAC ALARM / OVERRIDE PENDING / HVAC NOMINAL annunciator
src/button.c	Debounced manual override button around the internal pull-up
src/servo.c	50 Hz PWM baffle actuator
src/ir_remote.c	VS1838B edge timing and NEC override remote decode
src/chacha20.c	ChaCha20 stream cipher and HChaCha20 subkey derivation
src/poly1305.c	Poly1305 one-time message authenticator
src/crypto_aead.c	XChaCha20-Poly1305 seal/open envelope
src/blake2b.c	BLAKE2b and the Argon2 variable-length hash H'
src/argon2.c	Argon2id core (BLAMKA, hybrid addressing)
src/crypto_kdf.c	Argon2id passphrase key derivation
src/envelope.c	Hex nonce/ciphertext/tag envelope codec
src/crc.c	CRC-16/CCITT-FALSE diagnostic
include/hvac.h	Pin map, bus, provisioning, implant addresses
include/implant.h	Implant beacon, arming magic, rootkit, anti-debug, persistence interface
include/control.h, include/hvac_auth.h	Sealed command and authorization interfaces

The Wire Protocol

Request frame

The local override, or the edge simulator, seals a two-byte setpoint into an authenticated envelope and sends it to the BMS gateway:

AT+SEND=0001,<len>,<hex envelope>

The plaintext of a request is exactly two bytes: an int16 setpoint in tenths of a degree Celsius, little-endian.

Command frame

The gateway answers an authenticated request with a sealed SETPOINT command. The command plaintext is a 23-byte body:

seq[4] (little-endian) || cmd[1] || setpoint[2] (little-endian) || state_tag[16]

• seq is the monotonic gateway sequence number.
• cmd is HVAC_COMMAND_SETPOINT (0x01). It is the only guarded command.
• setpoint is the authorized setpoint in tenths of a degree Celsius.
• state_tag is an XChaCha20-Poly1305 tag over the authorization record the command would produce, so the controller can verify that the verdict it is about to store is the one the gateway authorized.

The gateway sends it back to the claimed sender address:

AT+SEND=<node>,<len>,<hex envelope>

The firmware enforces the guard in control_parse: the recovered command byte must equal HVAC_COMMAND_SETPOINT, and the recovered setpoint must be inside the provisioning band HVAC_SETPOINT_MIN_TENTHS (50 tenths, 5.0 C) to HVAC_SETPOINT_MAX_TENTHS (350 tenths, 35.0 C). Anything else is rejected before it can reach the actuator decision. This is the sealed replacement for the old unauthenticated setpoint injection.

Sealed envelope layout

Every payload on the wire is the lowercase hexadecimal encoding of:

nonce[24] || ciphertext[L] || tag[16]

For a two-byte request body this is 24 + 2 + 16 = 42 bytes, or 84 hex characters. For a 23-byte command body this is 24 + 23 + 16 = 63 bytes, or 126 hex characters. The declared length L in the AT+SEND and +RCV framing is the length of the hex string, not of the underlying plaintext.

The maximum accepted plaintext is 48 bytes (ENVELOPE_MAX_PLAINTEXT), and the maximum hex envelope buffer is (24 + 48 + 16) * 2 + 1 = 177 bytes (ENVELOPE_MAX_HEX_LEN), which fits the 256-byte radio command and receive buffers with framing headroom.

Declared-length slicing invariant

Given the substring T after the second comma:

C = T[0 : L]   and   T[L] == ","

The receiver checks T[L] == ",", so a mismatch between the declared length and the actual payload is a parse error rather than silent corruption. This is what makes hex-bearing payloads safe to carry and is the same invariant Act I uses.

BMS status readout

ST:OPEN  L:UP
SP:20.0 B:--

Line 1 is the current baffle state (CLOSED, OPEN, MOVING, or FAULT) and the gateway link (UP or --). Line 2 is the active setpoint and the beacon status. In the clean build the beacon field is always --. In the SANDBOX_ONLY build the beacon field is -- while the rootkit is active and UP otherwise, so a masked beacon and an absent beacon are visually identical to the operator. Exactly one status LED is lit at a time to match: red for FAULT, yellow while an override is pending or the baffle is moving, green while the node is nominal.

Radio provisioning

For the link to work, both radios must share the same network identifier and each must have the address the other targets:

• Firmware sets its own radio: AT+ADDRESS=7, AT+NETWORKID=18.
• gateway.py sets the gateway radio: AT+ADDRESS=1, AT+NETWORKID=18.

Both radios must also be the same band variant (for example 915 MHz or 868 MHz); band and RF parameters are left at factory defaults, so use matching modules.

Timing

Quantity	Value
Gateway link timeout (HVAC_SETPOINT_WAIT_MS)	5000 ms
Baffle travel time (BAFFLE_TRAVEL_MS)	1000 ms
Manual override debounce (OVERRIDE_DEBOUNCE_US)	30000 us
DHT11 host start pulse	18000 us
DHT11 bit threshold	50 us
DHT11 per-edge timeout	240 us
LCD I2C clock	100000 Hz
Radio UART baud	115200
Room climate band	0 to 400 tenths (0.0 C to 40.0 C)
SETPOINT band	50 to 350 tenths (5.0 C to 35.0 C)
Safe setpoint	200 tenths (20.0 C)
Baffle deadband	5 tenths
Servo closed pulse	500 us
Servo open pulse	1500 us
Servo PWM period	20000 us (50 Hz)
Implant beacon interval	8 ticks
Implant trigger delay	3 ticks

The Cryptographic Envelope

The radio is the first open path, and it is one a key can close. The fix is authenticated encryption: every request and every command is sealed so a forged frame dies at the authentication tag instead of moving the baffle. The full implementation lives in src/chacha20.c, src/poly1305.c, and src/crypto_aead.c, and every primitive is checked against its published test vectors in the native suite.

Why XChaCha20-Poly1305

• 256-bit key, 192-bit nonce. The extended nonce means nonces can be drawn at random forever, so the controller never needs a shared counter that a reboot could reuse.
• AEAD in one pass. Confidentiality and integrity come from one operation; the associated data (the HVAC node id, byte 0x07) is authenticated even though it is not encrypted.
• Constant-time software. ChaCha20 has no data-dependent table lookups, so it has no cache-timing surface. The RP2350 has no hardware AES engine (it accelerates SHA-256 only), which makes software AES both slower and riskier on this silicon.
• 128-bit Poly1305 tag. Guessing a valid tag succeeds with probability $2^{-128}$.

