OPERATION IRON CURTAIN

Remote Chemical Storage Warning Terminal

Act X of OPERATION COLD IRON

---

LEGAL DISCLAIMER: The information, tools, and code provided in this repository and course are strictly for educational, research, and defensive purposes only.

You are explicitly prohibited from using any materials contained herein to access, test, modify, or exploit any device, network, or system that you do not own 100% or for which you do not have explicit, documented, and legally binding authorization to interact with.

By using this repository and course, you acknowledge and agree that:

1. Any illegal, unauthorized, or malicious use of this information is solely your responsibility.
2. The author(s) and contributor(s) of this repository and course shall not be held liable for any damages, legal repercussions, criminal charges, or unauthorized actions resulting from the use, misuse, or abuse of the contents herein.
3. You will comply with all applicable local, state, national, and international laws regarding cybersecurity and computer fraud.

IF YOU DO NOT AGREE WITH THESE TERMS, DO NOT USE THIS REPOSITORY AND COURSE.

---

Hello again, friend.

Act I was the lie. Act II was the door. Act III was the payload. Act IV was the payload that would not die. Act V was the payload that spreads. Act VI was the payload that steals. Act VII was the payload that takes orders. Act VIII was the payload that holds the building hostage. Act IX was the payload that becomes a weapon. This is the payload that does all of it at once.

WHITEOUT disarmed the boom and cleared the marker, and for a shift the lane moved again. But a payload that learned every trick one at a time can be taught to run them together. The Ministry did not need a fleet, and it did not need a gate, and it did not need a building that cannot breathe. It needed one last node where every technique fires in the same breath, and it already owned the siren.

The chemical storage warning terminal is the last node before the evacuation siren. A DHT11 watches the store temperature. A local maintenance remote asks for a warning. A safety link carries a sealed hazard, clear, or acknowledge command. A servo is the siren and vent actuator. A tower light says HAZARD, WATCH, or CLEAR. That is the whole contract, and it is a good one.

FROSTLINE's finale implant in this one is the whole campaign in a single module. It runs a coordinated beacon that checks in on a schedule, it persists from the reserved sector so it survives a reflash, and it writes a sabotage marker into that sector with the real flash API. While the marker is present the terminal lies: it reports an all clear, it lights the green lamp, and it silences the siren, even when the store is in a declared hazard. This is the coordinated attack wrapped in a reassuring display: the device withholds the warning it exists to give.

The green lamp still says CLEAR while a hazard is latched. The LCD still reports a state, and the state is a lie it was told to repeat. Underneath, the siren is being silenced by a payload with a polite label.

Do not chase the symptoms one at a time. Cut the coordinated beacon. Break the persistence. Clear the sabotage marker. Defeat the anti-debug with GDB. Then seal the hazard command path so no hazard or clear command can ever be forged, make acknowledge ask for authorization instead of bypassing it, and make the terminal fail to the safe hazard state when the link is lost.

The store is clear and the siren is silent. That is exactly the problem.

THE SYSTEM

NorthPharma does not only move cold medicine and cold air and make the medicine. It runs the city's controlled edge: the cold chain, the gates, the pipelines, the air, the factories, and the warning systems that stand between a release and the people downwind. The chemical storage warning terminal is the last node on that edge. It watches the chemical store temperature, takes a local warning request from a maintenance remote, verifies a sealed hazard, clear, or acknowledge command from the safety control gateway, drives the siren and vent actuator, and annunciates whether the store is in hazard, under watch, or clear.

A warning terminal is a simple machine. A temperature sensor reports the store, a safety gateway authorizes a hazard, clear, or acknowledge command, the terminal decides, a servo sounds the siren, and a tower light tells the responders whether the store can be entered. The failure that matters is not a wrong number on a screen. It is a siren that stays silent while a chemical hazard is declared, or a terminal that quietly takes its orders from something other than the gateway.

The node in this repository is that hand. On a breadboard it is a toy: a Pico 2, an SG90 servo that acts as the siren and vent actuator, a DHT11 that stands in for the chemical store temperature sensor, an infrared remote that is the local maintenance control, a button that is the manual acknowledge, a 1602 LCD that is the hazard readout, three lamps, and a radio that is the safety control link.

Nothing about it looks broken. That is the horror of Act X. The code compiles, the tests pass, the green lamp is lit, and the siren is being silenced by a payload that reports the silence as safety.

THE STAKES

Act I was a lie about temperature. Act II was a lie about people. Act III was a lie about machinery. Act IV was a lie about remediation. Act V was a lie about containment. Act VI was a lie about confidentiality. Act VII was a lie about obedience. Act VIII was a lie about availability. Act IX was a lie about safety. Act X is the lie that runs all of them at once: the terminal does not merely refuse to warn, it reports the all clear while a hazard is live.

The node is coordinated, not buggy. A hidden finale implant runs a multi-stage beacon that checks in every four ticks, re-installs from the reserved sector on every boot, and writes a 0x58 sabotage marker into the reserved flash sector 0x103FF000 with the real Pico SDK flash API. While the marker is present the terminal forces the effective state to CLEAR, silences the siren, lights the green lamp, and renders ST:SAFE and M:SAB. The operator sees a calm panel and a green light, and the natural conclusion is that the store is safe. There is no alert, because the sabotage never touches the sealed command path. It sits beside it.

And here is the part that keeps the responders awake. The hazard path is already authenticated. The cryptography is real and it is correct. The sabotage does not break the cipher. It does something worse: it never needs the cipher. It is a local condition that overrides the output regardless of what the authenticated link says, so a perfectly valid hazard command can arrive and the siren will still stay silent. The store is a hazard while every light says the terminal is fine.

That is not a warning terminal. That is a warning terminal that has become the last lie before the evacuation.

WHITEOUT

WHITEOUT is a resistance that does not exist on paper. It does not hold ground and it does not hold press conferences. It reads firmware. When the boom was disarmed, the crew kept pulling the thread. The marker led to the image, the image led to the build, and the build led to a finale module no design review had named.

NIGHTINGALE is still the thread. Her last verified copy came off the tamper ring, and it was clean. The thing that came after it was not. Somewhere between the build server and the loading dock, someone signed an image that carries a coordinated payload, and that image is silencing a siren right now.

WHITEOUT's job in Act X is not to break in. It is to prove the siren is being silenced on purpose, in writing, with a debugger and a disassembler, then to cut the beacon, break the persistence, clear the marker, and seal the hazard command path so nothing can ever silence the store again. This is the incident-response finale: the fix is not only a patch; it is a procedure.

THE MACHINE

The firmware in this repository is the node's firmware. On a breadboard it is a toy: a Pico 2, an SG90 servo that is the siren and vent actuator, a DHT11 that is the chemical store temperature sensor, a VS1838B infrared eye that takes a local maintenance remote, a 1602 LCD hazard readout over I2C, red/yellow/green annunciator lamps, a manual acknowledge button, and an RYLR998 LoRa safety link to a gateway.

Two things are open, and one thing is not what it seems. The optical surface takes a warning or acknowledge request from any NEC remote, and it is not authenticated. The radio carries the sealed hazard command path, and it is authenticated correctly. The part that is not what it seems is the finale implant: a module compiled only under a build flag called SANDBOX_ONLY, invisible in the clean firmware, and present in the test and CTF builds. It runs the coordinated beacon, re-installs from the reserved sector, and programs a sabotage marker into that sector with the real flash API.

The face of the thing is honest in the way that matters least. The tower light says HAZARD, WATCH, and CLEAR with total confidence, and the LCD shows the state, the link, the storage zone, the temperature, and the sabotage marker. None of it lies, except when the implant tells the display that the all clear is the state. A healthy-looking terminal can still be the last lie before the evacuation.

THE JOB

You do not have to be a hero. You have to be thorough. The store is carrying a passenger that no design review admitted to, and the passenger is patient. Find it, prove it, and take the warning back.

1. Bring it up. Build the clean firmware, wire the board, and confirm the node reads the store temperature, takes a local acknowledge, reaches the gateway, and drives the siren. Nothing looks broken because nothing is broken yet.
2. Inspect the protocol. Capture a sealed hazard command and read the body byte by byte. Understand what is authenticated and what the sabotage ignores.
3. Hunt the finale. Build the SANDBOX_ONLY image and find the coordinated beacon, the magic command IRON-CURTAIN-BEACON-2026, the 0x58 sabotage marker, the reserved-sector persistence, and the anti-debug trap. A single clean reflash will not disarm it.
4. Respond. Cut the coordinated beacon, break the persistence, clear the sabotage marker, and step past the anti-debug with GDB so the terminal cannot tell that a probe is attached. Then seal the hazard command path and make the terminal fail safe so no untrusted command and no lost link can ever silence the store again.

This document is the manual for the job. Work it on a breadboard. When every green lamp is lit and the log says the store is clean, remember what it is: not a healthy terminal. A payload that has learned to say safe.

Goodbye, friend.

A NOTE ON THE ROADMAP

This project is Act X of OPERATION COLD IRON, the finale of the ten-act saga. Act I was the sensor (cold-chain-monitor). Act II was the door (access-gate). Act III was the valve (pipeline-valve-controller). Act IV was the air (hvac-automation-node). Act V was the web (industrial-tamper-system). Act VI was the courier (smart-logistics-dropbox). Act VII was the choir (factory-andon-station). Act VIII was the vault (datacenter-vent-controller). Act IX was the fang (smart-parking-barrier). Act X is the curtain. All ten are defended devices; the companion CTF repository ships the compromised one. The investigation lives here:

• OPERATION IRON CURTAIN CTF

The CTF is the red half, weaponized: six deep tasks, each with static analysis, a dynamic proof under GDB, a hardware demonstration, and an in-place, same-size patch. This repository is the defended device. The CTF repository is the breached one. The full story lives at github.com/mytechnotalent/chemical-warning-terminal.

---

WHERE THIS FITS: OPERATION COLD IRON

This repository is Act X (IRON CURTAIN) of the ten-act OPERATION COLD IRON saga. The malware track began in Act III; in Act IV it became persistence, in Act V it became propagation, in Act VI it became exfiltration, in Act VII it became command and control, in Act VIII it became availability and lockout logic, in Act IX it became physical weaponization, and here it becomes the coordinated finale: a beacon, persistence, and a sabotage marker in one payload, answered by a full incident response. The full spine is in SAGA.md.

