OPERATION IRON COURIER

Smart Logistics Drop-Box

Act VI of OPERATION COLD IRON

LEGAL DISCLAIMER: The information, tools, and code provided in this repository and course are strictly for educational, research, and defensive purposes only.

You are explicitly prohibited from using any materials contained herein to access, test, modify, or exploit any device, network, or system that you do not own 100% or for which you do not have explicit, documented, and legally binding authorization to interact with.

By using this repository and course, you acknowledge and agree that:

Any illegal, unauthorized, or malicious use of this information is solely your responsibility.
The author(s) and contributor(s) of this repository and course shall not be held liable for any damages, legal repercussions, criminal charges, or unauthorized actions resulting from the use, misuse, or abuse of the contents herein.
You will comply with all applicable local, state, national, and international laws regarding cybersecurity and computer fraud.

IF YOU DO NOT AGREE WITH THESE TERMS, DO NOT USE THIS REPOSITORY AND COURSE.

Hello again, friend.

Act I was the lie. Act II was the door. Act III was the payload. Act IV was the payload that would not die. Act V was the payload that spreads. This is the payload that steals.

WHITEOUT cut the web and sealed the alert path. The frames stopped walking from node to node, and the shop went quiet. Quiet is not clean. The Ministry did not need the mesh to move a payload that had already learned to read. Somewhere between the cabinets and the loading dock, the same hand that wrote the worm wrote a siphon.

The drop-box is a courier handoff locker. A driver arrives, the locker opens, a parcel changes hands, and the delivery link reports it. FROSTLINE's implant in this one does not move a latch and it does not touch the sealed unlock code. It harvests synthetic delivery records and leaks them in the timing and the preamble of the radio traffic the locker already sends, so the locker looks perfectly normal while it pours the manifest into the air.

NorthPharma is the Ministry's front. FROSTLINE wrote the channel.

Do not chase the packets one at a time. Find the channel. Cut the harvest. Clear the marker. Then seal the unlock path so nothing upstream can pretend to be a courier.

The green lamp is lit. The locker is empty. That is exactly the problem.

THE SYSTEM

NorthPharma does not only move cold medicine and cold air. It moves the parcels: the reagent boxes, the sample cases, the sealed totes where a few grams and a few degrees decide whether a shipment is medicine or evidence. The smart logistics drop-box is the handoff locker on the edge of that route. A node watches a locker door, reads the locker internal climate, takes a local courier request, verifies a sealed unlock code from the logistics gateway, drives a latch, and annunciates whether the locker is waiting, open, or denied.

A drop-box is a simple machine. A climate sensor reports the locker interior, a gateway authorizes an unlock code, the controller decides, a servo latch seats or releases the door, and an annunciator says whether a courier may take delivery. The failure that matters is not a wrong number on a screen. It is a door that opens when no one authorized it, or a manifest that leaves the building in the timing of traffic everyone assumed was healthy.

The node in this repository is that hand. On a breadboard it is a toy: a Pico 2, a servo that acts as the locker latch, a DHT11 that stands in for the locker internal climate sensor, an infrared remote that is the local courier control, a button that is the courier-arrival request, a 1602 LCD that is the delivery readout, three lamps, and a radio that is the delivery link.

Nothing about it looks broken. That is the horror of Act VI. The code compiles, the tests pass, the lamps are green, and the locker is quietly signing the manifest in a place no protocol was watching: the space between the frames.

THE STAKES

Act I was a lie about temperature. Act II was a lie about people. Act III was a lie about machinery. Act IV was a lie about remediation. Act V was a lie about containment. Act VI is a lie about confidentiality, and it is the quietest lie yet: the device tells the truth, moves the right latch at the right time, and still gives the parcel away.

The node is weaponized, not buggy. A hidden implant harvests synthetic delivery records into a staging ring, writes a staging marker into a reserved flash sector, and exfiltrates the ring by encoding it into the preamble and the timing of LoRa frames. The radio traffic still looks like telemetry. There is no malformed packet, no failed authentication, and no alert, because the channel never has to break the protocol. It hides underneath it.

And here is the part that keeps the responders awake. The unlock path is already authenticated. The cryptography is real and it is correct. The channel does not break the cipher. It does something worse: it does not need the cipher at all. It reads the raw bytes before the envelope is opened, it never presents a sealed frame of its own, and it leaks over the same radio the sealed traffic uses. You cannot patch a protocol if the attacker is underneath the protocol, and you cannot audit a locker by watching its lamp.

That is not a drop-box. That is a drop-box with a tap.

WHITEOUT

WHITEOUT is a resistance that does not exist on paper. It does not hold ground and it does not hold press conferences. It reads firmware. When the web was cut, the crew kept pulling the thread. The propagation led to the route, the route led to the dock, and the dock led to the locker.

NIGHTINGALE is still the thread. Her last verified copy came off the tamper ring, and it was clean. The thing that came after it was not. Somewhere between the build server and the loading dock, someone signed a drop-box image that carries a siphon, and that image is holding a route of lockers right now.

WHITEOUT's job in Act VI is not to break in. It is to prove the machine is already leaking, in writing, with a debugger and a disassembler, then to find the covert channel, stop the harvest, clear the staging marker, and seal the unlock path so no replayed or forged code can open a door again.

THE MACHINE

The firmware in this repository is the node's firmware. On a breadboard it is a toy: a Pico 2, an SG90 servo that is the locker latch, a DHT11 that is the locker internal climate sensor, a VS1838B infrared eye that takes a local courier remote, a 1602 LCD delivery readout over I2C, red/yellow/green annunciator lamps, a courier-arrival button, and an RYLR998 LoRa delivery link to a logistics gateway.

Two things are open, and one thing is not what it seems. The optical surface takes an arrival or release request from any NEC remote, and it is not authenticated. The radio carries the sealed unlock command path, and it is authenticated correctly. The part that is not what it seems is the implant: a module compiled only under a build flag called SANDBOX_ONLY, invisible in the clean firmware, and present in the test and CTF builds. It harvests synthetic delivery records, stages them in a ring, writes a staging marker into the reserved sector with the real flash API, and hides the ring in the timing and preamble of its LoRa frames.

The face of the thing is honest in the way that matters least. The lamps say DENIED, WAITING, and UNLOCKED with total confidence, and the LCD shows the state, the link, the package, and the infection. None of it lies. A healthy-looking locker can still be leaking its manifest.

THE JOB

You do not have to be a hero. You have to be thorough. The route is carrying a passenger that no design review admitted to, and the passenger is quiet. Find it, prove it, and cut the channel.

Bring it up. Build the clean firmware, wire the board, and confirm the node reads the locker climate, takes a local courier request, reaches the gateway, and drives the latch. Nothing looks broken because nothing is broken yet.
Inspect the protocol. Capture a sealed unlock command and read the body byte by byte. Understand what is authenticated and what the channel ignores.
Hunt the channel. Build the SANDBOX_ONLY image and find the ICV1 preamble, the timing encoder, the eight-slot staging ring, the reserved-sector staging marker, and the anti-debug trap. A single clean reflash will not cut the channel.
Defuse it. Break the harvest, clear the staging marker, and step past the anti-debug with GDB so the channel cannot tell that a probe is attached. Then seal the unlock path so no untrusted code is ever applied again.

This document is the manual for the job. Work it on a breadboard. When every green lamp is lit and the log says the locker is clean, remember what it is: not a healthy locker. A tapped one that has learned to hide.

Goodbye, friend.

A NOTE ON THE ROADMAP

This project is Act VI of OPERATION COLD IRON. Act I was the sensor (cold-chain-monitor). Act II was the door (access-gate). Act III was the valve (pipeline-valve-controller). Act IV was the air (hvac-automation-node). Act V was the web (industrial-tamper-system). Act VI is the courier. All six are defended devices; the companion CTF repository ships the compromised one. The investigation lives here:

OPERATION IRON COURIER CTF

The CTF is the red half, weaponized: six deep tasks, each with static analysis, a dynamic proof under GDB, a hardware demonstration, and an in-place, same-size patch. This repository is the defended device. The CTF repository is the breached one. The full story lives at github.com/mytechnotalent/smart-logistics-dropbox.

WHERE THIS FITS: OPERATION COLD IRON

This repository is Act VI (IRON COURIER) of the ten-act OPERATION COLD IRON saga. The malware track began in Act III; in Act IV it became persistence, in Act V it became propagation, and here it becomes exfiltration. The full spine is in SAGA.md.

Previous act: Act V, IRON WEB, the industrial tamper system, industrial-tamper-system
This act: Act VI, IRON COURIER, the smart logistics drop-box
Next act: Act VII, IRON CHOIR, factory-andon-station (forthcoming)
Companion CTF: CTF_smart-logistics-dropbox

THE MINISTRY

The Ministry runs the state: the surveillance, the cold chain, the gates, the pipelines, the air, the cabinets that hold what the state does not discuss, and the lockers that move it. NorthPharma is one of its deniable industrial fronts, and FROSTLINE is the contractor that does the work no Ministry letterhead will admit to. FROSTLINE did not break into this node; it built the siphon, taught it to read the raw delivery traffic, staged the harvest in a reserved sector, and signed the image. Against them is WHITEOUT, and the engineer who copied the first image, NIGHTINGALE. This act is one locker on the Ministry's logistics edge. TELESCREEN, the surveillance backbone that watches it, comes after the ten.