Why Argon2id

A passphrase is not a key. Argon2id (RFC 9106) is the memory-hard password hash: it mixes the passphrase with a salt across memory and time so an attacker cannot cheaply recover the field passphrase from a captured image. The classroom profile is t=3, p=1, m=64 blocks (CRYPTO_KDF_TIME_COST, CRYPTO_KDF_PARALLELISM, CRYPTO_KDF_MEMORY_BLOCKS) to fit the RP2350 SRAM budget. Raise it on the BMS gateway. The lab salt is the 16 ASCII bytes coldiron-salt-01.

Key model: one field key

Act IV uses a single field key derived with Argon2id from a committed lab passphrase and salt. It seals every frame on the wire and it computes the state tag over the authorization record. In the classroom build the firmware and the gateway derive the same key, so they interoperate with no provisioning step. That is a lab convenience, not a deployment.

The design keeps the key roles separable so students can reason about the real lifecycle: derive, provision per device, use, rotate on a schedule, and retire. A production build provisions key material from one-time-programmable (OTP) memory, keeps the state-tag key off the field device where possible, and rotates without reflashing every controller.

Envelope layout

The sealed frame is carried as hex inside the AT+SEND payload:

nonce[24] || ciphertext[L] || tag[16]

The receiver recomputes the Poly1305 tag over the associated data and ciphertext, compares it in constant time, and only then decrypts. This envelope is wired end to end: src/control.c opens the command with src/envelope.c, and the gateway authenticates before it parses or acts. Authenticated frames carry the HVAC node id as associated data, so a frame sealed for one node cannot be relabeled for another.

Anti-replay and authenticated state

Strong AEAD is necessary and not sufficient. Two stateful controls sit on top:

• Anti-replay sequence window. src/hvac_auth.c keeps last_seq, the highest sequence number ever accepted. hvac_auth_apply accepts a command only when its sequence is strictly greater than last_seq. A captured command, even a perfectly valid one, is rejected on second use.
• Authenticated state tag. The authorization record is nine bytes: granted[1], seq[4], last_seq[4]. The tag is an XChaCha20-Poly1305 tag over that record, computed under the field key with a deterministic nonce built from the sequence number and the domain byte 0xA7. hvac_auth_state_ok recomputes the tag and compares it in constant time before the baffle is allowed to move. A debugger that sets granted = true without recomputing the tag fails here first.

The sequence window and the state tag are independent. The window stops a valid command from working twice; the tag stops an unauthorized verdict from existing at all.

The FROSTLINE Implant

Act IV carries the persistence lesson, and the implant is the reason. It is real in technique and inert in effect: it runs on your breadboard, it moves your servo, and it writes to a reserved flash sector that holds nothing else. It is compiled only when SANDBOX_ONLY is defined, so the clean firmware image contains no implant at all. The test suite and the companion CTF build with SANDBOX_ONLY and with the host mock, so every implant path is exercised natively.

What the implant does, in the order the code does it:

1. First run and reserved sector. implant_init reads the marker byte at HVAC_IMPLANT_RESERVE_ADDR (0x103FF000), the final sector of external flash. On the first run the marker is absent, so the implant writes 0xC7 (IMPLANT_MARKER_BYTE) once and returns. On every later boot the marker is present, so the implant re-arms its logic bomb. A firmware reflash that writes the program region does not touch the reserved sector, so the payload comes back even when the code is gone.
2. Beacon. Every 8 ticks (IMPLANT_BEACON_INTERVAL_TICKS) the implant emits a covert frame to the local classroom hub. The frame is the 4-byte magic preamble DE AD BE EF (IMPLANT_BEACON_MAGIC) followed by a 4-byte synthetic status blob: the low and high bytes of the tick counter, the marker byte 0xC7, and a byte that reports whether a probe is attached. The beacon carries no real data and targets no external address.
3. Logic bomb. The implant arms when it sees the exact 8-byte magic command FROSTLNE (IMPLANT_ARM_MAGIC, the bytes 'F' 'R' 'O' 'S' 'T' 'L' 'N' 'E') on an inbound frame. It then detonates 3 ticks later (IMPLANT_TRIGGER_DELAY_TICKS) by calling the baffle close path directly, independent of the operator, the gateway, and the authorization record.
4. Rootkit hiding. implant_rootkit_active is true when the reserved-sector marker is present and no debug probe is attached. While the rootkit is active, monitor.c renders the beacon field as -- instead of UP and suppresses the BCN maintenance log line. The beacon still transmits. The operator sees a clean node while the radio is still talking, which is the whole point of a rootkit: it changes what the defender can see, not what the attacker does.
5. Anti-debug. Every tick the implant reads the CoreDebug DHCSR register at 0xE000EDF0 (HVAC_IMPLANT_DHCSR_ADDR). Bit 0 is C_DEBUGEN and bit 1 is C_HALT. If either bit is set, the implant returns early and suppresses the beacon and the bomb. It behaves like a well-mannered firmware module while a probe is attached, and it goes back to work the moment the probe is gone.

The implant is bounded by construction and by test. It touches only its own beacon radio frame, its arming latch, the servo close path, and the one reserved sector. There is no network, no filesystem, no host impact, and no real data. test_implant_init_first_run, test_implant_reinstall_on_boot, test_implant_persistence_present, test_implant_debug_attached, test_implant_handle_command, test_implant_beacon, test_implant_anti_debug, test_implant_logic_bomb, test_implant_persist_once, and test_implant_rootkit_guards assert exactly that behavior.

The honest limit is the point of the lab. A sanitized educational implant is still a benign educational implant: it demonstrates the technique, not the tradecraft. It is confined to the breadboard, guarded by SANDBOX_ONLY, and has no network; the reserved sector is on the same chip and holds nothing else. The real lesson is detection and complete removal, and the defense is not a patch to the implant but the erasure of the reserved sector plus the removal of the code path and the build flag that allowed it in.

Hardware You Need

Full parts list with links: PARTS.md.