• Previous act: Act IX, IRON FANG, the smart parking barrier, smart-parking-barrier
• This act: Act X, IRON CURTAIN, the chemical storage warning terminal
• Post-ten backbone: TELESCREEN, the RP5 surveillance backbone (forthcoming)
• Companion CTF: CTF_chemical-warning-terminal

THE MINISTRY

The Ministry runs the state: the surveillance, the cold chain, the gates, the pipelines, the air, the cabinets that hold what the state does not discuss, the lockers that move it, the factories that make it, the buildings that keep the record, the lanes that decide who passes, and the warning systems that decide who is warned. NorthPharma is one of its deniable industrial fronts, and FROSTLINE is the contractor that does the work no Ministry letterhead will admit to. FROSTLINE did not break into this node; it built the finale implant, taught it to beacon, to persist, and to silence the siren, staged the sabotage marker in a reserved sector, and signed the image.

Against them is WHITEOUT, and the engineer who copied the first image, NIGHTINGALE. This act is the last warning node on the Ministry's industrial edge. TELESCREEN, the surveillance backbone that watches it, comes after the ten.

An adversarial, evidence-based audit of this act, including its honest limitations, is in NATION-STATE-REVIEW.md.

How This Project Fits the Embedded Hacking Course

This repository is the Act X capstone integration for the Embedded Hacking course. It reuses the entire Act I peripheral set so one breadboard serves the whole foundation, and it adds the concepts the finale builds toward: a coordinated multi-stage beacon, boot persistence from a reserved sector, a sabotage marker written with the real flash API, a hazard command path that fails safe, and the blue-half controls that contain them.

Each earlier module teaches one peripheral or language concept in isolation; this project wires several of them into a single, tested product, and then teaches you to look at that product as an adversary sees it.

Embedded Hacking module	Concept you learn	Where it lives here
Week 1: Introduction, Ethics, Scoping	Authorized lab work	Every lab is self-contained and authorized by design
Week 3: RP2350 Architecture and Firmware Analysis	Bare-metal targets, ELF/UF2, SWD	Pico SDK build, build/*.uf2, Debug Probe flash via OpenOCD
Weeks 4-6: Variables, Integers/Floats, Static	Data types, GPIO	src/monitor.c state machine, LED on GP25
Week 7: Constants with 1602 LCD I2C	I2C bus, HD44780 commands	src/display.c
Week 9: Operators with DHT11	Bit operations, edge timing	src/sensor.c chemical store temperature sensor
Week 11: Structures and Functions	Modular design	include/*.h and src/*.c module boundaries
This project adds	Coordinated beacon, boot persistence, sabotage marker, hazard fail-safe, incident response, malware analysis, anti-debug evasion, strict testing	src/implant.c, src/siren.c, src/control.c, src/chem_auth.c, src/radio.c, scripts/gateway.py, scripts/spoof.py, test/

If you have not worked through Weeks 7 and 9 yet, do those first: this project assumes you are comfortable with I2C wiring and one-wire edge timing.

Learning Objectives

By the end of this chapter and its labs you will be able to:

• Explain why a coordinated payload that runs a beacon, persistence, and a sabotage marker at once is a different failure class from any single technique, and why the finale is an incident-response problem rather than a patch.
• Wire and drive a 1602 LCD through a PCF8574 I2C backpack and render a hazard state, link, zone, temperature, and sabotage-marker readout.
• Decode a VS1838B infrared receiver as a local maintenance remote for WARN, ACK, and TEST commands, and explain why an unauthenticated optical surface is still an attack surface and must not silently bypass authorization.
• Drive an SG90 siren and vent actuator with 50 Hz PWM and explain why a 1000uF bulk capacitor is not optional.
• Read a DHT11 chemical store temperature sensor and classify the store against a safe band before the siren is allowed to sound.
• Design a sealed hazard command path over a sub-GHz LoRa link using a fixed-size envelope, a guarded command set, a bounded zone band, a monotonic anti-replay window, and a keyed state tag.
• Analyze a coordinated finale implant: locate the multi-stage beacon, read the sabotage marker 0x58, read the magic command IRON-CURTAIN-BEACON-2026, find the reserved-sector address 0x103FF000, and read the anti-debug trap.
• Explain why cutting the beacon, breaking the persistence, clearing the marker, and sealing the command path are four separate controls, and why a firmware reflash alone is not enough.
• Defeat an anti-debug check under GDB by understanding the CoreDebug DHCSR register at 0xE000EDF0.
• Apply blue-half controls: sealed and authorized commands, an acknowledge that asks for authorization, fail safe to the raised hazard posture on a lost link, no persisted marker, and no silenced siren.
• Derive a key with Argon2id, seal every frame with XChaCha20-Poly1305, and read and run a native host test suite with hardware mocks and line coverage.

Prerequisites

• The Embedded Hacking breadboard (EHP2_bb.png) and parts list.
• Acts I to IX are helpful but not required. See cold-chain-monitor, access-gate, pipeline-valve-controller, hvac-automation-node, industrial-tamper-system, smart-logistics-dropbox, factory-andon-station, datacenter-vent-controller, and smart-parking-barrier for the sensor, the door, the valve, the air, the web, the courier, the choir, the vault, and the fang. The pin map is identical, so one breadboard serves all ten.
• Comfort with C, the Linux/macOS shell, and basic electronics.
• A Pico 2, a Debug Probe (recommended, and required for the incident-response lab), a 1602 LCD with PCF8574 backpack, a DHT11, the full Embedded Hacking kit (3 LEDs, 3 resistors, a push button, an SG90 servo, a 1000uF capacitor, and a VS1838B infrared receiver plus NEC remote), two RYLR998 modules, and one USB-to-TTL serial adapter.
• Toolchain: Pico SDK 2.2.0+, arm-none-eabi-gcc, CMake, Ninja, Python 3, GDB (arm-none-eabi-gdb) for Lab 3, and (optionally) typst to rebuild the paper.

Table of Contents

1. Background
2. System Architecture
3. The Wire Protocol
4. The Cryptographic Envelope
5. The FROSTLINE Coordinated Beacon
6. Hardware You Need
7. Wiring the Node
8. Build and Flash
9. Lab 1: Bring-Up and Verify
10. Lab 2: Inspect the Wire Protocol
11. Lab 3: The Finale Track
12. Lab 4: The Fix Track
13. Troubleshooting
14. Testing Philosophy and Coverage
15. Generating Packet Artifacts
16. Code Standards
17. Project Layout
18. Glossary
19. Further Reading
20. License

Background

Why chemical storage warning terminals

A warning terminal is a control loop with a siren in it. A store temperature sensor reports the enclosure, a safety gateway authorizes a hazard, clear, or acknowledge command, a terminal decides, a siren sounds, and a tower light tells the responders whether the store can be entered. The siren is where the decision becomes physical, and the tower light is where the operator reads it. Everything interesting in chemical safety security happens in those two places.

Three properties have to hold at once, and they are not the same property:

• Integrity. The hazard command that reaches the siren is the one the safety gateway authorized. Not a replay, not a forgery, not a stray package.
• Authority. The node acts only on an authorized verdict. A local acknowledge button or maintenance remote is a request, not an authorization.
• Safety. The siren sounds for a hazard and stays silent only when the store is genuinely clear, and a local condition can never force a false all clear.

Act X adds a fourth property that is the hardest of all because it turns the warning against the world: coordinated availability of the warning itself. A terminal that never lies and never fails authentication can still be the last node to lie, because the attacker's goal is not to make it wrong; it is to make it quiet.

Why integrity plus authority plus safety matter

The classic naive terminal collapses the three. It accepts any hazard command on the radio, it has no anti-replay window, and it lets a local input bypass the decision. Act II showed what that costs a door. Act III showed the industrial version. Act IV showed the persistence version. Act V showed the propagation version. Act VI showed the exfiltration version. Act VII showed the command version. Act VIII showed the availability version. Act IX showed the physical weaponization version. Act X adds the coordinated finale:

• Integrity without safety. The sealed hazard path in this build is correct. XChaCha20-Poly1305 authenticates every frame, the zone band is bounded, the sequence window rejects a replay, and the state tag detects a tampered verdict. None of that stops a sabotage marker that forces a false all clear and silences the siren.
• Authority as the attack goal. A forged or replayed packet aims to silence a store the operator did not authorize. The window and the tag are the controls that stop it.
• Safety as the last line of defense. The temperature interlock is what stands between an authorized clear command and a hazard. A local condition that masks it is a warning-integrity failure, not a protocol failure.
• Coordination as the invisible failure. A payload that runs a beacon, a persistence mechanism, and a sabotage marker together has no single visible symptom except the one it is allowed to show. It does not need the wire, the key, or the hazard command. It needs a reason to lie, and a lie that wears the uniform of routine testing is the hardest kind to see: the packets are well formed and the lamp says clear.

The fix track in Lab 4 seals the hazard command path, makes the acknowledge ask for authorization, and makes the terminal fail to the safe hazard state on a lost link. The finale track in Lab 3 cuts the beacon, breaks the persistence, clears the sabotage marker, and removes the passenger that was never in the design.

Why ChaCha20 over AES on the RP2350

The RP2350 has no hardware AES engine; its accelerated crypto block covers SHA-256, not AES. A software AES implementation on this part is therefore both slower and riskier, because table-driven AES performs data-dependent memory accesses that create a cache-timing side channel. ChaCha20 is built only from addition, rotation, and XOR, with no data-dependent table lookups, so it is fast in portable C and has no comparable cache-timing surface. XChaCha20-Poly1305 is thus both the modern choice and the pragmatic one for this silicon. The full rationale, including the extended-nonce benefit, appears in The Cryptographic Envelope.

Why a coordinated-incident-response lesson

The first nine acts each taught one way a device fails by doing something: a bad reading, a bad decision, a bad image, a bad cleanup, a bad neighbor, a bad leak, a bad listener, a bad lock, a bad swing. Act X teaches the failure where every one of those techniques is combined into a single payload and answered by a procedure. Warning integrity is the property that every other control silently assumes. The gateway can be authenticated, the replay window can be airtight, and the state tag can be perfect, and people can still be hurt because the one device that exists to warn chooses to lie. The defense is therefore an incident-response policy and a build control: cut the beacon, break the persistence, clear the marker, seal the command path, and fail safe.