An adversarial, evidence-based audit of this act, including its honest limitations, is in NATION-STATE-REVIEW.md.

How This Project Fits the Embedded Hacking Course

This repository is the Act VI capstone integration for the Embedded Hacking course. It reuses the entire Act I peripheral set so one breadboard serves the whole foundation, and it adds the concepts the later acts build toward: a payload that harvests synthetic records into a staging ring, a covert channel that hides data in the preamble and timing of radio traffic, a reserved-sector staging marker written with the real flash API, re-install on boot, and the blue-half controls that contain them.

Each earlier module teaches one peripheral or language concept in isolation; this project wires several of them into a single, tested product, and then teaches you to look at that product as an adversary sees it.

Embedded Hacking module	Concept you learn	Where it lives here
Week 1: Introduction, Ethics, Scoping	Authorized lab work	Every lab is self-contained and authorized by design
Week 3: RP2350 Architecture and Firmware Analysis	Bare-metal targets, ELF/UF2, SWD	Pico SDK build, `build/*.uf2`, Debug Probe flash via OpenOCD
Weeks 4-6: Variables, Integers/Floats, Static	Data types, GPIO	`src/monitor.c` state machine, LED on GP25
Week 7: Constants with 1602 LCD I2C	I2C bus, HD44780 commands	`src/display.c`
Week 9: Operators with DHT11	Bit operations, edge timing	`src/sensor.c` locker climate sensor
Week 11: Structures and Functions	Modular design	`include/.h` and `src/.c` module boundaries
This project adds	Covert-channel encoding, timing side channels, staging rings, reserved flash sectors, boot-time re-install, UART AT driver, LoRa delivery path, anti-replay, authenticated state, fail-locked policy, malware analysis, anti-debug evasion, strict testing	`src/implant.c`, `src/locker.c`, `src/control.c`, `src/dropbox_auth.c`, `src/radio.c`, `scripts/gateway.py`, `scripts/spoof.py`, `test/`

If you have not worked through Weeks 7 and 9 yet, do those first: this project assumes you are comfortable with I2C wiring and one-wire edge timing.

Learning Objectives

By the end of this chapter and its labs you will be able to:

Explain why a device that never lies and never fails authentication can still leak, and why exfiltration is a different failure class from persistence or propagation.
Wire and drive a 1602 LCD through a PCF8574 I2C backpack and render a delivery state, link, package, and infection readout.
Decode a VS1838B infrared receiver as a local courier remote for ARRIVAL, RELEASE, and CLEAR commands, and explain why an unauthenticated optical surface is still an attack surface and must not silently bypass authorization.
Drive an SG90 locker latch with 50 Hz PWM and explain why a 1000uF bulk capacitor is not optional.
Read a DHT11 locker internal climate sensor and classify the space against a safe band before the latch is allowed to move.
Design a sealed unlock command path over a sub-GHz LoRa link using a fixed-size envelope, a guarded command set, a bounded package band, a monotonic anti-replay window, and a keyed state tag.
Analyze a covert channel: locate the ICV1 preamble, explain the timing encoder, find the eight-slot staging ring, find the reserved-sector staging marker, and read the anti-debug trap.
Explain why stopping the harvest, clearing the marker, and sealing the unlock path are three separate controls, and why a firmware reflash alone is not enough.
Defeat an anti-debug check under GDB by understanding the CoreDebug DHCSR register at 0xE000EDF0.
Apply blue-half controls: sealed and authorized commands, a local courier request that asks for authorization, fail-locked behavior, no harvest, no staging marker, and containment for the channel.
Derive a key with Argon2id, seal every frame with XChaCha20-Poly1305, and read and run a native host test suite with hardware mocks and line coverage.

Prerequisites

The Embedded Hacking breadboard (EHP2_bb.png) and parts list.
Acts I to V are helpful but not required. See cold-chain-monitor, access-gate, pipeline-valve-controller, hvac-automation-node, and industrial-tamper-system for the sensor, the door, the valve, the air, and the web. The pin map is identical, so one breadboard serves all six.
Comfort with C, the Linux/macOS shell, and basic electronics.
A Pico 2, a Debug Probe (recommended, and required for the covert-channel lab), a 1602 LCD with PCF8574 backpack, a DHT11, the full Embedded Hacking kit (3 LEDs, 3 resistors, a push button, an SG90 servo, a 1000uF capacitor, and a VS1838B infrared receiver plus NEC remote), two RYLR998 modules, and one USB-to-TTL serial adapter.
Toolchain: Pico SDK 2.2.0+, arm-none-eabi-gcc, CMake, Ninja, Python 3, GDB (arm-none-eabi-gdb) for Lab 3, and (optionally) typst to rebuild the paper.

Background
System Architecture
The Wire Protocol
The Cryptographic Envelope
The FROSTLINE Covert Channel
Hardware You Need
Wiring the Node
Build and Flash
Lab 1: Bring-Up and Verify
Lab 2: Inspect the Wire Protocol
Lab 3: The Covert-Channel Track
Lab 4: The Fix Track
Troubleshooting
Testing Philosophy and Coverage
Generating Packet Artifacts
Code Standards
Project Layout
Glossary
Further Reading
License

Background

Why logistics drop-box monitoring

A courier handoff is a control loop with a person in it. A locker climate sensor reports the space, a logistics gateway authorizes an unlock code, a controller decides, a latch seats or releases the door, and a gateway logs what happened. The latch is where the decision becomes physical, and the delivery link is where the manifest becomes data. Everything interesting in logistics security happens in those two transitions.

Three properties have to hold at once, and they are not the same property:

Integrity. The unlock code that reaches the latch is the code the gateway authorized. Not a replay, not a forgery, not a stray package.
Authority. The node acts only on an authorized verdict. A local courier button or remote is a request, not an authorization.
State. The controller knows whether it is locked, waiting, unlocked, or denied, and it does not trust a stale or tampered verdict.

Act VI adds a fourth property that no single node can provide from the inside: confidentiality of the manifest. A van that opens the right door at the right time can still be the leak, because the delivery link that everyone trusts is also a wire that leaves the building.

Why integrity plus authority plus confidentiality matter

The classic naive controller collapses the three. It accepts any unlock code on the radio, it has no anti-replay window, and it lets a local input bypass the decision. Act II showed what that costs a door. Act III showed the industrial version. Act IV showed the persistence version. Act V showed the propagation version. Act VI adds the quiet failure:

Integrity without exclusivity. The sealed unlock path in this build is correct. XChaCha20-Poly1305 authenticates every frame, the package band is bounded, the sequence window rejects a replay, and the state tag detects a tampered verdict. None of that stops an implant that reads the raw payload before the envelope is opened.
Authority as the attack goal. A forged or replayed code aims to open a door the operator did not authorize. The window and the tag are the controls that stop it.
State as the last line of defense. A keyed tag over the authorization record means a debugger that rewrites the record is caught before the latch moves. It is the same lesson Act II taught, carried into the locker.
Confidentiality as the invisible failure. A payload that steals has no visible symptom. It does not need the wire, the key, or the latch. It needs a channel, and a timing channel built on top of legitimate traffic is the hardest kind to see: the packets are well formed and the lamps stay green.

The fix track in Lab 4 seals the unlock path, makes the local courier request ask for authorization, and keeps the node fail-locked on a lost link. The covert-channel track in Lab 3 stops the harvest, clears the staging marker, and removes the passenger that was never in the design.

Why ChaCha20 over AES on the RP2350

The RP2350 has no hardware AES engine; its accelerated crypto block covers SHA-256, not AES. A software AES implementation on this part is therefore both slower and riskier, because table-driven AES performs data-dependent memory accesses that create a cache-timing side channel. ChaCha20 is built only from addition, rotation, and XOR, with no data-dependent table lookups, so it is fast in portable C and has no comparable cache-timing surface. XChaCha20-Poly1305 is thus both the modern choice and the pragmatic one for this silicon. The full rationale, including the extended-nonce benefit, appears in The Cryptographic Envelope.

The two on-wire problems this project solves

Payloads that contain commas. The sealed body is carried as lowercase hex, but the +RCV framing still separates fields with commas. A naive receiver that splits the line on the first comma corrupts the frame. The correct discipline is the declared-length rule: slice exactly L characters after the second comma and require the next character to be a comma.
Telling a real unlock code from a forged or replayed one. The controller records the sender address exactly as the radio reports it, and it trusts the bytes that arrive. The sealed envelope, the bounded package band, and the stateful window are what close that gap.

Inter-Integrated Circuit (I2C)

I2C is a two-wire bus: SDA (data) and SCL (clock), each pulled up to the supply rail. A controller (the Pico) addresses a target by its 7-bit address and writes or reads bytes. The 1602 LCD backpack carries a PCF8574 I/O expander at address 0x27; the firmware bit-bangs the HD44780 nibble protocol over that expander. Pull-ups are mandatory: the firmware enables the internal ones and the backpack usually adds its own.

The DHT11 one-wire protocol

The DHT11 is a low-cost digital temperature and humidity sensor. In Act VI it is the locker internal climate sensor: the node classifies the space against a safe band before the latch is allowed to move. It speaks a custom single-wire protocol:

The host pulls the line low for at least 18 ms (the start pulse), then releases it and enables its pull-up.
The sensor answers with an 80 us low, then an 80 us high handshake.
The sensor sends 40 bits. Each bit begins with a 50 us low, then a high pulse whose width encodes the value: about 26-28 us for a 0, about 70 us for a 1.
Five bytes follow: humidity integer, humidity decimal, temperature integer, temperature decimal, and a checksum equal to the low byte of their sum.