Qty	Part	Notes
1	Raspberry Pi Pico 2 (RP2350) with headers	The HVAC controller
1	Raspberry Pi Debug Probe	SWD flashing, UART0 console, and the Lab 3 anti-debug/GDB work (recommended, effectively required)
1	Full-size breadboard
1	Assorted jumper wires
1	1602 LCD with PCF8574 I2C backpack	BMS status and setpoint readout, address 0x27
1	DHT11 temperature/humidity sensor	Room climate sensor
1	10K resistor	Only if your DHT11 has no onboard pull-up
3	5mm LEDs (red, yellow, green)	HVAC ALARM, OVERRIDE PENDING, HVAC NOMINAL annunciator
3	100, 220, or 330 Ohm resistors	One per LED
1	Push button (tactile switch)	Manual override, active low
1	SG90 servo motor	The HVAC baffle actuator
1	1000uF 25V capacitor	Bulk decoupling on the servo 5V rail
1	VS1838B infrared receiver	Local override remote input
1	NEC-compatible infrared remote	Local override OPEN, CLOSE, and CLEAR commands
3	RYLR998 LoRa modules with antennas	2 for the command loop, 3 for the live attack lab
2	USB-to-TTL serial adapters (FTDI FT232, CP2102, or CH340), 3.3V logic	1 for the gateway, 1 for the attacker in the live lab
4	USB cables	Pico 2, Debug Probe, and serial adapter(s)

How many radios do you actually need?

Goal	Radios	What is connected
Legitimate sealed setpoint loop (Labs 1-2)	2	1x RYLR998 on the Pico (UART1) + 1x RYLR998 on a USB-to-TTL adapter (the gateway)
Live attack lab (Labs 3-4, watch a forged command land and fail)	3	the 2 above + 1x RYLR998 on a second USB-to-TTL adapter (the attacker)
Attack concept with no extra hardware	2 or 0	read-and-run the offline parser demo, or the unit tests

A radio never receives its own transmission, and the gateway radio is busy listening as gateway.py, so the live attack needs a separate attacker radio. The 2-radio kit runs the whole legitimate system; only the live attack observation needs the third.

Serial adapter warning: the RYLR998 is not 5V tolerant. Use a 3.3V-logic USB-to-TTL adapter (or set its jumper to 3.3V).

How each part works

Every part in the bill of materials does one physical job and one job in this act:

Part	How it works	Role in this act
1x Full-size breadboard (long)	The two columns of spring-clip tie points sit on a 0.1 inch grid, so every hole in a row is bridged by a metal clip, while the two outer power rails run the full length and distribute power and ground to the whole build.	It is the substrate that holds the Pico 2, LCD, sensor, servo, and radio headers and distributes 3.3V and 5V across the node.
1x Assorted jumper wires (male-to-male, male-to-female, female-to-female)	Male pins push into breadboard tie points or female headers, female sockets slide over the Pico 2, LCD, and servo header pins, and male-to-female leads bridge a breadboard row to a module header.	They carry power and the I2C, one-wire, UART, PWM, IR, and GPIO signals between the boards.
1x Raspberry Pi Pico 2 with header	The RP2350 pairs two Arm Cortex-M33 cores with 3.3V logic and a GPIO block that exposes ADC, I2C, UART, and PWM, plus the onboard GP25 LED.	It is the HVAC controller that reads the room climate, treats the IR and button inputs as requests, drives the baffle servo and annunciator, and runs the sealed setpoint state machine.
1x Raspberry Pi Pico Debug Probe	It drives the two-wire SWD port (SWCLK and SWDIO) to flash and single-step the target, and it also presents a USB UART bridge for the serial console.	It flashes and debugs the node and is the instrument for the Lab 3 malware work and the fix.
2x USB A-male to USB micro-B cables	USB carries 5V power and a data channel on the same cable, so one cable powers the Pico 2 and presents its USB CDC console while the other powers the Debug Probe and carries its SWD and UART traffic.	They power the two boards and carry the console and debug links.
3x 5mm LEDs (1 red, 1 green, 1 yellow)	An LED is a diode with a forward voltage drop of roughly 2V, so current flows only from the anode to the cathode, and a GPIO pin set high sources that current and lights the lamp.	They are the red HVAC ALARM, yellow OVERRIDE PENDING, and green HVAC NOMINAL annunciator, and exactly one is lit per state.
3x 100, 220, or 330 Ohm resistors	A resistor in series with each LED sets the current by Ohm's law, I equals (supply minus forward voltage) divided by resistance, which protects the LED and keeps the GPIO within its current limit.	One resistor per lamp limits the LED current on each of the three annunciator pins.
1x Push button (tactile switch)	The switch shorts its input pin to ground when pressed, and the RP2350 internal pull-up holds that pin high at rest so the press reads as active low.	It is the manual override request that raises OVERRIDE PENDING and never moves the baffle on its own.
1x 1602 LCD with PCF8574 I2C backpack	The HD44780 controller takes a 4-bit nibble protocol with register-select and enable strobes, and the PCF8574 I2C expander latches those eight control lines so the whole display is driven over two I2C wires at address 0x27.	It renders the BMS status and setpoint readout.
1x DHT11 temperature and humidity sensor	The host pulls the single data line low for a start pulse, then the sensor answers with 40 bits of humidity, temperature, and checksum timed by pulse widths, and the checksum must match.	It is the room climate sensor whose reading marks the space not nominal when it fails or leaves the 0.0 C to 40.0 C band.
1x SG90 servo motor	The servo expects a 50 Hz PWM signal whose high pulse of 1 to 2 ms selects the shaft angle, and a Pico PWM slice generates that pulse train.	It is the HVAC baffle actuator, seated closed at 0 degrees and open at 90 degrees.
1x 1000uF 25V capacitor	Wired across the servo 5V rail and ground, the capacitor is a bulk reservoir that supplies the motor inrush current and smooths the rail while the servo starts.	It keeps the baffle move from browning out the RP2350 and resetting the node.
1x Infrared (IR) receiver (VS1838B)	The receiver pairs a photodiode with a 38 kHz bandpass demodulator that ignores ambient light and outputs an active-low logic pulse for each IR burst.	It is the local override remote input on GP5.
1x Infrared (IR) remote controller (NEC-compatible)	The remote emits its bursts modulated at 38 kHz in the NEC frame, a 9 ms leader followed by 32 bits where the address and command are each sent with their bitwise complements for validation.	It is the local remote that raises the OPEN 0x01 and CLOSE 0x02 override requests and sends CLEAR 0x03.
1x RYLR998 LoRa radio module	The module is configured and driven over UART with AT commands and carries sub-GHz LoRa packets, and its logic pins are 3.3V only so the radio must never see 5V.	It is the UART1 command and status link that carries the sealed frames between the node and the BMS gateway, and it is not 5V tolerant.