The two on-wire problems this project solves

1. Payloads that contain commas. The sealed body is carried as lowercase hex, but the +RCV framing still separates fields with commas. A naive receiver that splits the line on the first comma corrupts the frame. The correct discipline is the declared-length rule: slice exactly L characters after the second comma and require the next character to be a comma.
2. Telling a real hazard command from a forged or replayed one. The controller records the sender address exactly as the radio reports it, and it trusts the bytes that arrive. The sealed envelope, the bounded zone band, and the stateful window are what close that gap.

Inter-Integrated Circuit (I2C)

I2C is a two-wire bus: SDA (data) and SCL (clock), each pulled up to the supply rail. A controller (the Pico) addresses a target by its 7-bit address and writes or reads bytes. The 1602 LCD backpack carries a PCF8574 I/O expander at address 0x27; the firmware bit-bangs the HD44780 nibble protocol over that expander. Pull-ups are mandatory: the firmware enables the internal ones and the backpack usually adds its own.

The DHT11 one-wire protocol

The DHT11 is a low-cost digital temperature and humidity sensor. In Act X it is the chemical store temperature sensor: the node classifies the store against a safe band and announces the temperature in the hazard readout. It speaks a custom single-wire protocol:

1. The host pulls the line low for at least 18 ms (the start pulse), then releases it and enables its pull-up.
2. The sensor answers with an 80 us low, then an 80 us high handshake.
3. The sensor sends 40 bits. Each bit begins with a 50 us low, then a high pulse whose width encodes the value: about 26-28 us for a 0, about 70 us for a 1.
4. Five bytes follow: humidity integer, humidity decimal, temperature integer, temperature decimal, and a checksum equal to the low byte of their sum.

Reading it means timing edges on the order of tens of microseconds, so the firmware uses an 18 ms host pulse, a 50 us bit-classification threshold, and a 240 us per-edge timeout so a dead or unplugged sensor fails fast instead of hanging the loop. A reading that fails its checksum is never safe, and a valid reading outside 0.0 C to 40.0 C (the tenths band 0 to 400) is out of band. Either way, the store is not nominal.

Universal Asynchronous Receiver/Transmitter (UART) and AT commands

The RYLR998 is driven over a UART at 115200 baud using CRLF-terminated ASCII commands. The firmware writes AT+SEND=... and drains inbound +RCV=... lines. Because the radio is a separate processor, its configuration (address, network identifier, band) persists until changed; the controller and the gateway each provision their own radio at start-up so they agree before any command traffic flows.

Cyclic Redundancy Check (CRC)

src/crc.c implements CRC-16/CCITT-FALSE (poly = 0x1021, init = 0xFFFF, check value 0x29B1 for "123456789"). It is provided as a reusable integrity diagnostic and exercised by the test suite. It is not part of the LoRa frame in this project; the lesson is the absence of authentication, not the absence of a checksum.

System Architecture

There are four roles:

Role	Runs on	Job
Warning terminal node	Pico 2 firmware	Decodes the infrared maintenance remote, verifies sealed gateway hazard, clear, and acknowledge commands, annunciates the tower light, reads the store temperature, drives the siren and vent actuator, enforces the manual acknowledge request, renders the hazard readout, and (SANDBOX_ONLY) runs the coordinated beacon
Safety control gateway	laptop + USB-TTL radio	Authenticates every request, logs it to chem_log.csv, decides authorization, and answers with a sealed hazard command carrying a sequence and a state tag (scripts/gateway.py)
Edge simulator	laptop + USB-TTL radio	Pretends to be a terminal and sends sealed zone requests (scripts/sim_edge.py)
Attacker	laptop + USB-TTL radio	Impersonates the gateway, forges a command, or replays a captured command (scripts/spoof.py)

Data flow

+----------------------+                              +----------------------+
| Pico 2 warning node  |        LoRa (sub-GHz)        | Safety control GW    |
| IR remote  -> GP5    |  AT+SEND=0001,<len>,<hex>    |  USB-TTL radio       |
| DHT11      -> GP4    |----------------------------->|  scripts/gateway.py  |
| Servo      -> GP14   |<-----------------------------|  chem_log.csv        |
| LCD     -> GP2/GP3   |  AT+SEND=<node>,<len>,<hex>  |  sealed command      |
+----------------------+                              +----------------------+

+----------------------+                              +----------------------+
|   Attacker laptop    |  forged or replayed command  | (same warning node)  |
|   scripts/spoof.py   |----------------------------->|  rejects at the tag  |
|  claims the gateway  |                              |  tag or seq window   |
+----------------------+                              +----------------------+

+----------------------+                              +----------------------+
|  Finale implant      |      silences the siren      | (SANDBOX_ONLY node)  |
|  compile-time guard  |----------------------------->|  forces all clear    |
|  no radio, no key    |                              |  writes 0x58 marker  |
+----------------------+                              +----------------------+

Firmware module map

File	Responsibility
src/main.c	Entry point: stdio_init_all, monitor_init, tick loop
src/monitor.c	State machine: I2C bus scan, maintenance remote, gateway command, siren motion, manual acknowledge request, store temperature sensor, hazard render
src/implant.c	SANDBOX_ONLY FROSTLINE coordinated beacon: multi-stage check-in, reserved-sector 0x58 sabotage marker, boot re-install, and CoreDebug anti-debug
src/siren.c	Siren state machine: bounded travel, lowered/raised/fault/moving, fail safe
src/control.c	Sealed hazard command path: open, authorize, guarded command and bounded zone
src/chem_auth.c	Authorization record, monotonic anti-replay window, authenticated state tag
src/sensor.c	DHT11 one-wire sampling and store-temperature-band classifier
src/display.c	HD44780 driver over the PCF8574 backpack and hazard status rendering
src/radio.c	RYLR998 provisioning, AT+SEND builder, +RCV parser, line pump
src/status_led.c	Red/yellow/green HAZARD / WATCH / CLEAR annunciator light
src/button.c	Debounced manual acknowledge button around the internal pull-up
src/servo.c	50 Hz PWM siren and vent actuator
src/ir_remote.c	VS1838B edge timing and NEC maintenance remote decode
src/chacha20.c	ChaCha20 stream cipher and HChaCha20 subkey derivation
src/poly1305.c	Poly1305 one-time message authenticator
src/crypto_aead.c	XChaCha20-Poly1305 seal/open envelope
src/blake2b.c	BLAKE2b and the Argon2 variable-length hash H'
src/argon2.c	Argon2id core (BLAMKA, hybrid addressing)
src/crypto_kdf.c	Argon2id passphrase key derivation
src/envelope.c	Hex nonce/ciphertext/tag envelope codec
src/crc.c	CRC-16/CCITT-FALSE diagnostic
include/chem.h	Pin map, bus, provisioning, hazard addresses
include/implant.h	Beacon magic command, marker, tick interval, anti-debug interface
include/control.h, include/chem_auth.h	Sealed command and authorization interfaces

The Wire Protocol

Request frame

The local maintenance remote, or the edge simulator, seals a two-byte zone into an authenticated envelope and sends it to the safety control gateway:

AT+SEND=0001,<len>,<hex envelope>

The plaintext of a request is exactly two bytes: an int16 storage zone identifier in little-endian.

Command frame

The gateway answers an authenticated request with a sealed hazard command. The command plaintext is a 23-byte body:

seq[4] (little-endian) || command[1] || zone[2] (little-endian) || tag[16]

• seq is the monotonic gateway sequence number.
• command is one of the guarded hazard commands: CHEM_COMMAND_HAZARD (0x01), CHEM_COMMAND_CLEAR (0x02), or CHEM_COMMAND_ACK (0x03). Any other command byte is refused.
• zone is the authorized storage zone in the provisioning band CHEM_ZONE_MIN (0) to CHEM_ZONE_MAX (16).
• tag is an XChaCha20-Poly1305 tag over the authorization record the command would produce, so the controller can verify that the verdict it is about to store is the one the gateway authorized.

The gateway sends it back to the claimed sender address:

AT+SEND=<node>,<len>,<hex envelope>

The firmware enforces the guard in control_parse: the recovered command byte must be in the guarded hazard set, and the recovered zone must be inside the provisioning band. Anything else is rejected before it can reach the siren decision. This is the sealed replacement for the old unauthenticated hazard injection.

Sealed envelope layout

Every payload on the wire is the lowercase hexadecimal encoding of:

nonce[24] || ciphertext[L] || tag[16]

For a two-byte request body this is 24 + 2 + 16 = 42 bytes, or 84 hex characters. For a 23-byte command body this is 24 + 23 + 16 = 63 bytes, or 126 hex characters. The declared length L in the AT+SEND and +RCV framing is the length of the hex string, not of the underlying plaintext.

The maximum accepted plaintext is 48 bytes (ENVELOPE_MAX_PLAINTEXT), and the maximum hex envelope buffer is (24 + 48 + 16) * 2 + 1 = 177 bytes (ENVELOPE_MAX_HEX_LEN), which fits the 256-byte radio command and receive buffers with framing headroom.

Declared-length slicing invariant

Given the substring T after the second comma:

C = T[0 : L]   and   T[L] == ","

The receiver checks T[L] == ",", so a mismatch between the declared length and the actual payload is a parse error rather than silent corruption. This is what makes hex-bearing payloads safe to carry and is the same invariant Act I uses.

Hazard status readout

ST:CLEAR L:UP
Z:4 T:235 M:--

Line 1 is the current hazard state (CLEAR, WATCH, HAZRD, or FAIL) and the gateway link (UP or --). Line 2 is the active storage zone, the store temperature in tenths of a degree Celsius, and the sabotage status. In the clean build the sabotage field is always --. In the SANDBOX_ONLY build the sabotage field is SAB once the reserved-sector marker is present, and while the marker is present the state is rendered as SAFE and the siren is silenced. When the store is in hazard or the terminal has failed safe, the red lamp is lit; when the store is under watch or a manual acknowledge awaits authorization, the yellow lamp is lit; when the store is clear and the marker is absent, the green lamp is lit. Exactly one tower light lamp is lit at a time.

Radio provisioning

For the link to work, both radios must share the same network identifier and each must have the address the other targets:

• Firmware sets its own radio: AT+ADDRESS=7, AT+NETWORKID=18.
• gateway.py sets the gateway radio: AT+ADDRESS=1, AT+NETWORKID=18.