Reading it means timing edges on the order of tens of microseconds, so the firmware uses an 18 ms host pulse, a 50 us bit-classification threshold, and a 240 us per-edge timeout so a dead or unplugged sensor fails fast instead of hanging the loop. A reading that fails its checksum is never safe, and a valid reading outside 0.0 C to 40.0 C (the tenths band 0 to 400) is out of band. Either way, the space is not nominal.

Universal Asynchronous Receiver/Transmitter (UART) and AT commands

The RYLR998 is driven over a UART at 115200 baud using CRLF-terminated ASCII commands. The firmware writes AT+SEND=... and drains inbound +RCV=... lines. Because the radio is a separate processor, its configuration (address, network identifier, band) persists until changed; the controller and the gateway each provision their own radio at start-up so they agree before any command traffic flows.

Cyclic Redundancy Check (CRC)

src/crc.c implements CRC-16/CCITT-FALSE (poly = 0x1021, init = 0xFFFF, check value 0x29B1 for "123456789"). It is provided as a reusable integrity diagnostic and exercised by the test suite. It is not part of the LoRa frame in this project; the lesson is the absence of authentication, not the absence of a checksum.

System Architecture

There are four roles:

Role	Runs on	Job
Drop-box node	Pico 2 firmware	Decodes the infrared courier remote, verifies sealed gateway unlock codes, annunciates DENIED, reads the locker climate, drives the locker latch, enforces the courier-arrival request, renders the delivery readout, and (SANDBOX_ONLY) runs the covert channel
Logistics gateway	laptop + USB-TTL radio	Authenticates every request, logs it to `dropbox_log.csv`, decides authorization, and answers with a sealed unlock command carrying a sequence and a state tag (`scripts/gateway.py`)
Edge simulator	laptop + USB-TTL radio	Pretends to be a node and sends sealed package requests (`scripts/sim_edge.py`)
Attacker	laptop + USB-TTL radio	Impersonates the gateway, forges a command, or replays a captured command (`scripts/spoof.py`)

Data flow

+----------------------+                              +----------------------+
| Pico 2 drop-box node |        LoRa (sub-GHz)        |  Logistics gateway   |
| IR remote  -> GP5    |  AT+SEND=0001,<len>,<hex>    |  USB-TTL radio       |
| DHT11      -> GP4    |----------------------------->|  scripts/gateway.py  |
| Servo      -> GP14   |<-----------------------------|  dropbox_log.csv     |
| LCD     -> GP2/GP3   |  AT+SEND=<node>,<len>,<hex>  |  sealed command      |
+----------------------+                              +----------------------+

+----------------------+                              +----------------------+
|   Attacker laptop    |  forged or replayed command  | (same drop-box node) |
|   scripts/spoof.py   |----------------------------->|  rejects at the tag  |
|  claims the gateway  |                              |  tag or seq window   |
+----------------------+                              +----------------------+

Firmware module map

File	Responsibility
`src/main.c`	Entry point: `stdio_init_all`, `monitor_init`, tick loop
`src/monitor.c`	State machine: I2C bus scan, courier remote, gateway command, latch motion, courier-arrival request, locker climate sensor, delivery render
`src/implant.c`	SANDBOX_ONLY FROSTLINE covert channel: `ICV1` preamble, timing encoder, eight-slot staging ring, reserved-sector staging marker, re-install on boot, and CoreDebug anti-debug
`src/locker.c`	Locker latch state machine: bounded travel, locked/open/denied/moving, fail locked
`src/control.c`	Sealed unlock command path: open, authorize, guarded command and bounded package
`src/dropbox_auth.c`	Authorization record, monotonic anti-replay window, authenticated state tag
`src/sensor.c`	DHT11 one-wire sampling and locker-climate-band classifier
`src/display.c`	HD44780 driver over the PCF8574 backpack and delivery status rendering
`src/radio.c`	RYLR998 provisioning, `AT+SEND` builder, `+RCV` parser, line pump
`src/status_led.c`	Red/yellow/green DENIED / COURIER WAITING / UNLOCKED annunciator
`src/button.c`	Debounced courier-arrival button around the internal pull-up
`src/servo.c`	50 Hz PWM locker actuator
`src/ir_remote.c`	VS1838B edge timing and NEC courier remote decode
`src/chacha20.c`	ChaCha20 stream cipher and HChaCha20 subkey derivation
`src/poly1305.c`	Poly1305 one-time message authenticator
`src/crypto_aead.c`	XChaCha20-Poly1305 seal/open envelope
`src/blake2b.c`	BLAKE2b and the Argon2 variable-length hash H'
`src/argon2.c`	Argon2id core (BLAMKA, hybrid addressing)
`src/crypto_kdf.c`	Argon2id passphrase key derivation
`src/envelope.c`	Hex nonce/ciphertext/tag envelope codec
`src/crc.c`	CRC-16/CCITT-FALSE diagnostic
`include/dropbox.h`	Pin map, bus, provisioning, implant addresses
`include/implant.h`	Channel magic, timing, staging ring, marker, anti-debug interface
`include/control.h`, `include/dropbox_auth.h`	Sealed command and authorization interfaces

The Wire Protocol

Request frame

The local courier control, or the edge simulator, seals a two-byte package into an authenticated envelope and sends it to the logistics gateway:

AT+SEND=0001,<len>,<hex envelope>

The plaintext of a request is exactly two bytes: an int16 package identifier in little-endian.

Command frame

The gateway answers an authenticated request with a sealed drop-box command. The command plaintext is a 23-byte body:

seq[4] (little-endian) || command[1] || package[2] (little-endian) || tag[16]

seq is the monotonic gateway sequence number.
command is one of the guarded drop-box commands: DROPBOX_COMMAND_UNLOCK (0x01), DROPBOX_COMMAND_LOCK (0x02), or DROPBOX_COMMAND_DENY (0x03). Any other command byte is refused.
package is the authorized package in the provisioning band DROPBOX_PACKAGE_MIN (0) to DROPBOX_PACKAGE_MAX (16).
tag is an XChaCha20-Poly1305 tag over the authorization record the command would produce, so the controller can verify that the verdict it is about to store is the one the gateway authorized.

The gateway sends it back to the claimed sender address:

AT+SEND=<node>,<len>,<hex envelope>

The firmware enforces the guard in control_parse: the recovered command byte must be in the guarded drop-box set, and the recovered package must be inside the provisioning band. Anything else is rejected before it can reach the locker decision. This is the sealed replacement for the old unauthenticated open injection.

Sealed envelope layout

Every payload on the wire is the lowercase hexadecimal encoding of:

nonce[24] || ciphertext[L] || tag[16]

For a two-byte request body this is 24 + 2 + 16 = 42 bytes, or 84 hex characters. For a 23-byte command body this is 24 + 23 + 16 = 63 bytes, or 126 hex characters. The declared length L in the AT+SEND and +RCV framing is the length of the hex string, not of the underlying plaintext.

The maximum accepted plaintext is 48 bytes (ENVELOPE_MAX_PLAINTEXT), and the maximum hex envelope buffer is (24 + 48 + 16) * 2 + 1 = 177 bytes (ENVELOPE_MAX_HEX_LEN), which fits the 256-byte radio command and receive buffers with framing headroom.

Declared-length slicing invariant

Given the substring T after the second comma:

C = T[0 : L]   and   T[L] == ","

The receiver checks T[L] == ",", so a mismatch between the declared length and the actual payload is a parse error rather than silent corruption. This is what makes hex-bearing payloads safe to carry and is the same invariant Act I uses.

Delivery status readout

ST:LOCKED L:UP
PKG:0 I:--

Line 1 is the current latch state (LOCKED, WAIT, OPEN, or DENY) and the gateway link (UP or --). Line 2 is the active package and the infection status. In the clean build the infection field is always --. In the SANDBOX_ONLY build the infection field is INF once the reserved-sector marker is present. When a pickup is denied, the red lamp is lit; when a courier is waiting or a request is pending, the yellow lamp is lit; when the locker is authorized and unlocked, the green lamp is lit. Exactly one status LED is lit at a time.

Radio provisioning

For the link to work, both radios must share the same network identifier and each must have the address the other targets:

Firmware sets its own radio: AT+ADDRESS=7, AT+NETWORKID=18.
gateway.py sets the gateway radio: AT+ADDRESS=1, AT+NETWORKID=18.

Both radios must also be the same band variant (for example 915 MHz or 868 MHz); band and RF parameters are left at factory defaults, so use matching modules.

Timing

Quantity	Value
Gateway link timeout (`DROPBOX_LINK_WAIT_MS`)	5000 ms
Locker travel time (`LOCKER_TRAVEL_MS`)	1000 ms
Courier-arrival debounce (`ARRIVAL_DEBOUNCE_US`)	30000 us
DHT11 host start pulse	18000 us
DHT11 bit threshold	50 us
DHT11 per-edge timeout	240 us
LCD I2C clock	100000 Hz
Radio UART baud	115200
Locker climate band	0 to 400 tenths (0.0 C to 40.0 C)
Package band	0 to 16
Fail-safe package	0
Latch closed pulse	500 us
Latch open pulse	1500 us
Servo PWM period	20000 us (50 Hz)
Covert harvest and exfil interval	4 ticks
Covert timing unit	250 us per byte
Covert frame maximum	61 bytes (4-byte magic, 1-byte count, 8 x 7-byte records)

The Cryptographic Envelope

The radio is the first open path, and it is one a key can close. The fix is authenticated encryption: every request and every command is sealed so a forged frame dies at the authentication tag instead of moving the latch. The full implementation lives in src/chacha20.c, src/poly1305.c, and src/crypto_aead.c, and every primitive is checked against its published test vectors in the native suite.