Wiring the Node

Pin map

This is the authoritative map; it is identical to Acts I to III and is defined in include/hvac.h and enforced by the test suite.

Peripheral	Signal	Pico 2 GPIO
DHT11 room climate sensor	DATA (one-wire)	GP4
1602 LCD (PCF8574)	SDA (I2C1)	GP2
1602 LCD (PCF8574)	SCL (I2C1)	GP3
RYLR998	RX <- Pico TX (UART1)	GP8
RYLR998	TX -> Pico RX (UART1)	GP9
Infrared override remote	OUT (VS1838B)	GP5
Baffle servo	PWM signal	GP14
Red HVAC ALARM LED	anode	GP16
Yellow OVERRIDE PENDING LED	anode	GP17
Green HVAC NOMINAL LED	anode	GP18
Manual override button	to ground	GP15
Onboard LED	heartbeat	GP25
Debug Probe / UART0 console	TX	GP0
Debug Probe / UART0 console	RX	GP1

Note: GPIO 2/3 are the classic I2C1 pins used throughout the Embedded Hacking breadboard; this project's map matches that board because it is the same board.

1602 LCD with I2C backpack

LCD backpack	Pico 2
VCC	3.3V
GND	GND
SDA	GP2
SCL	GP3

DHT11 room climate sensor

DHT11	Pico 2
VCC	3.3V
DATA	GP4
GND	GND

If your DHT11 has no onboard pull-up, add a 10K resistor between DATA and 3.3V. The firmware also enables the internal pull-up, but the external resistor makes reads far more reliable over jumper wires. The room is not nominal when the sensor fails or reads outside 0.0 C to 40.0 C.

Status LEDs

LED	Pico 2	Series resistor
Red (HVAC ALARM)	GP16 (anode)	220-330 Ohm to GND
Yellow (OVERRIDE PENDING)	GP17 (anode)	220-330 Ohm to GND
Green (HVAC NOMINAL)	GP18 (anode)	220-330 Ohm to GND

Exactly one lamp is lit at a time. Red is an HVAC alarm or a failed-safe latch, yellow is a pending override or a moving baffle, and green is a nominal space.

LED behavior

State	Lamp	Indication	Meaning
HVAC_OFF	none	All dark	Defined but never selected; the live state machine always drives alarm, pending, or nominal.
HVAC_ALARM	Red	Solid	Baffle fault or a failed-safe latch.
HVAC_OVERRIDE_PENDING	Yellow	Solid	An override request is pending or the baffle is travelling.
HVAC_NOMINAL	Green	Solid	The space is nominal and the baffle is seated or open.

The three annunciator lamps are always solid; status_led.c never blinks them. Exactly one lamp is lit at a time, and HVAC_OFF leaves all three dark. The onboard GP25 LED is initialized as an output and driven as a heartbeat: monitor.c toggles it every four monitor ticks in monitor_heartbeat, so a running node is visible even while idle.

Manual override button

Button	Pico 2
Leg 1	GP15
Leg 2	GND

The firmware enables the internal pull-up, so do not connect 3.3V to the button. The manual override is a local request, not an authorization: a press raises the OVERRIDE PENDING indication and never moves the baffle on its own. Lab 4 explains why the override must ask for authorization instead of silently bypassing it.

SG90 baffle servo

Servo	Pico 2
Signal (orange)	GP14
VCC (red)	5V (VBUS)
GND (brown)	GND

Solder the 1000uF capacitor across the servo 5V and GND rails to absorb the inrush current; without it the RP2350 can brown out when the baffle moves. Seated (closed) is 0 degrees and open is 90 degrees.

Infrared receiver

VS1838B	Pico 2
OUT	GP5
VCC	3.3V
GND	GND

Point any NEC-compatible remote at the receiver. In Act IV this is the local override remote, not a maintenance extra: the firmware decodes MONITOR_IR_OVERRIDE_OPEN (0x47), MONITOR_IR_OVERRIDE_CLOSE (0x45), and MONITOR_IR_OVERRIDE_CLEAR (0x46). There is no challenge and no secret on the optical surface, which is why an override command is treated as a request and not as an authorization.

Using the remote

Point the NEC remote at the VS1838B receiver on GP5 and press a mapped button; the receiver idles high and pulls low on a mark. Every valid frame prints IR <NAME> (0xNN) on the console and drives the override request path.

NEC command	Name	Action
0x47	MONITOR_IR_OVERRIDE_OPEN	Raises an override request (g_override_pending); it never moves the baffle on its own.
0x45	MONITOR_IR_OVERRIDE_CLOSE	Raises an override request (g_override_pending); it never moves the baffle on its own.
0x46	MONITOR_IR_OVERRIDE_CLEAR	Clears the pending override request (monitor_clear_override).

OPEN and CLOSE both raise the same pending request; the authorized command path decides the final baffle direction.

RYLR998 LoRa radio

The RYLR998 must be powered. Forgetting VDD is the single most common reason the link appears dead: the firmware prints while the radio sits silent.

RYLR998	Pico 2
VDD	3.3V
GND	GND
RXD	GP8 (Pico UART1 TX)
TXD	GP9 (Pico UART1 RX)

Attach the antenna before transmitting. TX and RX are crossed: the radio's RXD is the Pico's TX and vice versa.

Debug Probe (recommended)

Debug Probe	Pico 2
SWCLK	SWCLK (3-pin debug header)
SWDIO	SWDIO
GND	GND
UART TX	GP1 (Pico RX)
UART RX	GP0 (Pico TX)
GND	GND

The firmware enables stdio on both UART0 (115200) and USB, so you can watch boot output on the probe's console or on the Pico's own USB serial port. The Debug Probe is also the instrument for the Lab 3 malware work: it is how you watch the beacon, expose the rootkit, trigger the bomb, and step past the anti-debug trap.