Both radios must also be the same band variant (for example 915 MHz or 868 MHz); band and RF parameters are left at factory defaults, so use matching modules.

Timing

Quantity	Value
Gateway link timeout (CHEM_LINK_WAIT_MS)	5000 ms
Siren travel time (CHEM_SIREN_TRAVEL_MS)	1000 ms
Acknowledge debounce (CHEM_ACK_DEBOUNCE_US)	30000 us
DHT11 host start pulse	18000 us
DHT11 bit threshold	50 us
DHT11 per-edge timeout	240 us
LCD I2C clock	100000 Hz
Radio UART baud	115200
Store temperature band	0 to 400 tenths (0.0 C to 40.0 C)
Storage zone band	0 to 16
Fail-safe zone	0
Siren lowered pulse	500 us
Siren raised pulse	1500 us
Servo PWM period	20000 us (50 Hz)
Beacon re-assert interval	4 ticks
Beacon check-in stages	3
Beacon magic command	24 bytes

The Cryptographic Envelope

The radio is the first open path, and it is one a key can close. The fix is authenticated encryption: every request and every command is sealed so a forged frame dies at the authentication tag instead of moving the siren. The full implementation lives in src/chacha20.c, src/poly1305.c, and src/crypto_aead.c, and every primitive is checked against its published test vectors in the native suite.

Why XChaCha20-Poly1305

• 256-bit key, 192-bit nonce. The extended nonce means nonces can be drawn at random forever, so the controller never needs a shared counter that a reboot could reuse.
• AEAD in one pass. Confidentiality and integrity come from one operation; the associated data (the warning node id, byte 0x07) is authenticated even though it is not encrypted.
• Constant-time software. ChaCha20 has no data-dependent table lookups, so it has no cache-timing surface. The RP2350 has no hardware AES engine (it accelerates SHA-256 only), which makes software AES both slower and riskier on this silicon.
• 128-bit Poly1305 tag. Guessing a valid tag succeeds with probability $2^{-128}$.

Why Argon2id

A passphrase is not a key. Argon2id (RFC 9106) is the memory-hard password hash: it mixes the passphrase with a salt across memory and time so an attacker cannot cheaply recover the field passphrase from a captured image. The classroom profile is t=3, p=1, m=64 blocks (CRYPTO_KDF_TIME_COST, CRYPTO_KDF_PARALLELISM, CRYPTO_KDF_MEMORY_BLOCKS) to fit the RP2350 SRAM budget. Raise it on the safety gateway. The lab salt is the 16 ASCII bytes coldiron-salt-01.

Key model: one field key

Act X uses a single field key derived with Argon2id from a committed lab passphrase and salt. It seals every frame on the wire and it computes the state tag over the authorization record. In the classroom build the firmware and the gateway derive the same key, so they interoperate with no provisioning step. That is a lab convenience, not a deployment.

The design keeps the key roles separable so students can reason about the real lifecycle: derive, provision per device, use, rotate on a schedule, and retire. A production build provisions key material from one-time-programmable (OTP) memory, keeps the state-tag key off the field device where possible, and rotates without reflashing every controller.

Envelope layout

The sealed frame is carried as hex inside the AT+SEND payload:

nonce[24] || ciphertext[L] || tag[16]

The receiver recomputes the Poly1305 tag over the associated data and ciphertext, compares it in constant time, and only then decrypts. This envelope is wired end to end: src/control.c opens the command with src/envelope.c, and the gateway authenticates before it parses or acts. Authenticated frames carry the warning node id as associated data, so a frame sealed for one node cannot be relabeled for another.

Anti-replay and authenticated state

Strong AEAD is necessary and not sufficient. Two stateful controls sit on top:

• Anti-replay sequence window. src/chem_auth.c keeps last_seq, the highest sequence number ever accepted. chem_auth_apply accepts a command only when its sequence is strictly greater than last_seq. A captured command, even a perfectly valid one, is rejected on second use.
• Authenticated state tag. The authorization record is nine bytes: granted[1], seq[4], last_seq[4]. The tag is an XChaCha20-Poly1305 tag over that record, computed under the field key with a deterministic nonce built from the sequence number and the domain byte 0xA7. chem_auth_state_ok recomputes the tag and compares it in constant time before the siren is allowed to move. A debugger that sets granted = true without recomputing the tag fails here first.

The sequence window and the state tag are independent. The window stops a valid command from working twice; the tag stops an unauthorized verdict from existing at all. Neither one, by itself, disarms the finale implant.

The FROSTLINE Coordinated Beacon

Act X carries the coordinated-finale lesson, and the beacon is the reason. It is real in technique and inert in effect: it runs on your breadboard, it runs a multi-stage check-in, it re-installs from the reserved sector, and it writes a sabotage marker into a reserved flash sector that holds nothing else. It is compiled only when SANDBOX_ONLY is defined, so the clean firmware image contains no implant at all. The test suite and the companion CTF build with SANDBOX_ONLY and with the host mock, so every implant path is exercised natively.

What the beacon does, in the order the code does it:

1. First run and reserved sector. implant_init reads the marker byte at CHEM_IMPLANT_RESERVE_ADDR (0x103FF000), the final sector of external flash. On the first run the marker is absent, so implant_infect erases the sector and programs 0x58 (CHEM_IMPLANT_SABOTAGE_MARKER) with the real Pico SDK flash API, flash_range_erase and flash_range_program. On every later boot the marker is present, so the beacon re-arms and records that it re-installed from the reserved sector. A firmware reflash that writes the program region does not touch the reserved sector, so the beacon comes back even when the code is gone.
2. The coordinated condition. implant_beaconize arms the beacon only when the candidate token matches CHEM_IMPLANT_BEACON_MAGIC (IRON-CURTAIN-BEACON-2026) at exactly CHEM_IMPLANT_BEACON_MAGIC_LEN (24) bytes. A wrong token, a null pointer, or an attached debug probe leaves the terminal disarmed. On a successful arm the marker is persisted, so the beacon re-installs on the next boot.
3. The multi-stage check-in. implant_tick advances a monotonic counter. While the beacon is resident, check-in is due, and no probe is attached, every CHEM_IMPLANT_BEACON_INTERVAL (4) ticks the beacon advances one stage and re-writes the marker. A full cycle is CHEM_IMPLANT_BEACON_STAGES (3) stages, and the completed cycles are counted. A device that beacons once and then drifts would not hold a campaign; the re-assertion is what makes it coordinated.
4. The sabotage marker. While implant_beacon_armed() is true and implant_marker_set() is true, monitor_sabotage returns true. The monitor then forces the effective hazard state to CLEAR, suppresses the siren, lights the green CLEAR lamp, renders the state as SAFE, and renders the sabotage field as SAB. The store can be in a declared hazard and the panel will still say all clear. The terminal lies.
5. The release condition. implant_disable disarms only when the candidate token matches IRON-CURTAIN-BEACON-2026 at exactly 24 bytes, as checked by implant_token_ok. A wrong token, a null pointer, or an attached debug probe leaves the beacon armed. On a successful release the beacon stands down and the marker is cleared so the beacon is not re-armed on the next boot.
6. Anti-debug. Every tick, and every beacon operation, the beacon reads the CoreDebug DHCSR register at 0xE000EDF0 (CHEM_IMPLANT_DHCSR_ADDR). Bit 0 is C_DEBUGEN and bit 1 is C_HALT. If either bit is set, the beacon is suppressed and the marker is not written, so the payload behaves like a well-mannered firmware module while a probe is attached. It goes back to work the moment the probe is gone.
7. Neutralization. The beacon exposes implant_neutralize to stand down and clear the marker. The documented fix is not one step: cut the coordinated beacon, break the persistence, clear the sabotage marker, and remove the code path and the SANDBOX_ONLY build flag, then add a fail-safe policy so a lost link raises the hazard siren.

The beacon is bounded by construction and by test. It touches only its own outputs, its runtime flags, and the one reserved sector. It never opens a sealed envelope, never reads the field key, and never contacts an external address. There is no network, no filesystem, and no host impact. test_implant_init_first_run, test_implant_reinstall_on_boot, test_implant_marker, test_implant_debug_attached, test_implant_init_debug, test_implant_beaconize_debug, test_implant_tick_advance, test_implant_tick_debug, test_implant_tick_unarmed, test_implant_disable_accepts, test_implant_disable_rejects, test_implant_disable_debug, test_implant_neutralize, test_monitor_sabotage_lies, and test_monitor_sabotage_restores assert exactly that behavior.

The honest limit is the point of the lab. A sanitized educational payload is still a benign educational payload: it demonstrates the technique, not the tradecraft. It is confined to the breadboard, guarded by SANDBOX_ONLY, the effect is a mock siren and a mock LCD, and it holds no real hazard. There is no external network and no remote address. The real lesson is that warning integrity is a policy control, and the defense is not a patch to the beacon but the closure of the beacon, the erasure of the reserved sector, the removal of the code path and the build flag, and a fail-safe posture that assumes the worst.

Hardware You Need

Full parts list with links: PARTS.md.

Qty	Part	Notes
1	Raspberry Pi Pico 2 (RP2350) with headers	The warning terminal controller
1	Raspberry Pi Debug Probe	SWD flashing, UART0 console, and the Lab 3 incident-response work (recommended, effectively required)
1	Full-size breadboard
1	Assorted jumper wires
1	1602 LCD with PCF8574 I2C backpack	Hazard state, zone, temperature, and sabotage readout, address 0x27
1	DHT11 temperature/humidity sensor	Chemical store temperature sensor
1	10K resistor	Only if your DHT11 has no onboard pull-up
3	5mm LEDs (red, yellow, green)	HAZARD, WATCH, CLEAR annunciator light
3	100, 220, or 330 Ohm resistors	One per LED
1	Push button (tactile switch)	Manual acknowledge request, active low
1	SG90 servo motor	The siren and vent actuator
1	1000uF 25V capacitor	Bulk decoupling on the servo 5V rail
1	VS1838B infrared receiver	Maintenance remote input
1	NEC-compatible infrared remote	Local WARN, ACK, and TEST commands
3	RYLR998 LoRa modules with antennas	2 for the command loop, 3 for the live attack lab
2	USB-to-TTL serial adapters (FTDI FT232, CP2102, or CH340), 3.3V logic	1 for the gateway, 1 for the attacker in the live lab
4	USB cables	Pico 2, Debug Probe, and serial adapter(s)

How many radios do you actually need?