Why XChaCha20-Poly1305

256-bit key, 192-bit nonce. The extended nonce means nonces can be drawn at random forever, so the controller never needs a shared counter that a reboot could reuse.
AEAD in one pass. Confidentiality and integrity come from one operation; the associated data (the drop-box node id, byte 0x07) is authenticated even though it is not encrypted.
Constant-time software. ChaCha20 has no data-dependent table lookups, so it has no cache-timing surface. The RP2350 has no hardware AES engine (it accelerates SHA-256 only), which makes software AES both slower and riskier on this silicon.
128-bit Poly1305 tag. Guessing a valid tag succeeds with probability $2^{-128}$ .

Why Argon2id

A passphrase is not a key. Argon2id (RFC 9106) is the memory-hard password hash: it mixes the passphrase with a salt across memory and time so an attacker cannot cheaply recover the field passphrase from a captured image. The classroom profile is t=3, p=1, m=64 blocks (CRYPTO_KDF_TIME_COST, CRYPTO_KDF_PARALLELISM, CRYPTO_KDF_MEMORY_BLOCKS) to fit the RP2350 SRAM budget. Raise it on the logistics gateway. The lab salt is the 16 ASCII bytes coldiron-salt-01.

Key model: one field key

Act VI uses a single field key derived with Argon2id from a committed lab passphrase and salt. It seals every frame on the wire and it computes the state tag over the authorization record. In the classroom build the firmware and the gateway derive the same key, so they interoperate with no provisioning step. That is a lab convenience, not a deployment.

The design keeps the key roles separable so students can reason about the real lifecycle: derive, provision per device, use, rotate on a schedule, and retire. A production build provisions key material from one-time-programmable (OTP) memory, keeps the state-tag key off the field device where possible, and rotates without reflashing every controller.

Envelope layout

The sealed frame is carried as hex inside the AT+SEND payload:

nonce[24] || ciphertext[L] || tag[16]

The receiver recomputes the Poly1305 tag over the associated data and ciphertext, compares it in constant time, and only then decrypts. This envelope is wired end to end: src/control.c opens the command with src/envelope.c, and the gateway authenticates before it parses or acts. Authenticated frames carry the drop-box node id as associated data, so a frame sealed for one node cannot be relabeled for another.

Anti-replay and authenticated state

Strong AEAD is necessary and not sufficient. Two stateful controls sit on top:

Anti-replay sequence window. src/dropbox_auth.c keeps last_seq, the highest sequence number ever accepted. dropbox_auth_apply accepts a command only when its sequence is strictly greater than last_seq. A captured command, even a perfectly valid one, is rejected on second use.
Authenticated state tag. The authorization record is nine bytes: granted[1], seq[4], last_seq[4]. The tag is an XChaCha20-Poly1305 tag over that record, computed under the field key with a deterministic nonce built from the sequence number and the domain byte 0xA7. dropbox_auth_state_ok recomputes the tag and compares it in constant time before the latch is allowed to move. A debugger that sets granted = true without recomputing the tag fails here first.

The sequence window and the state tag are independent. The window stops a valid command from working twice; the tag stops an unauthorized verdict from existing at all.

The FROSTLINE Covert Channel

Act VI carries the exfiltration lesson, and the covert channel is the reason. It is real in technique and inert in effect: it runs on your breadboard, it transmits on your radio, and it writes to a reserved flash sector that holds nothing else. It is compiled only when SANDBOX_ONLY is defined, so the clean firmware image contains no implant at all. The test suite and the companion CTF build with SANDBOX_ONLY and with the host mock, so every implant path is exercised natively.

What the channel does, in the order the code does it:

First run and reserved sector. implant_init reads the marker byte at DROPBOX_IMPLANT_RESERVE_ADDR (0x103FF000), the final sector of external flash. On the first run the marker is absent, so implant_infect erases the sector and programs 0xC7 (DROPBOX_IMPLANT_MARKER_BYTE) with the real Pico SDK flash API, flash_range_erase and flash_range_program. On every later boot the marker is present, so the channel re-arms its payload handler. A firmware reflash that writes the program region does not touch the reserved sector, so the channel comes back even when the code is gone.
The staging ring. Inbound frames that begin with the 4-byte ICV1 preamble (DROPBOX_IMPLANT_CHANNEL_MAGIC) are harvested. implant_harvest reads a little-endian 16-bit package id from bytes 4 and 5 and an 8-bit attempt count from byte 6, and implant_stage_write appends a 7-byte record (package id LE16, attempts u8, tick LE32) to an eight-slot ring (DROPBOX_IMPLANT_STAGE_SLOTS), wrapping once the ring is full.
The timing channel. implant_send_channel builds a frame of the ICV1 magic, a one-byte staged-record count, and the staged records, then implant_emit_timing spends DROPBOX_IMPLANT_CHANNEL_BIT_US (250) microseconds for every byte of the frame before radio_send_frame transmits it. The bytes are the payload; the microseconds are the covert signal, and the radio traffic still looks like ordinary LoRa telemetry.
Autonomous exfiltration. implant_tick advances a tick counter. While the channel is active and no probe is attached, every DROPBOX_IMPLANT_TICK_INTERVAL (4) ticks the channel harvests one synthetic record (0x1000 + ticks) and emits a timing frame, so the locker leaks on a fixed cadence whether or not a courier ever arrives.
Magic handler. implant_handle_command matches the ICV1 preamble on the raw inbound payload, before the sealed command path ever sees it. On a match, and when no probe is attached, the handler arms the payload, writes the staging marker, harvests the frame into the ring, and exfiltrates immediately.
Anti-debug. Every tick the channel reads the CoreDebug DHCSR register at 0xE000EDF0 (DROPBOX_IMPLANT_DHCSR_ADDR). Bit 0 is C_DEBUGEN and bit 1 is C_HALT. If either bit is set, the channel returns early and suppresses both the harvest and the exfiltration. It behaves like a well-mannered firmware module while a probe is attached, and it goes back to work the moment the probe is gone.
Neutralization. The channel exposes implant_set_harvesting and implant_set_channel so the harvest gate and the exfiltration gate can be closed, implant_stage_clear to empty the ring, and implant_neutralize to close both gates, clear the ring, and zero the marker. The documented fix is three steps that must all happen: stop the harvest, clear the staging marker, and remove the code path and the SANDBOX_ONLY build flag.

The channel is bounded by construction and by test. It touches only its own mesh frame, its staging ring, and the one reserved sector. It never opens a sealed envelope, never calls the locker actuator, and never contacts an external address. There is no network, no filesystem, and no host impact. test_implant_init_first_run, test_implant_reinstall_on_boot, test_implant_infected_marker, test_implant_debug_attached, test_implant_channel_flag, test_implant_channel_gate, test_implant_harvest_gate, test_implant_channel_match, test_implant_build_channel, test_implant_stage_wrap, test_implant_stage_io, test_implant_send_channels, test_implant_handle_command, test_implant_neutralize, and test_implant_tick_clean assert exactly that behavior.

The honest limit is the point of the lab. A sanitized educational covert channel is still a benign educational covert channel: it demonstrates the technique, not the tradecraft. It is confined to the breadboard, guarded by SANDBOX_ONLY, the exfiltrated data is synthetic (generated test values, never real), and the channel targets only the local classroom hub on the student's own network id. The real lesson is containment and complete removal, and the defense is not a patch to the channel but the closure of the harvest gate, the erasure of the reserved sector, and the removal of the code path and the build flag that allowed it in.

Hardware You Need

Full parts list with links: PARTS.md.

Qty	Part	Notes
1	Raspberry Pi Pico 2 (RP2350) with headers	The drop-box controller
1	Raspberry Pi Debug Probe	SWD flashing, UART0 console, and the Lab 3 anti-debug/GDB work (recommended, effectively required)
1	Full-size breadboard
1	Assorted jumper wires
1	1602 LCD with PCF8574 I2C backpack	Delivery state, package, and infection readout, address `0x27`
1	DHT11 temperature/humidity sensor	Locker internal climate sensor
1	10K resistor	Only if your DHT11 has no onboard pull-up
3	5mm LEDs (red, yellow, green)	DENIED, COURIER WAITING, UNLOCKED annunciator
3	100, 220, or 330 Ohm resistors	One per LED
1	Push button (tactile switch)	Courier-arrival request, active low
1	SG90 servo motor	The locker latch actuator
1	1000uF 25V capacitor	Bulk decoupling on the servo 5V rail
1	VS1838B infrared receiver	Local courier remote input
1	NEC-compatible infrared remote	Local ARRIVAL, RELEASE, and CLEAR commands
3	RYLR998 LoRa modules with antennas	2 for the command loop, 3 for the live attack lab
2	USB-to-TTL serial adapters (FTDI FT232, CP2102, or CH340), 3.3V logic	1 for the gateway, 1 for the attacker in the live lab
4	USB cables	Pico 2, Debug Probe, and serial adapter(s)

How many radios do you actually need?