Peripherals used

Every part in the Act IV bill of materials is exercised by the firmware:

Peripheral	Role	Where it is used
Red, yellow, green LEDs	Tri-color HVAC node annunciator	status_led.c drives exactly one lamp per state
Manual override button (GP15)	Local override request	button.c consumes one debounced press in monitor_handle_override
1602 I2C LCD	BMS status readout	display.c renders the formatted lines over I2C1
DHT11 (GP4)	Room temperature and humidity	sensor.c reads the one-wire frame every telemetry interval
SG90 servo (GP14)	Baffle actuator	servo.c drives the baffle open and closed
1000uF capacitor	Bulk decoupling on the servo 5V rail	Required to keep the RP2350 from browning out on servo moves
VS1838B IR receiver (GP5)	Local override remote input	ir_remote.c captures and decodes the frame
NEC IR remote	Override OPEN, CLOSE, and CLEAR	Sends 0x01, 0x02, and 0x03
RYLR998 (UART1)	LoRa command and status link	radio.c sends sealed frames and pumps inbound commands
Onboard GP25 LED	Onboard heartbeat	monitor.c toggles it every four monitor ticks in monitor_heartbeat
Debug Probe	SWD flashing, UART0 console, and malware analysis	stdio is enabled on both UART0 115200 and USB

Every Act IV peripheral in the bill of materials is exercised by the firmware.

How the functionality works

Every input feeds the state machine in monitor_step, every output is driven once per tick, and the interactive console mirrors both over UART0 and USB. The DHT11 is sampled every two seconds, so one live status line appears about every two seconds. This is what each surface does at run time.

Inputs

Input	What it does when you use it
Infrared remote (GP5)	A decoded NEC frame prints IR <NAME> (0xNN) and raises or clears a pending local override; it never moves the baffle on its own.
Manual override button (GP15)	A debounced press prints BUTTON manual override -> pending and raises the override-pending indication, which the authorized SETPOINT path must resolve.
DHT11 (GP4)	The room climate is sampled every tick; a good read prints a live status line, and a failed read prints SENSOR read failed -> WARNING.
RYLR998 (UART1)	Each inbound +RCV frame prints RX from 0xNNNN, N bytes and is offered to the sealed SETPOINT path.

Outputs

Output	What it shows
Red, yellow, green LEDs	Exactly one solid lamp per state, red ALARM, yellow OVERRIDE PENDING or MOVING, and green NOMINAL; status_led.c never blinks them.
1602 I2C LCD	ST:<state> L:<link> on the first line and SP:<setpoint> B:<beacon> on the second, refreshed every tick.
SG90 servo	The baffle, seated closed for no call for cooling and open when the room rises above the setpoint deadband.
Onboard GP25 LED	The heartbeat, toggled every four monitor ticks in monitor_heartbeat.

Watching the console

Open the UART0 console (Debug Probe) or the Pico's own USB serial port at 115200. The boot banner and control hint name the remote buttons and the push button:

=== OPERATION IRON LUNG // ACT IV HVAC ===
REMOTE: CH+ 0x47 open | CH- 0x45 close | CH 0x46 clear
BUTTON: GP15 manual override

While the node runs, a climate read prints one live status line and each event prints a named line:

ROOM t=23 h=610 ok=1 ST=CLOSED n=4
IR OPEN (0x47)
RX from 0x0001, 126 bytes
BUTTON manual override -> pending
SENSOR read failed -> WARNING

The status line carries the sensor value (t and h), the climate verdict (ok), the annunciator state (ST), and a running status count (n). The event lines cover a decoded remote command, a button press, an inbound radio frame, and a failed sensor read.

Build and Flash

1. Install toolchain prerequisites

• Pico SDK 2.2.0+
• ARM GNU toolchain (arm-none-eabi)
• CMake and Ninja
• Python 3.x
• GDB (arm-none-eabi-gdb) for the Lab 3 malware analysis

Linux:

export PICO_SDK_PATH="$HOME/.pico-sdk/sdk/2.2.0"

macOS:

brew install cmake ninja arm-none-eabi-gcc python
export PICO_SDK_PATH="$HOME/.pico-sdk/sdk/2.2.0"

Windows: install PowerShell, Visual Studio Build Tools, CMake, Ninja, Python 3, and the ARM embedded toolchain.

2. Build the firmware

The clean firmware does not define SANDBOX_ONLY, so it ships no implant:

mkdir -p build && cmake -S . -B build -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s && cmake --build build

To build the malware-track image with the implant compiled in, turn the option on:

cmake -S . -B build-sandbox -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s -DSANDBOX_ONLY=ON && cmake --build build-sandbox

Build-time artifact guardrail:

• The build regenerates packet_artifact.h from scripts/packet_artifact.json before compiling.
• The build fails if the committed include/packet_artifact.h is stale relative to the JSON artifact.

Generated outputs:

• build/hvac_automation_node.elf (primary firmware binary)
• build/hvac_automation_node.uf2 (UF2 for BOOTSEL/picotool)
• build/hvac_automation_node_app.elf / .uf2 (backward-compatible copies)

3. Flash the RP2350

BOOTSEL (drag-and-drop): hold BOOTSEL while plugging in USB, then:

cp build/hvac_automation_node.uf2 /Volumes/RP2350/

picotool:

picotool load build/hvac_automation_node.uf2 -fx

(If picotool is not on your PATH, invoke it from $HOME/.pico-sdk/picotool/*/picotool/picotool.)

Debug Probe (SWD): with openocd installed you can flash and reset without touching BOOTSEL:

openocd -f interface/cmsis-dap.cfg -f target/rp2350.cfg \
  -c "program build/hvac_automation_node.elf verify reset exit"

4. Watch the console

Open the UART0 console (Debug Probe) or the Pico's USB serial port at 115200. On reset you should see:

BOOT
I2C scan:
  found 0x27
=== OPERATION IRON LUNG // ACT IV HVAC ===
REMOTE: CH+ 0x47 open | CH- 0x45 close | CH 0x46 clear
BUTTON: GP15 manual override

found 0x27 confirms the LCD backpack answered on the I2C bus, and the banner confirms the node reached its ready policy. If a peripheral fails, the firmware prints INIT FAIL and stops.

Lab 1: Bring-Up and Verify

Goal: prove the node reads the room climate, drives the LCD, takes a local override, reaches the gateway, and moves the baffle.

1. Wire the node per the pin map and attach the antenna.

2. Build and flash the clean firmware.

3. Connect the gateway radio to the laptop and find its port (/dev/cu.usbserial-* on macOS, /dev/ttyUSB* on Linux).

4. Start the BMS gateway:

   python3 scripts/gateway.py --port /dev/cu.usbserial-XXXX --baud 115200


5. Send a sealed setpoint request from the edge simulator, or seal one from a node. The gateway prints it, then answers with a sealed SETPOINT command:

   +OK
   +OK
   +RCV=7,84,<84 hex characters>,-11,10
   HVAC seq=1 setpoint=220


6. The node turns yellow (OVERRIDE PENDING), receives the command, verifies the state tag and the anti-replay window, then turns green (HVAC NOMINAL) and drives the baffle to the room demand. Press the manual override at any time to raise an override request.