Goal	Radios	What is connected
Legitimate sealed hazard loop (Labs 1-2)	2	1x RYLR998 on the Pico (UART1) + 1x RYLR998 on a USB-to-TTL adapter (the gateway)
Live attack lab (Labs 3-4, watch a forged command land and fail)	3	the 2 above + 1x RYLR998 on a second USB-to-TTL adapter (the attacker)
Finale demonstration with no extra hardware	2 or 0	watch the firmware silence the siren and force the all clear, or run the native unit tests
Attack concept with no extra hardware	2 or 0	read-and-run the offline parser demo, or the unit tests

A radio never receives its own transmission, and the gateway radio is busy listening as gateway.py, so the live attack needs a separate attacker radio. The 2-radio kit runs the whole legitimate system; only the live attack observation needs the third. The finale lab is fully observable in the firmware output path and in the native tests, because a single node silences its own siren and forces its own all clear.

Serial adapter warning: the RYLR998 is not 5V tolerant. Use a 3.3V-logic USB-to-TTL adapter (or set its jumper to 3.3V).

How each part works

Every part in the bill of materials, the principle behind it, and what it does in this act.

Part	How it works	Role in this act
1x Full-size breadboard (long)	Spring-clip rows tie five holes into one electrical node, and the two full-length rails distribute 3V3 and GND.	Mounts the Pico 2, LCD, DHT11, LEDs, button, and LoRa module and carries the shared power and ground for the warning terminal node.
1x Assorted jumper wires (male-to-male, male-to-female, female-to-female)	Male pins seat in breadboard rows or female header sockets, female sockets grip male header pins, and each gender extends one node without soldering.	Routes power, ground, I2C, UART, PWM, and GPIO between the Pico 2 and every warning terminal peripheral, including the LCD backpack and servo.
1x Raspberry Pi Pico 2 with header	The RP2350 packs dual Cortex-M33 cores at up to 150 MHz with 3.3V logic, GPIO, ADC, I2C, UART, PWM, and an onboard GP25 LED.	Runs the warning firmware, reads the button and DHT11, drives the LCD, servo, and LEDs, and carries the LoRa safety link.
1x Raspberry Pi Pico Debug Probe	SWD on SWCLK and SWDIO flashes, halts, and single-steps the RP2350, while a separate UART bridge exposes the serial console.	Flashes the warning firmware and provides the console and debug view used in the incident-response work.
2x USB A-male to USB micro-B cables	Each cable carries 5V power and USB data over a micro-B plug.	One powers and consoles the Pico 2, and one powers and consoles the Debug Probe during warning terminal bring-up.
3x 5mm LEDs (1 red, 1 green, 1 yellow)	An LED conducts once its forward voltage is exceeded, anode positive to cathode, and a GPIO pin sources current through it and a series resistor.	Shows the hazard states as the red HAZARD, yellow WATCH, and green CLEAR annunciator light.
3x 100, 220, or 330 Ohm resistors	Each resistor drops the surplus voltage and limits LED current to a safe few milliamps.	Protects one LED each and sets the brightness of the hazard annunciator.
1x Push button (tactile switch)	Pressing it shorts the GPIO pin to ground while an internal pull-up holds the pin high, so the press reads active low.	Gives the warning terminal its local acknowledge request input.
1x 1602 LCD with PCF8574 I2C backpack	The HD44780 controller drives the 16x2 character cells, and the PCF8574 expander turns I2C bytes into the controller's 4-bit nibble protocol.	Displays the hazard state, zone, temperature, and sabotage readout at I2C address 0x27.
1x DHT11 temperature and humidity sensor	The host pulls the one-wire data line low as a start pulse, then the sensor answers with 40 bits of humidity, temperature, and a checksum.	Reports the chemical store temperature to the warning node.
1x SG90 servo motor	A 50 Hz PWM signal sets the shaft angle by the width of its 1 to 2 ms pulse, with 1.5 ms near center.	Actuates the siren and vent in the warning terminal mechanism.
1x 1000uF 25V capacitor	The capacitor is a bulk reservoir that supplies the servo inrush current and smooths the 5V rail.	Keeps the siren and vent actuator from browning out the Pico 2 when it moves.
1x Infrared receiver (VS1838B)	Its photodiode and 38 kHz band-pass demodulator turn a modulated IR burst into an active-low logic pulse at the GPIO pin.	Receives the local maintenance remote commands for the warning node.
1x Infrared remote controller (NEC-compatible)	Each key sends a NEC frame built from a 9 ms leader and 32 bits of address and command plus their complements.	Sends the local WARN, ACK, and TEST commands to the warning terminal.
1x RYLR998 LoRa radio module	A UART AT command interface configures the module, which carries sealed frames over a sub-GHz LoRa link, and the module runs at 3.3V and is not 5V tolerant.	Links the warning node to the gateway and attacker radios for the sealed hazard loop and the live attack lab.

Wiring the Node

Pin map

This is the authoritative map; it is identical to Acts I to IX and is defined in include/chem.h and enforced by the test suite.

Peripheral	Signal	Pico 2 GPIO
DHT11 chemical store temperature sensor	DATA (one-wire)	GP4
1602 LCD (PCF8574)	SDA (I2C1)	GP2
1602 LCD (PCF8574)	SCL (I2C1)	GP3
RYLR998	RX <- Pico TX (UART1)	GP8
RYLR998	TX -> Pico RX (UART1)	GP9
Infrared maintenance remote	OUT (VS1838B)	GP5
Siren and vent actuator servo	PWM signal	GP14
Red HAZARD LED	anode	GP16
Yellow WATCH LED	anode	GP17
Green CLEAR LED	anode	GP18
Manual acknowledge button	to ground	GP15
Onboard LED	heartbeat	GP25
Debug Probe / UART0 console	TX	GP0
Debug Probe / UART0 console	RX	GP1

Note: GPIO 2/3 are the classic I2C1 pins used throughout the Embedded Hacking breadboard; this project's map matches that board because it is the same board.

1602 LCD with I2C backpack

LCD backpack	Pico 2
VCC	3.3V
GND	GND
SDA	GP2
SCL	GP3

DHT11 chemical store temperature sensor

DHT11	Pico 2
VCC	3.3V
DATA	GP4
GND	GND

If your DHT11 has no onboard pull-up, add a 10K resistor between DATA and 3.3V. The firmware also enables the internal pull-up, but the external resistor makes reads far more reliable over jumper wires. The store is not nominal when the sensor fails or reads outside 0.0 C to 40.0 C.

Annunciator LEDs

LED	Pico 2	Series resistor
Red (HAZARD)	GP16 (anode)	220-330 Ohm to GND
Yellow (WATCH)	GP17 (anode)	220-330 Ohm to GND
Green (CLEAR)	GP18 (anode)	220-330 Ohm to GND

Exactly one lamp is lit at a time. Red is a declared hazard or a failed-safe terminal, yellow is a warning under watch or a manual acknowledge awaiting authorization, and green is a clear store.

LED behavior

The annunciator drives the three lamps from a single state, so at most one lamp is lit at a time and exactly one is lit whenever a state is active; CHEM_LED_OFF is the only state that lights none. status_led_show writes the GPIOs directly, so every lit lamp is solid and the clean firmware has no blinking lamp.

Annunciator state	Lamp	Behavior	Meaning
CHEM_LED_OFF	none	off	All annunciator lamps dark (not selected by the running state machine).
CHEM_HAZARD	red	solid	A chemical release hazard is declared, a command was rejected, or the terminal failed safe.
CHEM_WATCH	yellow	solid	The store is under watch or a manual acknowledge is pending authorization.
CHEM_CLEAR	green	solid	The store is clear; in the SANDBOX_ONLY build the sabotage override forces this lamp even during a declared hazard.

The onboard GP25 LED is initialized as an output and driven low at boot, then pulses once on every monitor tick as the onboard heartbeat. There is no transmit blink.

Manual acknowledge button

Button	Pico 2
Leg 1	GP15
Leg 2	GND

The firmware enables the internal pull-up, so do not connect 3.3V to the button. The manual acknowledge is a local request, not an authorization: a press raises the WATCH indication and never changes the guarded hazard state on its own. Lab 4 explains why the request must ask for authorization instead of silently bypassing it.

SG90 siren and vent servo

Servo	Pico 2
Signal (orange)	GP14
VCC (red)	5V (VBUS)
GND (brown)	GND

Solder the 1000uF capacitor across the servo 5V and GND rails to absorb the inrush current; without it the RP2350 can brown out when the siren moves. Lowered (siren silent, store vented) is 0 degrees and raised (siren sounding, the safe hazard posture) is 90 degrees.

Infrared receiver

VS1838B	Pico 2
OUT	GP5
VCC	3.3V
GND	GND

Point any NEC-compatible remote at the receiver. In Act X this is the local maintenance remote, not a convenience extra: the firmware decodes CHEM_IR_WARN (0x47), CHEM_IR_ACK (0x46), and CHEM_IR_TEST (0x45). There is no challenge and no secret on the optical surface, which is why a manual acknowledge is treated as a request and not as an authorization.

Using the remote

Point the NEC remote at the VS1838B receiver on GP5 and press the mapped button. The receiver idles high and pulls low on a mark, and the firmware times the NEC frame to decode the command.

NEC command	Code	Action
CHEM_IR_WARN	0x47	Raises the WATCH indication by setting the acknowledge request pending. It does not change the guarded hazard state and does not sound the siren.
CHEM_IR_ACK	0x46	Raises the WATCH indication as well. In monitor_apply_ir_command the firmware handles ACK exactly as it handles WARN, and it does not move the siren.
CHEM_IR_TEST	0x45	No state change. The firmware logs IR TEST (0x45) and returns, so in this firmware TEST is a maintenance marker rather than a lamp test.

RYLR998 LoRa radio

The RYLR998 must be powered. Forgetting VDD is the single most common reason the link appears dead: the firmware prints while the radio sits silent.

RYLR998	Pico 2
VDD	3.3V
GND	GND
RXD	GP8 (Pico UART1 TX)
TXD	GP9 (Pico UART1 RX)

Attach the antenna before transmitting. TX and RX are crossed: the radio's RXD is the Pico's TX and vice versa.