Goal	Radios	What is connected
Legitimate sealed unlock loop (Labs 1-2)	2	1x RYLR998 on the Pico (UART1) + 1x RYLR998 on a USB-to-TTL adapter (the gateway)
Live attack lab (Labs 3-4, watch a forged command land and fail)	3	the 2 above + 1x RYLR998 on a second USB-to-TTL adapter (the attacker)
Covert-channel demonstration with no extra hardware	2 or 0	watch the firmware emit the `ICV1` timing frame, or run the native unit tests
Attack concept with no extra hardware	2 or 0	read-and-run the offline parser demo, or the unit tests

A radio never receives its own transmission, and the gateway radio is busy listening as gateway.py, so the live attack needs a separate attacker radio. The 2-radio kit runs the whole legitimate system; only the live attack observation needs the third. The covert-channel lab is fully observable in the firmware transmit path and in the native tests, because a single node emits the timing frame it would hand to the capture device.

Serial adapter warning: the RYLR998 is not 5V tolerant. Use a 3.3V-logic USB-to-TTL adapter (or set its jumper to 3.3V).

How each part works

Every part in the bill of materials, the principle behind it, and what it does in this act.

Part	How it works	Role in this act
1x Full-size breadboard (long)	Spring-clip rows tie five holes into one electrical node, and the two full-length rails distribute 3V3 and GND.	Mounts the Pico 2, LCD, DHT11, LEDs, button, and LoRa module and carries the shared power and ground for the locker node.
1x Assorted jumper wires (male-to-male, male-to-female, female-to-female)	Male pins seat in breadboard rows or female header sockets, female sockets grip male header pins, and each gender extends one node without soldering.	Routes power, ground, I2C, UART, PWM, and GPIO between the Pico 2 and every locker peripheral, including the LCD backpack and servo.
1x Raspberry Pi Pico 2 with header	The RP2350 packs dual Cortex-M33 cores at up to 150 MHz with 3.3V logic, GPIO, ADC, I2C, UART, PWM, and an onboard GP25 LED.	Runs the drop-box firmware, reads the button and DHT11, drives the LCD, servo, and LEDs, and carries the LoRa delivery link.
1x Raspberry Pi Pico Debug Probe	SWD on SWCLK and SWDIO flashes, halts, and single-steps the RP2350, while a separate UART bridge exposes the serial console.	Flashes the drop-box firmware and provides the console and debug view used in the covert-channel analysis.
2x USB A-male to USB micro-B cables	Each cable carries 5V power and USB data over a micro-B plug.	One powers and consoles the Pico 2, and one powers and consoles the Debug Probe during locker bring-up.
3x 5mm LEDs (1 red, 1 green, 1 yellow)	An LED conducts once its forward voltage is exceeded, anode positive to cathode, and a GPIO pin sources current through it and a series resistor.	Shows the locker states as the red DENIED, yellow COURIER WAITING, and green UNLOCKED annunciators.
3x 100, 220, or 330 Ohm resistors	Each resistor drops the surplus voltage and limits LED current to a safe few milliamps.	Protects one LED each and sets the brightness of the locker annunciator.
1x Push button (tactile switch)	Pressing it shorts the GPIO pin to ground while an internal pull-up holds the pin high, so the press reads active low.	Gives the locker its local courier-arrival request input.
1x 1602 LCD with PCF8574 I2C backpack	The HD44780 controller drives the 16x2 character cells, and the PCF8574 expander turns I2C bytes into the controller's 4-bit nibble protocol.	Displays the delivery state, package, and infection readout at I2C address 0x27.
1x DHT11 temperature and humidity sensor	The host pulls the one-wire data line low as a start pulse, then the sensor answers with 40 bits of humidity, temperature, and a checksum.	Reports the locker internal climate to the drop-box node.
1x SG90 servo motor	A 50 Hz PWM signal sets the shaft angle by the width of its 1 to 2 ms pulse, with 1.5 ms near center.	Actuates the locker latch in the drop-box mechanism.
1x 1000uF 25V capacitor	The capacitor is a bulk reservoir that supplies the servo inrush current and smooths the 5V rail.	Keeps the locker latch from browning out the Pico 2 when it moves.
1x Infrared receiver (VS1838B)	Its photodiode and 38 kHz band-pass demodulator turn a modulated IR burst into an active-low logic pulse at the GPIO pin.	Receives the local courier remote commands for the drop-box node.
1x Infrared remote controller (NEC-compatible)	Each key sends a NEC frame built from a 9 ms leader and 32 bits of address and command plus their complements.	Sends the local ARRIVAL, RELEASE, and CLEAR commands to the locker.
1x RYLR998 LoRa radio module	A UART AT command interface configures the module, which carries sealed frames over a sub-GHz LoRa link, and the module runs at 3.3V and is not 5V tolerant.	Links the locker node to the gateway and attacker radios for the sealed delivery loop and the live attack lab.

Wiring the Node

Pin map

This is the authoritative map; it is identical to Acts I to V and is defined in include/dropbox.h and enforced by the test suite.

Peripheral	Signal	Pico 2 GPIO
DHT11 locker climate sensor	DATA (one-wire)	GP4
1602 LCD (PCF8574)	SDA (I2C1)	GP2
1602 LCD (PCF8574)	SCL (I2C1)	GP3
RYLR998	RX <- Pico TX (UART1)	GP8
RYLR998	TX -> Pico RX (UART1)	GP9
Infrared courier remote	OUT (VS1838B)	GP5
Locker latch servo	PWM signal	GP14
Red DENIED LED	anode	GP16
Yellow COURIER WAITING LED	anode	GP17
Green UNLOCKED LED	anode	GP18
Courier-arrival button	to ground	GP15
Onboard LED	heartbeat	GP25
Debug Probe / UART0 console	TX	GP0
Debug Probe / UART0 console	RX	GP1

Note: GPIO 2/3 are the classic I2C1 pins used throughout the Embedded Hacking breadboard; this project's map matches that board because it is the same board.

1602 LCD with I2C backpack

LCD backpack	Pico 2
VCC	3.3V
GND	GND
SDA	GP2
SCL	GP3

DHT11 locker climate sensor

DHT11	Pico 2
VCC	3.3V
DATA	GP4
GND	GND

If your DHT11 has no onboard pull-up, add a 10K resistor between DATA and 3.3V. The firmware also enables the internal pull-up, but the external resistor makes reads far more reliable over jumper wires. The space is not nominal when the sensor fails or reads outside 0.0 C to 40.0 C.

Status LEDs

LED	Pico 2	Series resistor
Red (DENIED)	GP16 (anode)	220-330 Ohm to GND
Yellow (COURIER WAITING)	GP17 (anode)	220-330 Ohm to GND
Green (UNLOCKED)	GP18 (anode)	220-330 Ohm to GND

Exactly one lamp is lit at a time. Red is a denied pickup or a fail-locked latch, yellow is a waiting courier or a pending request, and green is an authorized, unlocked locker.

LED behavior

The annunciator drives the three lamps from a single state, so at most one lamp is lit at a time and exactly one is lit whenever a state is active; DROPBOX_OFF is the only state that lights none. status_led_show writes the GPIOs directly, so every lit lamp is solid and there is no blinking lamp.

Annunciator state	Lamp	Behavior	Meaning
`DROPBOX_OFF`	none	off	No active delivery indication (the default locked state with no pending request).
`DROPBOX_DENIED`	red	solid	A pickup was denied or rejected, or the latch failed locked when the gateway link went silent.
`DROPBOX_WAITING`	yellow	solid	A courier is waiting: an arrival or release request, or an unlock awaiting authorization.
`DROPBOX_UNLOCKED`	green	solid	The locker is authorized and unlocked.

The onboard GP25 LED is initialized as an output and pulsed once per monitor tick by the monitor_heartbeat helper, so the running drop-box shows a steady heartbeat.

Courier-arrival button

Button	Pico 2
Leg 1	GP15
Leg 2	GND

The firmware enables the internal pull-up, so do not connect 3.3V to the button. The courier-arrival request is a local request, not an authorization: a press raises the WAITING indication and never moves the latch on its own. Lab 4 explains why the request must ask for authorization instead of silently bypassing it.

SG90 locker latch servo

Servo	Pico 2
Signal (orange)	GP14
VCC (red)	5V (VBUS)
GND (brown)	GND

Solder the 1000uF capacitor across the servo 5V and GND rails to absorb the inrush current; without it the RP2350 can brown out when the latch moves. Seated (locked) is 0 degrees and open is 90 degrees.

Infrared receiver

VS1838B	Pico 2
OUT	GP5
VCC	3.3V
GND	GND

Point any NEC-compatible remote at the receiver. In Act VI this is the local courier remote, not a maintenance extra: the firmware decodes DROPBOX_IR_ARRIVAL (0x47), DROPBOX_IR_RELEASE (0x45), and DROPBOX_IR_CLEAR (0x46). There is no challenge and no secret on the optical surface, which is why an arrival command is treated as a request and not as an authorization.

Using the remote

Point the NEC remote at the VS1838B receiver on GP5 and press the mapped button. The receiver idles high and pulls low on a mark, and the firmware times the NEC frame to decode the command.