Checkpoint: the LCD shows ST:OPEN L:UP and SP:22.0 B:--, the green LED is lit after the baffle settles, and hvac_log.csv gains one row per request:

utc,sender,auth,setpoint,rssi_snr
2026-09-20T09:30:05+00:00,7,OK,220,"-11,10"

Theory check: why does a successful command prove the LCD initialized? Because monitor_init() only returns true when every peripheral, including the LCD, is ready; otherwise main prints INIT FAIL and never enters the loop.

Lab 2: Inspect the Wire Protocol

Goal: see the sealed envelope and the declared-length rule in action.

1. Capture a full +RCV line from the console or the gateway log.
2. Confirm the declared length equals the number of hex characters between the second comma and the RSSI field.
3. Split the hex into three parts: the first 48 hex characters are the 24-byte nonce, the last 32 are the 16-byte tag, and everything between is the ciphertext of the request or command body.
4. Locate the payload, its declared length, and the two tail fields in scripts/gateway.py (_rcv_parts and _split_payload), and explain why finding the first comma would be a bug.
5. Challenge: for the 23-byte command body, identify the four bytes of the sequence number, the one command byte, the two setpoint bytes, and the sixteen bytes of the state tag.

Checkpoint: you can explain why a frame must be sliced by the number in the declared length field, not by delimiter counting, and why the command byte and the setpoint are range-checked against the guarded set and the safe band before they can reach the actuator decision.

Lab 3: The Malware Track

Goal: find the FROSTLINE implant, prove what it does, expose its rootkit, and remove it for good. This is the persistence act, and this lab is its heart.

Safety: the implant is benign and confined to your breadboard. It beacons only to the local classroom hub, it actuates only your servo, and it writes only the reserved sector at 0x103FF000, on the same chip. There is no network, no filesystem, and no host impact.

Build the implant image

cmake -S . -B build-sandbox -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s -DSANDBOX_ONLY=ON && cmake --build build-sandbox

The clean build does not define SANDBOX_ONLY; the test build and the companion CTF build do. Compare the two binaries and explain why the implant symbols are absent from the clean one.

A: Detect the persistence in the reserved sector

1. Flash the SANDBOX_ONLY image and let it boot once. implant_init writes the 0xC7 marker into the reserved sector at 0x103FF000 on the first run.
2. Read the reserved sector with the Debug Probe or picotool and confirm the marker byte.
3. Reflash only the firmware image (the clean image is ideal) and let the node boot again. The marker is still present, and the implant re-arms.
4. Explain why reflashing the program region does not remove a payload that keeps its state outside that region.

The lesson: the natural response, reflash, is exactly the response the payload was designed to survive.

B: Break the re-install on boot

1. Read implant_init: when the marker is absent it writes the marker and returns; when the marker is present it calls implant_arm.
2. Patch the re-install check so a present marker no longer arms the bomb, and prove the bomb stays disarmed across a boot.
3. Erase the reserved sector and prove the node comes up clean with the marker gone.
4. Explain why BOTH steps are required: the patch stops the re-install, and the erasure removes the copy that a future firmware (or a future bug) could read again.

The lesson: there is no single patch for persistence. You remove the loader and you remove the payload.

C: Expose the rootkit hiding

1. Locate implant_rootkit_active: it is true when the marker is present and no probe is attached.
2. Find the masking branch in monitor.c: monitor_beacon_text renders -- while the rootkit is active, and monitor_log suppresses the BCN line.
3. Watch the LCD read B:-- and the log stay silent while the beacon still transmits on the radio. Attach the probe and observe the rootkit deactivate and the B:UP / BCN evidence return.
4. Defeat the masking branch so the operator sees the beacon regardless of persistence state.

The lesson: a rootkit is not about hiding the code; it is about controlling what the defender is allowed to observe.

D: Defeat the anti-debug with GDB

This is the dynamic-analysis trap. The implant reads CoreDebug DHCSR at 0xE000EDF0; bit 0 is C_DEBUGEN and bit 1 is C_HALT. While a probe is attached, the implant suppresses the beacon and the bomb.

1. Start the controller under the Debug Probe:

   arm-none-eabi-gdb build-sandbox/hvac_automation_node.elf
   (gdb) target extended-remote /dev/cu.usbmodemXXXX
   (gdb) monitor reset halt


2. Break in implant_tick and inspect implant_debug_attached. With a normal probe attached, it returns true, and the beacon and bomb stay silent.

3. Set a breakpoint after the anti-debug check, or clear the DHCSR debug bits in the debugger's view, and observe the beacon and the bomb resume.

4. Prove the payload: with the trap bypassed, the implant beacons and the logic bomb closes the baffle.

The lesson: an anti-debug check is a branch, and every branch is a place to stand. The correct neutralization is not to babysit the branch; it is to remove the code and the state it reads.

Malware-track checklist

• Locate the reserved-sector marker and explain the write-once first run.
• Identify the 8-byte arming magic and the 3-tick trigger delay.
• Show the re-install on boot and break it.
• Find the rootkit masking branch and expose the beacon.
• Read and explain the CoreDebug DHCSR anti-debug trap.
• Erase the reserved sector, remove the code path, and confirm the clean build is implant-free and marker-free.

Lab 4: The Fix Track

Goal: seal the controller so the red half and the implant cannot do to you what they did on the bench. Each control maps to a defect the earlier labs exposed.

1. Seal the SETPOINT command path

The old design accepted an unauthenticated setpoint. Act IV replaces it with src/control.c: the request must open under the field key, the command byte must equal HVAC_COMMAND_SETPOINT, the setpoint must be inside the provisioning band, and the sequence and state tag must pass src/hvac_auth.c before the setpoint is applied. Re-run the Lab 3 forged-command injection: the tag fails and the baffle does not move.

2. Override authorization

The local override is an operator request, and it must not silently bypass authorization. monitor_handle_override and monitor_apply_ir_command raise g_override_pending; they never move the baffle on their own. monitor_apply_setpoint clears the pending indication only when an authorized command arrives. Re-run the lab: press the manual override, then send a valid sealed SETPOINT. The baffle moves only from the authorized command, and the yellow OVERRIDE PENDING lamp returns to green only then.