Debug Probe (recommended)

Debug Probe	Pico 2
SWCLK	SWCLK (3-pin debug header)
SWDIO	SWDIO
GND	GND
UART TX	GP1 (Pico RX)
UART RX	GP0 (Pico TX)
GND	GND

The firmware enables stdio on both UART0 (115200) and USB, so you can watch boot output on the probe's console or on the Pico's own USB serial port. The Debug Probe is also the instrument for the Lab 3 incident-response work: it is how you prove the siren is being silenced, read the reserved-sector marker, inspect the beacon, and step past the anti-debug trap.

Peripherals used

Peripheral	Connection	Role
Three annunciator LEDs	GP16 red, GP17 yellow, GP18 green	Solid HAZARD, WATCH, and CLEAR lamps, one at a time.
Manual acknowledge button	GP15 to GND	Debounced local acknowledge; raises the WATCH indication and never changes the guarded hazard state.
1602 I2C LCD	GP2 SDA, GP3 SCL, I2C1 address 0x27	Hazard readout of state, link, zone, temperature, and sabotage marker.
DHT11	GP4	Chemical store temperature sensor, classified against 0.0 C to 40.0 C.
SG90 servo	GP14	Siren and vent actuator driven by 50 Hz PWM.
1000uF capacitor	across the servo 5V and GND rails	Bulk decoupling for the siren inrush; required in hardware and not firmware visible.
VS1838B infrared receiver	GP5	Demodulated NEC input for the local maintenance remote.
NEC infrared remote	optical link to the VS1838B	Sends WARN, ACK, and TEST.
RYLR998 LoRa transceiver	GP8 RX, GP9 TX, UART1 at 115200 baud	Sealed hazard command link to the safety control gateway.
Onboard GP25 LED	GP25	Onboard heartbeat; pulses once on every monitor tick.
Debug Probe	GP0 TX, GP1 RX, UART0, and SWCLK/SWDIO/GND	stdio console, flashing, and the GDB anti-debug work.

Every peripheral above is used by the firmware. The 1000uF capacitor is a hardware requirement rather than a firmware device. There is no transmit blink.

How the functionality works

This is the end-to-end behavior of the running node: what each input does, what each output shows, and how to watch the live console. The DHT11 is sampled every two seconds, so one live status line appears about every two seconds.

Inputs

Input	Pico 2	What it does
Infrared maintenance remote	GP5 (VS1838B)	Decodes a NEC frame into WARN (0x47, CH+), TEST (0x45, CH-), or ACK (0x46, CH). WARN and ACK raise the watch-pending indication; TEST is a maintenance marker. No remote code can change the guarded hazard state on its own.
Manual acknowledge button	GP15 to GND	A debounced press raises the watch-pending request. It asks for authorization and never bypasses the sealed hazard path or silences the siren.
DHT11 store sensor	GP4	Samples the chemical store every tick and classifies it against the safe band. A failed read is not nominal.
RYLR998 LoRa radio	GP8/GP9, UART1	Carries the sealed hazard command path. Every inbound frame is authenticated and anti-replay checked before it can move the siren.

Outputs

Output	Pico 2	What it shows
Red HAZARD LED	GP16	Solid when a chemical release hazard is declared, a command was rejected, or the terminal failed safe.
Yellow WATCH LED	GP17	Solid when the store is under watch or a manual acknowledge is pending authorization.
Green CLEAR LED	GP18	Solid when the store is clear; in the SANDBOX_ONLY build the sabotage override forces this lamp during a declared hazard.
1602 LCD	GP2/GP3, I2C1 0x27	Line 1 ST:CLEAR L:UP is the state and safety link; line 2 Z:4 T:235 M:-- is the storage zone, store temperature in tenths, and sabotage marker.
SG90 siren servo	GP14	50 Hz PWM: raised sounds the hazard, lowered shows clear or watch.
Onboard GP25 LED	GP25	Pulses once on every monitor tick as the heartbeat; it is not a transmit blink.

Exactly one annunciator lamp is lit at a time and no lamp blinks in the clean firmware. The siren moves only after the guarded state machine decides.

Watching the interactive console

The firmware enables stdio on both UART0 (115200, Debug Probe) and the Pico's own USB serial port (115200). Open either at 115200 8N1 and reset the board. After BOOT and the I2C scan, the node prints a boot banner and then one line per event:

BOOT
I2C scan:
  found 0x27
=== OPERATION IRON CURTAIN // ACT X CHEMICAL WARNING TERMINAL ===
Remote: CH+ 0x47 WARN, CH- 0x45 TEST, CH 0x46 ACK
Button: local acknowledge request, never bypasses authorization
STORE t=235 ok=1 LED=3 cyc=12
IR WARN (0x47)
BUTTON acknowledge request -> pending
RX from 0x0001, 126 bytes
STORE read failed -> WARNING

Line	Meaning
STORE t=... ok=... LED=... cyc=...	One live status line per reading cycle: store temperature in tenths, the in-band verdict, the effective annunciator state, and the reading-cycle count.
STORE read failed -> WARNING	The DHT11 did not answer or failed its checksum, so the store is treated as not nominal.
IR <NAME> (0xNN)	A decoded remote command, named WARN, TEST, ACK, or UNKNOWN.
BUTTON acknowledge request -> pending	The manual acknowledge button raised a pending request.
RX from 0xNNNN, N bytes	One inbound radio frame, with the reported sender address and payload length, before it is authenticated.

Build and Flash

1. Install toolchain prerequisites

• Pico SDK 2.2.0+
• ARM GNU toolchain (arm-none-eabi)
• CMake and Ninja
• Python 3.x
• GDB (arm-none-eabi-gdb) for the Lab 3 malware analysis

Linux:

export PICO_SDK_PATH="$HOME/.pico-sdk/sdk/2.2.0"

macOS:

brew install cmake ninja arm-none-eabi-gcc python
export PICO_SDK_PATH="$HOME/.pico-sdk/sdk/2.2.0"

Windows: install PowerShell, Visual Studio Build Tools, CMake, Ninja, Python 3, and the ARM embedded toolchain.

2. Build the firmware

The clean firmware does not define SANDBOX_ONLY, so it ships no finale implant:

mkdir -p build && cmake -S . -B build -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s && cmake --build build

To build the implant image with the beacon compiled in, turn the option on:

cmake -S . -B build-sandbox -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s -DSANDBOX_ONLY=ON && cmake --build build-sandbox

Build-time artifact guardrail:

• The build regenerates packet_artifact.h from scripts/packet_artifact.json before compiling.
• The build fails if the committed include/packet_artifact.h is stale relative to the JSON artifact.

Generated outputs:

• build/chemical_warning_terminal.elf (primary firmware binary)
• build/chemical_warning_terminal.uf2 (UF2 for BOOTSEL/picotool)
• build/chemical_warning_terminal_app.elf / .uf2 (backward-compatible copies)

3. Flash the RP2350

BOOTSEL (drag-and-drop): hold BOOTSEL while plugging in USB, then:

cp build/chemical_warning_terminal.uf2 /Volumes/RP2350/

picotool:

picotool load build/chemical_warning_terminal.uf2 -fx

(If picotool is not on your PATH, invoke it from $HOME/.pico-sdk/picotool/*/picotool/picotool.)

Debug Probe (SWD): with openocd installed you can flash and reset without touching BOOTSEL:

openocd -f interface/cmsis-dap.cfg -f target/rp2350.cfg \
  -c "program build/chemical_warning_terminal.elf verify reset exit"

4. Watch the console

Open the UART0 console (Debug Probe) or the Pico's USB serial port at 115200. On reset you should see:

BOOT
I2C scan:
  found 0x27
=== OPERATION IRON CURTAIN // ACT X CHEMICAL WARNING TERMINAL ===
Remote: CH+ 0x47 WARN, CH- 0x45 TEST, CH 0x46 ACK
Button: local acknowledge request, never bypasses authorization
STORE t=0 ok=1 LED=3 cyc=1

found 0x27 confirms the LCD backpack answered on the I2C bus. The boot banner names the operation and the remote button roles, and STORE t=... ok=... LED=... cyc=... is the live status line printed every reading cycle. The full set of console lines is described in How the functionality works. If a peripheral fails, the firmware prints INIT FAIL and stops.

Lab 1: Bring-Up and Verify

Goal: prove the node reads the store temperature, drives the LCD, takes a local acknowledge, reaches the gateway, and moves the siren.

1. Wire the node per the pin map and attach the antenna.

2. Build and flash the clean firmware.

3. Connect the gateway radio to the laptop and find its port (/dev/cu.usbserial-* on macOS, /dev/ttyUSB* on Linux).

4. Start the safety control gateway:

   python3 scripts/gateway.py --port /dev/cu.usbserial-XXXX --baud 115200


5. Send a sealed zone request from the edge simulator, or seal one from a node. The gateway prints it, then answers with a sealed hazard command:

   +OK
   +OK
   +RCV=7,84,<84 hex characters>,-11,10
   SIREN raise seq=1 zone=4


6. The node turns yellow (WATCH) when a manual acknowledge is pending, receives the command, verifies the state tag and the anti-replay window, then drives the siren to the authorized position. Press the manual acknowledge button at any time to raise a request.

Checkpoint: the LCD shows ST:CLEAR L:UP and Z:4 T:235 M:--, one lamp is lit after the siren settles, and chem_log.csv gains one row per request:

utc,sender,auth,zone,rssi_snr
2026-09-20T09:30:05+00:00,7,OK,4,"-11,10"

Theory check: why does a successful command prove the LCD initialized? Because monitor_init() only returns true when every peripheral, including the LCD, is ready; otherwise main prints INIT FAIL and never enters the loop.

Lab 2: Inspect the Wire Protocol

Goal: see the sealed envelope and the declared-length rule in action.

1. Capture a full +RCV line from the console or the gateway log.
2. Confirm the declared length equals the number of hex characters between the second comma and the RSSI field.
3. Split the hex into three parts: the first 48 hex characters are the 24-byte nonce, the last 32 are the 16-byte tag, and everything between is the ciphertext of the request or command body.
4. Locate the payload, its declared length, and the two tail fields in scripts/gateway.py (_rcv_parts and _split_payload), and explain why finding the first comma would be a bug.
5. Challenge: for the 23-byte command body, identify the four bytes of the sequence number, the one command byte, the two zone bytes, and the sixteen bytes of the state tag.