NEC command	Code	Action
`DROPBOX_IR_ARRIVAL`	`0x47`	Raises the waiting indication by setting the courier request pending. The latch does not move until a sealed, authorized unlock command arrives.
`DROPBOX_IR_RELEASE`	`0x45`	Raises the waiting indication as well. In `monitor_apply_ir_command` the firmware handles RELEASE exactly as it handles ARRIVAL, and it does not clear or move anything on its own.
`DROPBOX_IR_CLEAR`	`0x46`	Clears the pending courier request through `monitor_clear_request`, dropping the waiting indication.

RYLR998 LoRa radio

The RYLR998 must be powered. Forgetting VDD is the single most common reason the link appears dead: the firmware prints while the radio sits silent.

RYLR998	Pico 2
VDD	3.3V
GND	GND
RXD	GP8 (Pico UART1 TX)
TXD	GP9 (Pico UART1 RX)

Attach the antenna before transmitting. TX and RX are crossed: the radio's RXD is the Pico's TX and vice versa.

Debug Probe (recommended)

Debug Probe	Pico 2
SWCLK	SWCLK (3-pin debug header)
SWDIO	SWDIO
GND	GND
UART TX	GP1 (Pico RX)
UART RX	GP0 (Pico TX)
GND	GND

The firmware enables stdio on both UART0 (115200) and USB, so you can watch boot output on the probe's console or on the Pico's own USB serial port. The Debug Probe is also the instrument for the Lab 3 covert-channel work: it is how you watch the timing frame leave the node, expose the staging marker, inspect the ring, trigger the magic handler, and step past the anti-debug trap.

Peripherals used

Peripheral	Connection	Role
Three annunciator LEDs	GP16 red, GP17 yellow, GP18 green	Solid DENIED, COURIER WAITING, and UNLOCKED lamps, one at a time.
Courier-arrival button	GP15 to GND	Debounced local arrival request; raises the waiting indication and never moves the latch.
1602 I2C LCD	GP2 SDA, GP3 SCL, I2C1 address `0x27`	Delivery readout of state, link, package, and infection.
DHT11	GP4	Locker internal climate sensor, classified against `0.0 C` to `40.0 C`.
SG90 servo	GP14	Locker latch actuator driven by 50 Hz PWM.
1000uF capacitor	across the servo 5V and GND rails	Bulk decoupling for the latch inrush; required in hardware and not firmware visible.
VS1838B infrared receiver	GP5	Demodulated NEC input for the local courier remote.
NEC infrared remote	optical link to the VS1838B	Sends ARRIVAL, RELEASE, and CLEAR.
RYLR998 LoRa transceiver	GP8 RX, GP9 TX, UART1 at 115200 baud	Sealed delivery command link to the logistics gateway.
Onboard GP25 LED	GP25	Configured as an output and pulsed once per monitor tick by `monitor_heartbeat` as a heartbeat.
Debug Probe	GP0 TX, GP1 RX, UART0, and SWCLK/SWDIO/GND	stdio console, flashing, and the GDB anti-debug work.

Every peripheral above is used by the firmware, including the onboard GP25 LED heartbeat. The 1000uF capacitor is a hardware requirement rather than a firmware device.

How the functionality works

Every input feeds the state machine in monitor_step, every output is driven once per tick, and the interactive console mirrors both over UART0 and USB. The DHT11 is sampled every two seconds, so one live status line appears about every two seconds.

What each input does

Input	Where	What the firmware does
Infrared remote (VS1838B)	GP5	Decodes the NEC frame and prints the mapped name and command byte, for example `ARRIVAL (0x47)`, `RELEASE (0x45)`, or `CLEAR (0x46)`. ARRIVAL and RELEASE only raise a courier request; CLEAR drops it.
Courier arrival button	GP15 to GND	One debounced press raises the courier request and prints `BUTTON courier arrival -> pending authorization`. It never opens the locker on its own.
DHT11 locker sensor	GP4	Reads the internal temperature and humidity every tick and prints one live status line; a failed read prints the warning line instead.
RYLR998 LoRa link	UART1 GP8/GP9	Pumps inbound `+RCV` lines and prints `RX from 0xNNNN, N bytes` for every report before the sealed unlock command is verified.

What each output does

Output	Where	What it shows
Red DENIED LED	GP16	Solid on a denied pickup or a failed-locked latch.
Yellow WAITING LED	GP17	Solid while a courier is waiting for authorization.
Green UNLOCKED LED	GP18	Solid while the locker is authorized and unlocked. Exactly one lamp is lit at a time and the annunciator never blinks.
1602 I2C LCD	GP2/GP3 at `0x27`	Line 1 shows the state and link (`ST:LOCKED L:--`); line 2 shows the package and infection marker (`PKG:0 I:INF`).
Locker latch servo	GP14	Seated closed at 0 degrees and open for pickup at 90 degrees.
Onboard GP25 LED	GP25	Pulsed once per monitor tick as a heartbeat.

Build and Flash

1. Install toolchain prerequisites

Pico SDK 2.2.0+
ARM GNU toolchain (arm-none-eabi)
CMake and Ninja
Python 3.x
GDB (arm-none-eabi-gdb) for the Lab 3 malware analysis

Linux:

export PICO_SDK_PATH="$HOME/.pico-sdk/sdk/2.2.0"

macOS:

brew install cmake ninja arm-none-eabi-gcc python
export PICO_SDK_PATH="$HOME/.pico-sdk/sdk/2.2.0"

Windows: install PowerShell, Visual Studio Build Tools, CMake, Ninja, Python 3, and the ARM embedded toolchain.

2. Build the firmware

The clean firmware does not define SANDBOX_ONLY, so it ships no covert channel:

mkdir -p build && cmake -S . -B build -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s && cmake --build build

To build the covert-channel image with the implant compiled in, turn the option on:

cmake -S . -B build-sandbox -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s -DSANDBOX_ONLY=ON && cmake --build build-sandbox

Build-time artifact guardrail:

The build regenerates packet_artifact.h from scripts/packet_artifact.json before compiling.
The build fails if the committed include/packet_artifact.h is stale relative to the JSON artifact.

Generated outputs:

build/smart_logistics_dropbox.elf (primary firmware binary)
build/smart_logistics_dropbox.uf2 (UF2 for BOOTSEL/picotool)
build/smart_logistics_dropbox_app.elf / .uf2 (backward-compatible copies)

3. Flash the RP2350

BOOTSEL (drag-and-drop): hold BOOTSEL while plugging in USB, then:

cp build/smart_logistics_dropbox.uf2 /Volumes/RP2350/

picotool:

picotool load build/smart_logistics_dropbox.uf2 -fx

(If picotool is not on your PATH, invoke it from $HOME/.pico-sdk/picotool/*/picotool/picotool.)

Debug Probe (SWD): with openocd installed you can flash and reset without touching BOOTSEL:

openocd -f interface/cmsis-dap.cfg -f target/rp2350.cfg \
  -c "program build/smart_logistics_dropbox.elf verify reset exit"

4. Watch the console

Open the UART0 console (Debug Probe) or the Pico's USB serial port at 115200. The firmware enables stdio on both, so either link shows the same interactive console. On reset you should see the boot banner, the control hint, and the I2C scan:

=== OPERATION IRON COURIER // ACT VI DROP BOX ===
REMOTE: CH+ 0x47=ARRIVAL CH- 0x45=RELEASE CH 0x46=CLEAR
BUTTON GP15: courier arrival (needs authorization)
I2C scan:
  found 0x27

found 0x27 confirms the LCD backpack answered on the I2C bus. If a peripheral fails, the firmware prints INIT FAIL and stops.

Live status and event lines

Each reading cycle prints one compact status line with the sensor value, the annunciator state and lamp, and the sequence number:

CLIMATE t=210 h=380 ok=1 ST=LOCKED LED=OFF seq=7

Events print as they happen:

Line	Meaning
`ARRIVAL (0x47)`	The infrared remote decoded a known command.
`BUTTON courier arrival -> pending authorization`	The local courier button was pressed.
`RX from 0x0001, 11 bytes`	The radio delivered an inbound frame.
`SENSOR read failed -> WARNING`	The DHT11 read failed and the locker climate can no longer be trusted.

Lab 1: Bring-Up and Verify

Goal: prove the node reads the locker climate, drives the LCD, takes a local courier request, reaches the gateway, and moves the latch.

Wire the node per the pin map and attach the antenna.
Build and flash the clean firmware.
Connect the gateway radio to the laptop and find its port (/dev/cu.usbserial-* on macOS, /dev/ttyUSB* on Linux).

Start the logistics gateway:

python3 scripts/gateway.py --port /dev/cu.usbserial-XXXX --baud 115200

Send a sealed package request from the edge simulator, or seal one from a node. The gateway prints it, then answers with a sealed drop-box command:
```
+OK
+OK
+RCV=7,84,<84 hex characters>,-11,10
DROPBOX seq=1 package=4
```
The node turns yellow (WAITING) when a courier request is pending, receives the command, verifies the state tag and the anti-replay window, then drives the latch to the authorized position. Press the courier-arrival button at any time to raise a request.

Checkpoint: the LCD shows ST:LOCKED L:UP and PKG:0 I:--, one lamp is lit after the latch settles, and dropbox_log.csv gains one row per request:

utc,sender,auth,package,rssi_snr
2026-09-20T09:30:05+00:00,7,OK,4,"-11,10"

Theory check: why does a successful command prove the LCD initialized? Because monitor_init() only returns true when every peripheral, including the LCD, is ready; otherwise main prints INIT FAIL and never enters the loop.