3. Fail safe

Loss of the gateway link or a fault must leave the baffle in the safe state. monitor_check_link calls monitor_fail_safe when the link goes silent for HVAC_SETPOINT_WAIT_MS, which drives the safe setpoint and calls baffle_fail_safe. baffle_init seats the baffle closed at boot. Re-run the link-loss test: pull the gateway and watch the baffle seat and the fault latch, with the safe setpoint 20.0 C restored.

4. Contain the implant

The implant is a build-time and state problem, so the fix is a build-time and state control:

• Do not define SANDBOX_ONLY in production. The clean build has no implant.
• Erase the reserved sector so no persisted state can re-install the payload.
• Treat the firmware image as a signed artifact and verify it before flashing.
• At runtime, do not let any code path call the actuator directly; route every move through the guarded, authorized command path and record who authorized it.
• In production, burn the RP2350 secure-boot and debug-disable settings in OTP so SWD cannot read or write SRAM on a deployed controller.

The fix-track checklist

• Sealed command path: authenticate the frame, guard the command set and the setpoint band, verify the sequence and the state tag.
• Override authorization: request, do not bypass.
• Fail safe: seat the baffle on boot, on link loss, and on every fault, and restore the safe setpoint.
• Persistence removal: erase the reserved sector AND remove the re-install code.
• Build integrity: no SANDBOX_ONLY in production, sign and verify images.
• Debug lockdown: OTP debug disable on the deployed part.
• Key lifecycle: provision the field key from OTP and rotate on a schedule.

Troubleshooting

Symptom	Likely cause	Fix
No BOOT on the console	Wrong console pins / not reset	Check UART0 GP0/GP1 or USB; press RESET
INIT FAIL with no 0x27 in the scan	LCD not answering	Check LCD VCC=3.3V, SDA=GP2, SCL=GP3, contrast pot
LCD shows blocks / nothing	Contrast or address	Turn the backpack contrast pot; confirm address 0x27 vs 0x3F
Room climate always bad	DHT11 not reading	Check DATA=GP4; add 10K pull-up to 3.3V; wait 1-2 s after power-up
IR remote does nothing	Receiver wiring or remote protocol	Check OUT=GP5, VCC=3.3V; confirm the remote is NEC-compatible
Baffle will not move on a remote command	Command guard, band, or tag	Confirm the gateway holds the field key and the setpoint is inside 5.0 C to 35.0 C
AT+SEND sent but gateway sees nothing	Radio unpowered / wrong band	Power VDD, attach antenna, use matching band modules
Gateway sees nothing but +OK	Address/network mismatch	Confirm gateway radio provisioned to AT+ADDRESS=1, AT+NETWORKID=18
hvac_log.csv stays empty while +RCV prints	Gateway parser regression	Ensure _split_payload checks the comma at the declared length
Command rejected on the controller	Tag, window, command guard, or band	Check the field key matches, the sequence is newer, and the setpoint is in band
Marker reappears after a reflash	Reserved-sector persistence	The payload is still in the reserved sector; erase it and patch the re-install check (Lab 3)
LCD shows B:-- while the radio is busy	Rootkit masking (SANDBOX_ONLY build)	The rootkit is hiding its own beacon; see Lab 3C
Beacon data appears on the radio	Implant beacon (SANDBOX_ONLY build)	Expected in the malware-track build; see Lab 3
Debugger changes implant behavior	CoreDebug DHCSR anti-debug	The implant suppresses itself while a probe is attached; see Lab 3D

Testing Philosophy and Coverage

Hardware bugs are expensive to find on the bench, so the firmware is written so that almost all of it can be tested on the host. The suite compiles the real src/*.c files against mock Pico SDK headers (test/mock/), replacing GPIO, I2C, UART, and time with deterministic fakes, and it compiles src/implant.c with a host mock for the CoreDebug DHCSR register and the reserved flash sector.

• The mock GPIO can replay a recorded DHT11 waveform as an absolute time/level timeline, so the exact edge-timing decoder is exercised without a sensor.
• The mock I2C records every LCD byte, so rendered text can be decoded and asserted.
• The mock UART records outbound AT+SEND bytes and injects inbound +RCV lines, so the override-to-gateway-to-baffle path runs end to end with no radio.
• The implant host mock lets the tests set the DHCSR anti-debug bits and read and write the reserved-sector marker without touching real silicon.

Run the native test suite:

python3 scripts/run_tests.py

Or configure via CMake and CTest:

cmake -S test -B build-test -G Ninja && cmake --build build-test && ctest --test-dir build-test --output-on-failure

The suite has 139 cases and 452 checks with 0 failures, covering the full DHT11 waveform and every timeout shape, the baffle state machine and its bounded travel, the sealed command path and its guards, the authorization window and state tag, the override priority, fail-safe on link loss, the declared-length parser with hex-bearing payloads, the cryptographic primitives against published vectors, and the complete implant: beacon, logic bomb, rootkit, anti-debug, write-once persistence, and re-install on boot.

Verify 100% line coverage of owned firmware modules:

python3 scripts/check_coverage.py

The coverage report shows 2040 / 2040 lines, 100.00%. main.c is excluded from coverage by design. The Python adapter suite (test/test_field_crypto.py and test/test_hvac_node.py) adds 17 more tests, including the RFC 9106 Argon2id known-answer test.

The harness itself is a small in-repo framework (test/harness/) so the repo vendors no third-party code and every owned file obeys the coding standard.

Generating Packet Artifacts

scripts/gen_packet.py writes the build-time generated header from the JSON artifact:

• scripts/packet_artifact.json is the source of truth.
• include/packet_artifact.h is the generated header, committed for the build guardrail.

Why these constants are compiled into firmware:

• The RP2350 firmware has no runtime JSON parser or filesystem on this path.
• include/packet_artifact.h is generated from the JSON so the frame size, node id, hub address, wait time, servo pulses, DHT timeout, and provisioning constants are embedded in flash.
• This is provisioned data; regenerate whenever you rotate node identity, gateway addressing, or key material.

To sync the committed header from the JSON artifact:

python3 scripts/gen_packet.py --from-json scripts/packet_artifact.json --header-out include/packet_artifact.h

The check_packet_artifact_header CMake target fails the build when the committed header is stale.

Code Standards

This repository enforces unusually strict standards because the point is to teach disciplined embedded and tooling practice, not just working code.

C standard

• Every function body has no blank lines.
• Every function body is at most eight lines (Doxygen comment blocks and lone braces excluded).
• Every file, function, macro, type, and struct member carries Doxygen @brief documentation.
• Naming: snake_case files/functions, UPPER_SNAKE macros, snake_case_t types.