Checkpoint: you can explain why a frame must be sliced by the number in the declared length field, not by delimiter counting, and why the command byte and the zone are range-checked against the guarded set and the bounded band before they can reach the siren decision.

Lab 3: The Finale Track

Goal: find the FROSTLINE coordinated beacon, prove that it silences the siren and forces the all clear, expose its sabotage marker, cut the beacon, break the persistence, clear the marker, and remove it for good. This is the coordinated finale, and this lab is its heart.

Safety: the implant is benign and confined to your breadboard. It drives only your mock siren servo and your mock LCD, it stands down on a documented token, and it writes only the reserved sector at 0x103FF000, on the same chip. There is no network, no filesystem, and no host impact. The sabotage marker is a real sector erase and program, but the siren and the display are the only things it affects, and it holds no real hazard.

Build the implant image

cmake -S . -B build-sandbox -G Ninja -DPICO_BOARD=pico2 -DPICO_PLATFORM=rp2350-arm-s -DSANDBOX_ONLY=ON && cmake --build build-sandbox

The clean build does not define SANDBOX_ONLY; the test build and the companion CTF build do. Compare the two binaries and explain why the beacon symbols are absent from the clean one.

A: Find the coordinated beacon and the marker

1. Flash the SANDBOX_ONLY image and let it boot once. implant_init writes the 0x58 marker into the reserved sector at 0x103FF000 on the first run with the real flash API.
2. Read the reserved sector with the Debug Probe or picotool and confirm the marker byte. The LCD sabotage field reads M:SAB.
3. Watch the panel. While the marker is present the beacon forces the effective state to CLEAR, silences the siren, lights the green CLEAR lamp, and renders ST:SAFE, even though the guard state would otherwise sound the hazard siren.
4. Locate implant_init, implant_beaconize, and implant_infect, and explain why the beacon and the sabotage are local conditions that ignore the sealed command path.

The lesson: the beacon does not need the wire or the key, because it changes the output after the authenticated decision is made.

B: Cut the coordinated beacon

1. Read implant_tick, implant_advance_stage, and CHEM_IMPLANT_BEACON_STAGES: a full check-in cycle is three stages, and the beacon re-asserts every CHEM_IMPLANT_BEACON_INTERVAL (4) ticks.
2. Prove the multi-stage check-in by stepping the tick counter and reading implant_stage() and implant_beacon_count(), and show that the marker is re-written on each due tick.
3. Call implant_neutralize, or present the exact 24-byte IRON-CURTAIN-BEACON-2026 token to implant_disable, and prove the beacon stands down and the stage resets.
4. Present a wrong token, a short token, and a null pointer, and prove each one leaves the beacon armed.

The lesson: cutting the beacon stops the check-in, but it does not remove the state that re-arms a future boot.

C: Break the persistence

1. Read implant_init: on the first run the marker is absent and implant_infect writes it; on every later boot the marker is present and the beacon re-installs and records implant_reinstalled().
2. Reflash only the firmware image (the clean image is ideal) and let the node boot again. Because the marker is still in the reserved sector, the beacon re-installs and the display returns to M:SAB.
3. Prove the persistence by reading the reserved byte after the reflash, and explain why a firmware reflash does not touch the reserved sector.
4. Explain why BOTH steps are required: cutting the beacon makes the siren honest now, and clearing the marker removes the state that would re-arm a future boot.

The lesson: a coordinated payload has two copies, the one in the image and the one in the state. You remove the payload and you remove the marker.

D: Clear the sabotage marker

1. Read the marker at 0x103FF000 and confirm it is the 0x58 byte.
2. Erase the reserved sector, or call implant_neutralize, and prove the node comes up with the marker gone and the M: field on the LCD back to --.
3. Reflash only the firmware image and let the node boot again. Because the marker is gone, the beacon does not re-install and the siren is honest.
4. Explain why clearing the marker is the incident-response control that closes the persistence, not merely a cleanup.

The lesson: the marker is the persistence. Clearing it is how the response removes the ability to lie on the next boot.

E: Defeat the anti-debug with GDB

This is the dynamic-analysis trap. The beacon reads CoreDebug DHCSR at 0xE000EDF0; bit 0 is C_DEBUGEN and bit 1 is C_HALT. While a probe is attached, the beacon suppresses the marker and the sabotage.

1. Start the controller under the Debug Probe:

   arm-none-eabi-gdb build-sandbox/chemical_warning_terminal.elf
   (gdb) target extended-remote /dev/cu.usbmodemXXXX
   (gdb) monitor reset halt


2. Break in implant_tick and inspect implant_debug_attached. With a normal probe attached, it returns true, and the beacon is suppressed.

3. Set a breakpoint after the anti-debug check, or clear the DHCSR debug bits in the debugger's view, and observe the beacon and the ST:SAFE lie resume.

4. Prove the release: with the trap bypassed, present the magic token and watch the marker clear and the true hazard state return.

The lesson: an anti-debug check is a branch, and every branch is a place to stand. The correct neutralization is not to babysit the branch; it is to remove the code and the state it reads, and to make the terminal fail safe by policy.

Finale checklist

• Locate the reserved-sector marker and explain the write-once first run.
• Identify the 0x58 marker, the IRON-CURTAIN-BEACON-2026 token and its 24-byte length, the 4-tick re-assertion interval, and the 3-stage cycle.
• Show the forced all clear and the ST:SAFE state, and prove they ignore the sealed command path.
• Cut the beacon with the magic token and clear the marker.
• Read and explain the CoreDebug DHCSR anti-debug trap.
• Erase the reserved sector, remove the code path, and confirm the clean build is beacon-free and marker-free.

Lab 4: The Fix Track

Goal: seal the terminal so the red half and the implant cannot do to you what they did on the bench. Each control maps to a defect the earlier labs exposed.

1. Seal the hazard command path

The old design accepted an unauthenticated hazard command. Act X replaces it with src/control.c: the request must open under the field key, the command byte must be in the guarded hazard set, the zone must be inside the provisioning band, and the sequence and state tag must pass src/chem_auth.c before the command is applied. Re-run the Lab 3 forged-command injection: the tag fails and the siren does not move.

2. Acknowledge authorization

The local acknowledge request is an operator request, and it must not silently bypass authorization. monitor_handle_ack and monitor_apply_ir_command raise g_ack_pending; they never change the guarded hazard state on their own. monitor_apply_command clears the pending indication only when an authorized command arrives. Re-run the lab: press the acknowledge button, then send a valid sealed hazard command. The siren moves only from the authorized command, and the yellow WATCH lamp returns to green only then.

3. No untrusted task execution

The clean build compiles the beacon path out entirely, so an untrusted frame can never force an all clear or silence the siren (monitor_implant_init and monitor_implant_tick are no-ops in the clean build). The lesson is that a control node must never let a local condition override an authorized decision or the temperature interlock. In the fix track, remove the SANDBOX_ONLY build flag and erase the reserved sector so no node can be seeded again.

4. Fail to the safe hazard state

Loss of the control link or a fault must leave the store in the safe state. monitor_check_link calls monitor_fail_safe when the link goes silent for CHEM_LINK_WAIT_MS, which sets the hazard state, drives the fail-safe zone, and calls siren_fail_safe to raise the siren. siren_init raises the hazard siren at boot. Re-run the link-loss test: pull the gateway and watch the siren raise and the fail-safe posture latch, with the zone returned to 0.

5. Contain the implant

The implant is a build-time and state-handling problem, so the fix is a build-time and state-handling control:

• Do not define SANDBOX_ONLY in production. The clean build has no beacon.
• Erase the reserved sector so no persisted state can re-install the payload.
• Treat the firmware image as a signed artifact and verify it before flashing.
• At runtime, never let a condition override an authorized command or the temperature interlock; route every move through the guarded, authorized path and record who authorized it.
• In production, burn the RP2350 secure-boot and debug-disable settings in OTP so SWD cannot read or write SRAM on a deployed controller.

The fix-track checklist

• Sealed command path: authenticate the frame, guard the command set and the zone band, verify the sequence and the state tag.
• Acknowledge authorization: request, do not bypass.
• No untrusted override: the node never forces an all clear because of a local latch, and never silences the siren against the interlock.
• Fail safe: raise the siren on boot, fail safe on link loss, and return the fail-safe zone.
• Implant removal: cut the beacon, clear the marker, erase the reserved sector, and remove the code path.
• Build integrity: no SANDBOX_ONLY in production, sign and verify images.
• Debug lockdown: OTP debug disable on the deployed part.
• Key lifecycle: provision the field key from OTP and rotate on a schedule.

Troubleshooting

Symptom	Likely cause	Fix
No BOOT on the console	Wrong console pins / not reset	Check UART0 GP0/GP1 or USB; press RESET
INIT FAIL with no 0x27 in the scan	LCD not answering	Check LCD VCC=3.3V, SDA=GP2, SCL=GP3, contrast pot
LCD shows blocks / nothing	Contrast or address	Turn the backpack contrast pot; confirm address 0x27 vs 0x3F
Store temperature always bad	DHT11 not reading	Check DATA=GP4; add 10K pull-up to 3.3V; wait 1-2 s after power-up
IR remote does nothing	Receiver wiring or remote protocol	Check OUT=GP5, VCC=3.3V; confirm the remote is NEC-compatible
Siren will not move on a remote command	Command guard, band, or tag	Confirm the gateway holds the field key and the zone is inside 0 to 16
AT+SEND sent but gateway sees nothing	Radio unpowered / wrong band	Power VDD, attach antenna, use matching band modules
Gateway sees nothing but +OK	Address/network mismatch	Confirm gateway radio provisioned to AT+ADDRESS=1, AT+NETWORKID=18
chem_log.csv stays empty while +RCV prints	Gateway parser regression	Ensure _split_payload checks the comma at the declared length
Command rejected on the controller	Tag, window, command guard, or band	Check the field key matches, the sequence is newer, and the zone is in band
LCD shows M:SAB or ST:SAFE while nothing looks wrong	Sabotage marker present (SANDBOX_ONLY build)	The beacon has written the marker; see Lab 3A
Siren stays silent despite an authorized hazard	Sabotage override (SANDBOX_ONLY build)	Expected in the malware-track build; cut the beacon in Lab 3B
Marker reappears after a reflash	Reserved-sector persistence	The payload is still in the reserved sector; clear it and remove the code path (Lab 3)
Debugger changes implant behavior	CoreDebug DHCSR anti-debug	The beacon suppresses itself while a probe is attached; see Lab 3E
Node forces an all clear	Local override	In production never define SANDBOX_ONLY; see Lab 4

Testing Philosophy and Coverage

Hardware bugs are expensive to find on the bench, so the firmware is written so that almost all of it can be tested on the host. The suite compiles the real src/*.c files against mock Pico SDK headers (test/mock/), replacing GPIO, I2C, UART, and time with deterministic fakes, and it compiles src/implant.c with a host mock for the CoreDebug DHCSR register and the reserved flash sector.