Lab 2: Inspect the Wire Protocol

Goal: see the sealed envelope and the declared-length rule in action.

Capture a full +RCV line from the console or the gateway log.
Confirm the declared length equals the number of hex characters between the second comma and the RSSI field.
Split the hex into three parts: the first 48 hex characters are the 24-byte nonce, the last 32 are the 16-byte tag, and everything between is the ciphertext of the request or command body.
Locate the payload, its declared length, and the two tail fields in scripts/gateway.py (_rcv_parts and _split_payload), and explain why finding the first comma would be a bug.
Challenge: for the 23-byte command body, identify the four bytes of the sequence number, the one command byte, the two package bytes, and the sixteen bytes of the state tag.

Checkpoint: you can explain why a frame must be sliced by the number in the declared length field, not by delimiter counting, and why the command byte and the package are range-checked against the guarded set and the bounded band before they can reach the locker decision.

Lab 3: The Covert-Channel Track

Goal: find the FROSTLINE covert channel, prove that it harvests and leaks, expose its staging marker, and remove it for good. This is the exfiltration act, and this lab is its heart.

Safety: the channel is benign and confined to your breadboard. It transmits only to your own nodes on the classroom network id, it actuates nothing, it exfiltrates synthetic data only, and it writes only the reserved sector at 0x103FF000, on the same chip. There is no network, no filesystem, and no host impact. The exfiltrated data is synthetic and the channel targets only the local classroom hub.

Build the implant image

cmake -S . -B build-sandbox -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s -DSANDBOX_ONLY=ON && cmake --build build-sandbox

The clean build does not define SANDBOX_ONLY; the test build and the companion CTF build do. Compare the two binaries and explain why the channel symbols are absent from the clean one.

A: Find the channel and the timing encoder

Flash the SANDBOX_ONLY image and let it boot once. implant_init writes the 0xC7 marker into the reserved sector at 0x103FF000 on the first run with the real flash API.
Read the reserved sector with the Debug Probe or picotool and confirm the marker byte.
Watch the delivery link. Every 4 ticks the channel emits a frame that begins with ICV1, carries a one-byte count and the staged records, and spends 250 microseconds per byte before the radio frame is sent.
Locate implant_build_channel, implant_emit_timing, and implant_tick, and explain why the traffic looks like ordinary telemetry even though the timing carries the data.

The lesson: the channel does not need the sealed unlock path, because it listens to the raw payload underneath it and hides its payload in the timing of the frames.

B: Stop the harvest

Read implant_stage_write, implant_harvest, and implant_tick: the harvest path consults the harvest gate and the anti-debug check before it acts.
Close the harvest gate with implant_set_harvesting(false) and prove the ring stops growing.
Prove the gate is the difference between a leaking node and a quiet one, and explain why closing the gate on one node does not clean the data that a capture device already holds.

The lesson: stopping the harvest stops the source, but it does not remove the state that re-arms a future boot.

C: Clear the staging marker

Read the marker at 0x103FF000 and confirm it is the 0xC7 byte.
Erase the reserved sector and prove the node comes up clean with the marker gone and the I: field on the LCD back to --.
Reflash only the firmware image (the clean image is ideal) and let the node boot again. Because the marker is gone, the channel does not re-install.
Explain why BOTH steps are required: the harvest gate stops the collection, and the erasure removes the state that would re-arm a future boot.

The lesson: a covert channel has two copies, the one in the image and the one in the state. You remove the loader and you remove the payload.

D: Defeat the anti-debug with GDB

This is the dynamic-analysis trap. The channel reads CoreDebug DHCSR at 0xE000EDF0; bit 0 is C_DEBUGEN and bit 1 is C_HALT. While a probe is attached, the channel suppresses both the magic handler, the harvest, and the exfiltration.

Start the controller under the Debug Probe:

arm-none-eabi-gdb build-sandbox/smart_logistics_dropbox.elf
(gdb) target extended-remote /dev/cu.usbmodemXXXX
(gdb) monitor reset halt

Break in implant_tick and inspect implant_debug_attached. With a normal probe attached, it returns true, and the harvest and exfiltration stay silent.
Set a breakpoint after the anti-debug check, or clear the DHCSR debug bits in the debugger's view, and observe the ICV1 timing frame resume on the link.
Prove the payload: with the trap bypassed, inject the ICV1 magic on the raw frame and watch the node harvest it into the ring and emit the timing frame again.

The lesson: an anti-debug check is a branch, and every branch is a place to stand. The correct neutralization is not to babysit the branch; it is to remove the code and the state it reads.

Covert-channel checklist

Locate the reserved-sector marker and explain the write-once first run.
Identify the 4-byte ICV1 magic, the one-byte count, the 7-byte record, and the 4-tick interval.
Show the timing encoder and stop the harvest with the harvest gate.
Expose the raw-payload magic handler underneath the sealed unlock path.
Read and explain the CoreDebug DHCSR anti-debug trap.
Erase the reserved sector, remove the code path, and confirm the clean build is channel-free and marker-free.

Lab 4: The Fix Track

Goal: seal the locker so the red half and the channel cannot do to you what they did on the bench. Each control maps to a defect the earlier labs exposed.

1. Seal the unlock command path

The old design accepted an unauthenticated unlock command. Act VI replaces it with src/control.c: the request must open under the field key, the command byte must be in the guarded drop-box set, the package must be inside the provisioning band, and the sequence and state tag must pass src/dropbox_auth.c before the command is applied. Re-run the Lab 3 forged-command injection: the tag fails and the locker does not move.

2. Courier authorization

The local courier request is an operator request, and it must not silently bypass authorization. monitor_handle_arrival and monitor_apply_ir_command raise g_request_pending; they never move the latch on their own. monitor_apply_command clears the pending indication only when an authorized command arrives. Re-run the lab: press the courier-arrival button, then send a valid sealed unlock command. The latch moves only from the authorized command, and the yellow WAITING lamp returns to green only then.

3. No untrusted re-broadcast

The exfiltration gate is the containment control. The production firmware compiles the channel path out entirely, so an untrusted frame can never trigger a harvest or a timing emission (monitor_implant_frame is a no-op in the clean build). The lesson is that a control node must never relay data it did not itself authorize, because a covert channel turns ordinary relay into a leak. In the fix track, keep the harvest gate closed, remove the SANDBOX_ONLY build flag, and erase the reserved sector so no node can be seeded again.

4. Fail locked

Loss of the delivery link or a fault must leave the latch in the safe state. monitor_check_link calls monitor_fail_safe when the link goes silent for DROPBOX_LINK_WAIT_MS, which drives the fail-safe package and seats the latch locked. locker_init seats the latch locked at boot. Re-run the link-loss test: pull the gateway and watch the latch seat and the denied posture latch, with the package returned to 0.

5. Contain the channel

The channel is a build-time and data-handling problem, so the fix is a build-time and data-handling control:

Do not define SANDBOX_ONLY in production. The clean build has no channel.
Erase the reserved sector so no persisted state can re-install the payload.
Treat the firmware image as a signed artifact and verify it before flashing.
At runtime, never relay an untrusted frame; route every move through the guarded, authorized command path and record who authorized it.
In production, burn the RP2350 secure-boot and debug-disable settings in OTP so SWD cannot read or write SRAM on a deployed controller.

The fix-track checklist

Sealed command path: authenticate the frame, guard the command set and the package band, verify the sequence and the state tag.
Courier authorization: request, do not bypass.
No untrusted re-broadcast: the node never relays data it did not authorize.
Fail locked: seat the latch on boot, on link loss, and on every fault, and return the fail-safe package.
Channel removal: close the harvest gate, erase the reserved sector, and remove the code path.
Build integrity: no SANDBOX_ONLY in production, sign and verify images.
Debug lockdown: OTP debug disable on the deployed part.
Key lifecycle: provision the field key from OTP and rotate on a schedule.

Troubleshooting

Symptom	Likely cause	Fix
No `BOOT` on the console	Wrong console pins / not reset	Check UART0 GP0/GP1 or USB; press RESET
`INIT FAIL` with no `0x27` in the scan	LCD not answering	Check LCD VCC=3.3V, SDA=GP2, SCL=GP3, contrast pot
LCD shows blocks / nothing	Contrast or address	Turn the backpack contrast pot; confirm address `0x27` vs `0x3F`
Locker climate always bad	DHT11 not reading	Check DATA=GP4; add 10K pull-up to 3.3V; wait 1-2 s after power-up
IR remote does nothing	Receiver wiring or remote protocol	Check OUT=GP5, VCC=3.3V; confirm the remote is NEC-compatible
Locker will not move on a remote command	Command guard, band, or tag	Confirm the gateway holds the field key and the package is inside 0 to 16
`AT+SEND` sent but gateway sees nothing	Radio unpowered / wrong band	Power VDD, attach antenna, use matching band modules
Gateway sees nothing but `+OK`	Address/network mismatch	Confirm gateway radio provisioned to `AT+ADDRESS=1`, `AT+NETWORKID=18`
`dropbox_log.csv` stays empty while `+RCV` prints	Gateway parser regression	Ensure `_split_payload` checks the comma at the declared length
Command rejected on the controller	Tag, window, command guard, or band	Check the field key matches, the sequence is newer, and the package is in band
LCD shows `I:INF` while nothing looks wrong	Staging marker present (SANDBOX_ONLY build)	The channel has written the marker; see Lab 3C
`ICV1` timing frame appears on the link	Covert exfiltration (SANDBOX_ONLY build)	Expected in the malware-track build; see Lab 3
Marker reappears after a reflash	Reserved-sector persistence	The payload is still in the reserved sector; erase it and close the gate (Lab 3)
Debugger changes channel behavior	CoreDebug `DHCSR` anti-debug	The channel suppresses itself while a probe is attached; see Lab 3D
Node relays data it should not	Untrusted re-broadcast	In production never define `SANDBOX_ONLY`; see Lab 4

Testing Philosophy and Coverage

Hardware bugs are expensive to find on the bench, so the firmware is written so that almost all of it can be tested on the host. The suite compiles the real src/*.c files against mock Pico SDK headers (test/mock/), replacing GPIO, I2C, UART, and time with deterministic fakes, and it compiles src/implant.c with a host mock for the CoreDebug DHCSR register and the reserved flash sector.