Run the C audit:

python3 scripts/audit_c_standard.py

Python standard

• Strict PEP8, four-space indents, snake_case, 79-character lines.
• Every function has a NumPy-style docstring.
• Every function executable body is at most eight lines, with no exceptions.
• No blank lines inside function bodies.

Run the Python audit:

python3 scripts/audit_python_standard.py

Both audits must report nothing.

Project Layout

• src/main.c: firmware entry point
• src/monitor.c: state machine tying the override remote, sealed command path, baffle, manual override, room climate sensor, and radio together
• src/implant.c: SANDBOX_ONLY FROSTLINE implant (beacon, logic bomb, rootkit, anti-debug, reserved-sector persistence and re-install)
• src/baffle.c: baffle state machine and fail-safe policy
• src/control.c: sealed SETPOINT command path with a guarded setpoint set
• src/hvac_auth.c: authorization record, monotonic anti-replay window, authenticated state tag
• src/sensor.c: DHT11 one-wire sampling and room-climate-band classifier
• src/display.c: 1602 LCD rendering over the PCF8574 I2C backpack
• src/radio.c: RYLR998 provisioning, AT-command interface, and +RCV parser
• src/status_led.c: red/yellow/green HVAC ALARM / OVERRIDE PENDING / HVAC NOMINAL annunciator
• src/button.c: debounced manual override input
• src/servo.c: 50 Hz PWM baffle actuator
• src/ir_remote.c: VS1838B edge timing and NEC override remote decoder
• src/crc.c: CRC-16/CCITT-FALSE helper
• src/chacha20.c, src/poly1305.c, src/crypto_aead.c, src/blake2b.c, src/argon2.c, src/crypto_kdf.c, src/envelope.c: the in-repo cryptographic stack
• include/hvac.h: board-level pin, provisioning, and implant configuration
• include/implant.h, include/control.h, include/hvac_auth.h, include/baffle.h: implant, command, authorization, and baffle interfaces
• include/field_secrets.h: lab-only committed key material
• include/packet_artifact.h: generated packet artifact header
• test/test_hvac_node_and_security.c, test/test_peripheral_and_crypto.c: comprehensive test suites
• test/mock/: Pico SDK hardware mocks plus the implant CoreDebug and reserved-flash host mock
• test/harness/: minimal in-repo test harness (strictly C-standard compliant)
• scripts/gateway.py: BMS gateway with radio provisioning, authentication, CSV logging, and sealed command replies
• scripts/spoof.py: forged and replayed command injection client
• scripts/sim_edge.py: laptop HVAC node simulator
• scripts/field_crypto.py: pure-Python interoperable crypto
• scripts/gen_packet.py / scripts/packet_artifact.json: packet artifact generator and source
• scripts/run_tests.py, scripts/check_coverage.py: test runner and coverage report
• scripts/audit_c_standard.py, scripts/audit_python_standard.py: code-standard auditors
• scripts/gen_banner.py: banner generator
• paper.typ / paper.pdf: classroom paper describing the protocol, the persistence, and the exercise
• .github/workflows/release.yml: tag-driven UF2 release workflow

Glossary

• AEAD: authenticated encryption with associated data; one operation for secrecy and integrity.
• Anti-debug: a check that detects an attached debugger and changes behavior. Here it reads CoreDebug DHCSR at 0xE000EDF0 (bits C_DEBUGEN and C_HALT).
• Anti-replay window: a monotonic sequence rule that rejects a valid frame that has already been used.
• Argon2id: the memory-hard password hash (RFC 9106) used to derive the field key.
• AT command: a short ASCII command (AT+...) understood by the radio.
• Baffle: the servo-driven air damper this node actuates.
• Beacon: a periodic covert transmission, here the DE AD BE EF frame the implant emits every 8 ticks.
• CRC: cyclic redundancy check, a checksum for detecting corruption.
• Declared length: the byte count the sender claims for a payload; the receiver slices exactly that many characters.
• DHT11: a low-cost temperature/humidity sensor using a custom one-wire protocol, used here as the room climate sensor.
• Fail safe: a fault drives the baffle closed and restores the safe setpoint, the safe plant state.
• Field key: the key that seals frames on the wire and computes the state tag.
• HD44780: the character-LCD controller inside a 1602 module.
• I2C: a two-wire bus (SDA/SCL) used here for the LCD backpack.
• Implant: code that runs on the device but is not part of its intended function. Here the SANDBOX_ONLY FROSTLINE module.
• Logic bomb: a payload that arms on a trigger and acts later. Here it arms on the 8-byte magic FROSTLNE and closes the baffle 3 ticks later, and it re-arms from the reserved sector on every boot.
• LoRa: a long-range, low-power sub-GHz radio modulation.
• NEC: the infrared remote encoding the VS1838B decodes.
• PCF8574: an I2C I/O expander that drives the LCD's parallel interface.
• Persistence: surviving a removal attempt. The implant keeps its state in the reserved sector 0x103FF000 and re-installs on boot, so a firmware reflash alone does not remove it.
• Rootkit: code that hides its own activity from the operator. Here the implant masks its beacon from the LCD and the log while the beacon transmits.
• RSSI / SNR: received signal strength and signal-to-noise ratio reported with each +RCV frame.
• SANDBOX_ONLY: the build guard that compiles the benign implant. The clean firmware does not define it.
• State tag: a keyed tag over the authorization record that detects a tampered verdict.
• UART: a serial port used to talk to the radio.
• XChaCha20-Poly1305: the AEAD used for every sealed frame, with a 192-bit nonce and a 128-bit tag.

Further Reading

• Act I, the sensor and telemetry chapter: https://github.com/mytechnotalent/cold-chain-monitor
• Act II, the access gate chapter: https://github.com/mytechnotalent/access-gate
• Act III, the pipeline valve chapter: https://github.com/mytechnotalent/pipeline-valve-controller
• The companion CTF for this act: https://github.com/mytechnotalent/CTF_hvac-automation-node
• Embedded Hacking course and breadboard: https://github.com/mytechnotalent/Embedded-Hacking
• Reverse Engineering self-study course: https://github.com/mytechnotalent/Reverse-Engineering
• paper.typ / paper.pdf: the classroom paper for this project.
• DHT11 datasheet, RYLR998 AT command reference, SG90 datasheet, and VS1838B datasheet (module vendors).

Next

OPERATION IRON LUNG CTF

License

MIT License