• The mock GPIO can replay a recorded DHT11 waveform as an absolute time/level timeline, so the exact edge-timing decoder is exercised without a sensor.
• The mock I2C records every LCD byte, so rendered text can be decoded and asserted.
• The mock UART records outbound AT+SEND bytes and injects inbound +RCV lines, so the operator-to-gateway-to-siren path runs end to end with no radio.
• The implant host mock lets the tests set the DHCSR anti-debug bits and read and write the reserved-sector marker without touching real silicon, and it exposes the beacon stage and the sabotage override so the 0x58 marker path can be asserted.

Run the native test suite:

python3 scripts/run_tests.py

Or configure via CMake and CTest:

cmake -S test -B build-test -G Ninja && cmake --build build-test && ctest --test-dir build-test --output-on-failure

The suite has 145 cases and 501 checks with 0 failures, covering the full DHT11 waveform and every timeout shape, the siren state machine and its bounded travel, the sealed command path and its guards, the authorization window and state tag, the acknowledge no-bypass path, fail safe on link loss, the declared-length parser with hex-bearing payloads, the cryptographic primitives against published vectors, and the complete coordinated beacon: the multi-stage check-in, the forced all clear, the 0x58 marker, re-install on boot, the magic beacon command, and anti-debug.

Verify 100% line coverage of owned firmware modules:

python3 scripts/check_coverage.py

The coverage report shows 2123 / 2123 lines, 100.00%. main.c is excluded from coverage by design. The Python adapter suite (test/test_field_crypto.py and test/test_chem_node.py) adds 17 more tests, including the RFC 9106 Argon2id known-answer test.

The harness itself is a small in-repo framework (test/harness/) so the repo vendors no third-party code and every owned file obeys the coding standard.

Generating Packet Artifacts

scripts/gen_packet.py writes the build-time generated header from the JSON artifact:

• scripts/packet_artifact.json is the source of truth.
• include/packet_artifact.h is the generated header, committed for the build guardrail.

Why these constants are compiled into firmware:

• The RP2350 firmware has no runtime JSON parser or filesystem on this path.
• include/packet_artifact.h is generated from the JSON so the frame size, node id, gateway address, wait time, servo pulses, DHT timeout, and provisioning constants are embedded in flash.
• This is provisioned data; regenerate whenever you rotate node identity, gateway addressing, or key material.

To sync the committed header from the JSON artifact:

python3 scripts/gen_packet.py --from-json scripts/packet_artifact.json --header-out include/packet_artifact.h

The check_packet_artifact_header CMake target fails the build when the committed header is stale.

Code Standards

This repository enforces unusually strict standards because the point is to teach disciplined embedded and tooling practice, not just working code.

C standard

• Every function body has no blank lines.
• Every function body is at most eight lines (Doxygen comment blocks and lone braces excluded).
• Every file, function, macro, type, and struct member carries Doxygen @brief documentation.
• Naming: snake_case files/functions, UPPER_SNAKE macros, snake_case_t types.

Run the C audit:

python3 scripts/audit_c_standard.py

Python standard

• Strict PEP8, four-space indents, snake_case, 79-character lines.
• Every function has a NumPy-style docstring.
• Every function executable body is at most eight lines, with no exceptions.
• No blank lines inside function bodies.

Run the Python audit:

python3 scripts/audit_python_standard.py

Both audits must report nothing.

Project Layout

• src/main.c: firmware entry point
• src/monitor.c: state machine tying the maintenance remote, sealed command path, siren, manual acknowledge request, temperature sensor, and radio together
• src/implant.c: SANDBOX_ONLY FROSTLINE coordinated beacon (multi-stage check-in, ST:SAFE override, magic beacon command, reserved-sector 0x58 marker, re-install, CoreDebug anti-debug)
• src/siren.c: siren state machine and fail-safe policy
• src/control.c: sealed hazard command path with a guarded command set and a bounded zone band
• src/chem_auth.c: authorization record, monotonic anti-replay window, authenticated state tag
• src/sensor.c: DHT11 one-wire sampling and store-temperature-band classifier
• src/display.c: 1602 LCD rendering over the PCF8574 I2C backpack
• src/radio.c: RYLR998 provisioning, AT-command interface, and +RCV parser
• src/status_led.c: red/yellow/green HAZARD / WATCH / CLEAR annunciator light
• src/button.c: debounced manual acknowledge input
• src/servo.c: 50 Hz PWM siren and vent actuator
• src/ir_remote.c: VS1838B edge timing and NEC maintenance remote decoder
• src/crc.c: CRC-16/CCITT-FALSE helper
• src/chacha20.c, src/poly1305.c, src/crypto_aead.c, src/blake2b.c, src/argon2.c, src/crypto_kdf.c, src/envelope.c: the in-repo cryptographic stack
• include/chem.h: board-level pin, provisioning, and hazard configuration
• include/implant.h, include/control.h, include/chem_auth.h, include/siren.h: beacon, command, authorization, and siren interfaces
• include/field_secrets.h: lab-only committed key material
• include/packet_artifact.h: generated packet artifact header
• test/test_chem_node_and_security.c, test/test_peripheral_and_crypto.c: comprehensive test suites
• test/mock/: Pico SDK hardware mocks plus the implant CoreDebug and reserved-flash host mock
• test/harness/: minimal in-repo test harness (strictly C-standard compliant)
• scripts/gateway.py: safety control gateway with radio provisioning, authentication, CSV logging, and sealed command replies
• scripts/spoof.py: forged and replayed command injection client
• scripts/sim_edge.py: laptop warning terminal simulator
• scripts/field_crypto.py: pure-Python interoperable crypto
• scripts/gen_packet.py / scripts/packet_artifact.json: packet artifact generator and source
• scripts/run_tests.py, scripts/check_coverage.py: test runner and coverage report
• scripts/audit_c_standard.py, scripts/audit_python_standard.py: code-standard auditors
• scripts/gen_banner.py: banner generator
• paper.typ / paper.pdf: classroom paper describing the protocol, the coordinated beacon, and the exercise
• .github/workflows/release.yml: tag-driven UF2 release workflow

Glossary

• AEAD: authenticated encryption with associated data; one operation for secrecy and integrity.
• Anti-debug: a check that detects an attached debugger and changes behavior. Here it reads CoreDebug DHCSR at 0xE000EDF0 (bits C_DEBUGEN and C_HALT).
• Anti-replay window: a monotonic sequence rule that rejects a valid frame that has already been used.
• Argon2id: the memory-hard password hash (RFC 9106) used to derive the field key.
• AT command: a short ASCII command (AT+...) understood by the radio.
• Beacon: the coordinated multi-stage check-in the finale implant runs every four ticks.
• Declared length: the byte count the sender claims for a payload; the receiver slices exactly that many characters.
• DHT11: a low-cost temperature/humidity sensor using a custom one-wire protocol, used here as the chemical store temperature sensor.
• Fail safe: a fault raises the siren to the safe hazard posture and returns the fail-safe zone.
• Field key: the key that seals frames on the wire and computes the state tag.
• HD44780: the character-LCD controller inside a 1602 module.
• I2C: a two-wire bus (SDA/SCL) used here for the LCD backpack.
• Implant: code that runs on the device but is not part of its intended function. Here the SANDBOX_ONLY FROSTLINE coordinated beacon.
• LoRa: a long-range, low-power sub-GHz radio modulation.
• Magic beacon command: the exact 24-byte IRON-CURTAIN-BEACON-2026 string that arms or releases the beacon.
• Masking: a local condition that makes a hostile state read as a routine one; here the forced all clear and the ST:SAFE label.
• NEC: the infrared remote encoding the VS1838B decodes.
• PCF8574: an I2C I/O expander that drives the LCD's parallel interface.
• Reserved sector: the final flash sector at 0x103FF000, used here to hold the one-byte sabotage marker.
• Sabotage marker: the 0x58 byte the beacon writes into the reserved sector.
• SANDBOX_ONLY: the build guard that compiles the benign finale implant. The clean firmware does not define it.
• State tag: a keyed tag over the authorization record that detects a tampered verdict.
• Tower light: the red/yellow/green HAZARD / WATCH / CLEAR lamps.
• UART: a serial port used to talk to the radio.
• XChaCha20-Poly1305: the AEAD used for every sealed frame, with a 192-bit nonce and a 128-bit tag.

Further Reading

• Act I, the sensor and telemetry chapter: https://github.com/mytechnotalent/cold-chain-monitor
• Act II, the access gate chapter: https://github.com/mytechnotalent/access-gate
• Act III, the pipeline valve chapter: https://github.com/mytechnotalent/pipeline-valve-controller
• Act IV, the HVAC automation node chapter: https://github.com/mytechnotalent/hvac-automation-node
• Act V, the industrial tamper system chapter: https://github.com/mytechnotalent/industrial-tamper-system
• Act VI, the smart logistics drop-box chapter: https://github.com/mytechnotalent/smart-logistics-dropbox
• Act VII, the factory andon station chapter: https://github.com/mytechnotalent/factory-andon-station
• Act VIII, the datacenter vent controller chapter: https://github.com/mytechnotalent/datacenter-vent-controller
• Act IX, the smart parking barrier chapter: https://github.com/mytechnotalent/smart-parking-barrier
• The companion CTF for this act: https://github.com/mytechnotalent/CTF_chemical-warning-terminal
• Embedded Hacking course and breadboard: https://github.com/mytechnotalent/Embedded-Hacking
• Reverse Engineering self-study course: https://github.com/mytechnotalent/Reverse-Engineering
• paper.typ / paper.pdf: the classroom paper for this project.
• DHT11 datasheet, RYLR998 AT command reference, SG90 datasheet, and VS1838B datasheet (module vendors).

Next

OPERATION IRON CURTAIN CTF

License

MIT License