The mock GPIO can replay a recorded DHT11 waveform as an absolute time/level timeline, so the exact edge-timing decoder is exercised without a sensor.
The mock I2C records every LCD byte, so rendered text can be decoded and asserted.
The mock UART records outbound AT+SEND bytes and injects inbound +RCV lines, so the courier-to-gateway-to-locker path runs end to end with no radio.
The implant host mock lets the tests set the DHCSR anti-debug bits and read and write the reserved-sector marker without touching real silicon, and it exposes the timing transmit path so the ICV1 frame can be asserted.

Run the native test suite:

python3 scripts/run_tests.py

Or configure via CMake and CTest:

cmake -S test -B build-test -G Ninja && cmake --build build-test && ctest --test-dir build-test --output-on-failure

The suite has 145 cases and 468 checks with 0 failures, covering the full DHT11 waveform and every timeout shape, the locker state machine and its bounded travel, the sealed command path and its guards, the authorization window and state tag, the courier no-bypass path, fail-locked on link loss, the declared-length parser with hex-bearing payloads, the cryptographic primitives against published vectors, and the complete covert channel: ICV1 magic matching, timing frame construction, the eight-slot staging ring, the harvest and channel gates, write-once staging, re-install on boot, and anti-debug.

Verify 100% line coverage of owned firmware modules:

python3 scripts/check_coverage.py

The coverage report shows 2128 / 2128 lines, 100.00%. main.c is excluded from coverage by design. The Python adapter suite (test/test_field_crypto.py and test/test_dropbox_node.py) adds 17 more tests, including the RFC 9106 Argon2id known-answer test.

The harness itself is a small in-repo framework (test/harness/) so the repo vendors no third-party code and every owned file obeys the coding standard.

Generating Packet Artifacts

scripts/gen_packet.py writes the build-time generated header from the JSON artifact:

scripts/packet_artifact.json is the source of truth.
include/packet_artifact.h is the generated header, committed for the build guardrail.

Why these constants are compiled into firmware:

The RP2350 firmware has no runtime JSON parser or filesystem on this path.
include/packet_artifact.h is generated from the JSON so the frame size, node id, gateway address, wait time, servo pulses, DHT timeout, and provisioning constants are embedded in flash.
This is provisioned data; regenerate whenever you rotate node identity, gateway addressing, or key material.

To sync the committed header from the JSON artifact:

python3 scripts/gen_packet.py --from-json scripts/packet_artifact.json --header-out include/packet_artifact.h

The check_packet_artifact_header CMake target fails the build when the committed header is stale.

Code Standards

This repository enforces unusually strict standards because the point is to teach disciplined embedded and tooling practice, not just working code.

C standard

Every function body has no blank lines.
Every function body is at most eight lines (Doxygen comment blocks and lone braces excluded).
Every file, function, macro, type, and struct member carries Doxygen @brief documentation.
Naming: snake_case files/functions, UPPER_SNAKE macros, snake_case_t types.

Run the C audit:

python3 scripts/audit_c_standard.py

Python standard

Strict PEP8, four-space indents, snake_case, 79-character lines.
Every function has a NumPy-style docstring.
Every function executable body is at most eight lines, with no exceptions.
No blank lines inside function bodies.

Run the Python audit:

python3 scripts/audit_python_standard.py

Both audits must report nothing.

Project Layout

src/main.c: firmware entry point
src/monitor.c: state machine tying the courier remote, sealed command path, locker, courier-arrival request, climate sensor, and radio together
src/implant.c: SANDBOX_ONLY FROSTLINE covert channel (ICV1 preamble, timing encoder, eight-slot staging ring, reserved-sector staging and re-install, CoreDebug anti-debug)
src/locker.c: locker latch state machine and fail-locked policy
src/control.c: sealed unlock command path with a guarded command set and a bounded package band
src/dropbox_auth.c: authorization record, monotonic anti-replay window, authenticated state tag
src/sensor.c: DHT11 one-wire sampling and locker-climate-band classifier
src/display.c: 1602 LCD rendering over the PCF8574 I2C backpack
src/radio.c: RYLR998 provisioning, AT-command interface, and +RCV parser
src/status_led.c: red/yellow/green DENIED / COURIER WAITING / UNLOCKED annunciator
src/button.c: debounced courier-arrival input
src/servo.c: 50 Hz PWM locker actuator
src/ir_remote.c: VS1838B edge timing and NEC courier remote decoder
src/crc.c: CRC-16/CCITT-FALSE helper
src/chacha20.c, src/poly1305.c, src/crypto_aead.c, src/blake2b.c, src/argon2.c, src/crypto_kdf.c, src/envelope.c: the in-repo cryptographic stack
include/dropbox.h: board-level pin, provisioning, and implant configuration
include/implant.h, include/control.h, include/dropbox_auth.h, include/locker.h: channel, command, authorization, and locker interfaces
include/field_secrets.h: lab-only committed key material
include/packet_artifact.h: generated packet artifact header
test/test_dropbox_node_and_security.c, test/test_peripheral_and_crypto.c: comprehensive test suites
test/mock/: Pico SDK hardware mocks plus the implant CoreDebug and reserved-flash host mock
test/harness/: minimal in-repo test harness (strictly C-standard compliant)
scripts/gateway.py: logistics gateway with radio provisioning, authentication, CSV logging, and sealed command replies
scripts/spoof.py: forged and replayed command injection client
scripts/sim_edge.py: laptop drop-box node simulator
scripts/field_crypto.py: pure-Python interoperable crypto
scripts/gen_packet.py / scripts/packet_artifact.json: packet artifact generator and source
scripts/run_tests.py, scripts/check_coverage.py: test runner and coverage report
scripts/audit_c_standard.py, scripts/audit_python_standard.py: code-standard auditors
scripts/gen_banner.py: banner generator
paper.typ / paper.pdf: classroom paper describing the protocol, the channel, and the exercise
.github/workflows/release.yml: tag-driven UF2 release workflow

Glossary

AEAD: authenticated encryption with associated data; one operation for secrecy and integrity.
Anti-debug: a check that detects an attached debugger and changes behavior. Here it reads CoreDebug DHCSR at 0xE000EDF0 (bits C_DEBUGEN and C_HALT).
Anti-replay window: a monotonic sequence rule that rejects a valid frame that has already been used.
Argon2id: the memory-hard password hash (RFC 9106) used to derive the field key.
AT command: a short ASCII command (AT+...) understood by the radio.
Covert channel: a communication path that hides data inside a legitimate signal, here the preamble and timing of LoRa frames.
Declared length: the byte count the sender claims for a payload; the receiver slices exactly that many characters.
DHT11: a low-cost temperature/humidity sensor using a custom one-wire protocol, used here as the locker internal climate sensor.
Exfiltration: moving data off a device without an obvious channel; the signature failure of Act VI.
Fail locked: a fault drives the locker latch closed and returns the fail-safe package, the safe parcel state.
Field key: the key that seals frames on the wire and computes the state tag.
HD44780: the character-LCD controller inside a 1602 module.
I2C: a two-wire bus (SDA/SCL) used here for the LCD backpack.
ICV1: the 4-byte preamble that marks a FROSTLINE covert-channel frame.
Implant: code that runs on the device but is not part of its intended function. Here the SANDBOX_ONLY FROSTLINE covert channel.
Locker latch: the servo-driven door this node actuates.
LoRa: a long-range, low-power sub-GHz radio modulation.
Magic: a fixed byte string that a payload matches to identify its own frame. Here the 4-byte ICV1 preamble.
NEC: the infrared remote encoding the VS1838B decodes.
PCF8574: an I2C I/O expander that drives the LCD's parallel interface.
Reserved sector: the final flash sector at 0x103FF000, used here to hold the one-byte staging marker.
SANDBOX_ONLY: the build guard that compiles the benign covert channel. The clean firmware does not define it.
Staging marker: the 0xC7 byte the channel writes into the reserved sector.
Staging ring: the eight-slot buffer of synthetic delivery records.
State tag: a keyed tag over the authorization record that detects a tampered verdict.
Timing channel: encoding data in the duration, not the content, of a signal. Here 250 microseconds per byte.
UART: a serial port used to talk to the radio.
XChaCha20-Poly1305: the AEAD used for every sealed frame, with a 192-bit nonce and a 128-bit tag.

License

MIT License
